- Page 1 Operating Instructions ASCOLINE 700 AEH 350, 358 Electrical Induction Ranges Quality and Competence in Stainless Steel...
-
Page 2: Table Of Contents
Operating Instructions Ascoline 700, AEH 35x 1 Table of Contents Page Table of Contents ......................2 Details of the Equipment ....................3 Instructions on Safe-handling of the Equipment ............3 General instructions ......................3 Safety instructions for operating, cleaning and repair ............3 Instructions for transport .................... -
Page 3: Details Of The Equipment
Operating Instructions Ascoline 700, AEH 35x 2 Details of the Equipment Appliance type Version ID No. Free-standing appliance AEH 350 Electric Induction Range 6517.100 Wall and table top appliance AEH 358 Electric Induction Range 6615.100 (See data sheet in annex for technical data.) 3 Instructions on Safe-handling of the Equipment 3.1 General instructions... -
Page 4: Instructions For Transport
3.3 Instructions for transport Transport ascobloc equipment only in the original packaging. This avoids unnecessary damage and expense. Check equipment for damage. Do not lift or shift the appliance by holding the top plate, the bottom edges at the sides of the appliance or by the door handles. -
Page 5: Proper Use Of The Equipment
Operating Instructions Ascoline 700, AEH 35x diagram is to be found on the type plate. Once the electrical connections have been made, close the cover of the terminal box and screw the front panel in place again 4.2.1 Free-standing appliances The connections can be made from below or from the rear from a closed installation space. -
Page 6: Cleaning
Operating Instructions Ascoline 700, AEH 35x You can now put the main switch for the cooking zones to -0-. The green pilot light goes out. The pot/pan diameter should not be smaller than the circle shown in the front cooking zone. The cooking zone monitoring does not switch the power on till a sufficiently large pot is placed on the hob. -
Page 7: Repair And Maintenance
Operating Instructions Ascoline 700, AEH 35x Under no circumstances should plastic sponges with embedded sand grains or steel wool be used. Sand grains from cleaning salad or peeling potatoes that get onto the ceramic plate can cause scratches when pots and pans are moved back and forth. -
Page 8: Faults And Their Rectification
Operating Instructions Ascoline 700, AEH 35x 7 Faults and their Rectification 7.1 Fault indication on the display Short circuit temperature sensor, hob temperature too low < -50°C Temperature of hob too high, hob temperature sensor interrupted > 260°C No pan on the hob (pan too small for the hob) Wrong pan on the hob, short circuit of the induction coil Heat sink temperature >... -
Page 9: Fault Rectification
Operating Instructions Ascoline 700, AEH 35x 7.2 Fault rectification Always disconnect the power plug before starting any repair work! Fault Cause Remedy -No current -Check power supply -Power rotary knob in OFF position -Switch on power rotary knob -Pot too small... -
Page 10: Spare Parts
Operating Instructions Ascoline 700, AEH 35x 8 Spare Parts 8.1 List Item Name Type / Version Art. No. Remarks 08/6232 Appliance foot 08/2939 Scale ring 08/2951 Scale ring for on-switch 09/2662 Knob 09/3310 Generator BIM 5/260 400 V 08/2549 Glass ceramic cooking surface... -
Page 11: Declaration Of Conformity
Operating Instructions Ascoline 700, AEH 35x 9 Declaration of Conformity EC Declaration of Conformity for the CE Mark The manufacturer Gastro-Gerätebau GmbH Grüner Weg 29 D-01156 Dresden hereby declares that the appliance described below Appliance type Version ID No. Free-standing appliance...
