Sportstar Outdoor Pioneer II User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Outdoor Pioneer II and is the answer not in the manual?

Questions and answers

Related Manuals for Sportstar Outdoor Pioneer II

Summary of Contents for Sportstar Outdoor Pioneer II

  • Page 2: All Modes

    ·Outdoor Pioneer II User Manual The watch features a Dot matrix display and is equipped with special features such as sail, ski, altimeter, barometer and compass modes. The altimeter and barometer is capable of storing 24 hours of data which enables the user to recall 24 hours of previous readings.
  • Page 3 Press S2 to change the display to your preferred view. Figure 2 How to change from Time 1 to Time 2: To change from Time 1 to Time 2 or vice versa, press and hold S1 till T1 or T2 icon stops blinking. Figure 3...

  • Page 4: How To Set The Time

    How to set the Time: · While in time mode, press and hold S4 to enter time setting mode. The watch will display SET HOLD. · Continue holding S4 until the hour digit starts to flash. · Press S1 to increase the value of the flashing digit. Press and hold S1 to fast increase the value. ·...
  • Page 5 Figure 3 Compass Calibration mode: 1.Entering the compass mode for the first time (After watch reset): 1.1) When the watch enters the Compass mode for the first time, it will automatically enter the Compass calibration mode. The watch will display ROTATE CAL. 1.2) Rotate the watch horizontally 2 times at a rate of 15 seconds per rotation.
  • Page 6 digit will start to flash. 1.6) Press S1 or S2 to change the value. 1.7) Press S3 to set the next digit. The next digit will start to flash. 1.8) Press S1 or S2 to change the value. The compass offset range is from 00 to 90 degrees.
  • Page 7 2. Normal Compass calibration mode: Follow this procedure if the watch has already been calibrated previously. 2.1) While in Compass mode, press and hold S4 for 2 seconds. The watch will display CAL HOLD. 2.2) Continue holding S4 until the watch will display ROTATE CAL. 2.3) Rotate the watch horizontally 2 times at a rate of 15 seconds per rotation.

  • Page 8: Barometer Mode

    Figure 6 Barometer Mode ·Press S3 from Compass mode to Barometer mode. The watch will momentarily display BARO and then display view 1. Barometer mode has 5 views available for the user to choose. ·The watch can predict the weather condition for the next six hours provided it has accumulated 12 hours of previous barometric pressure readings...
  • Page 9 → View 1 Weather icon/ Sea Level pressure/ Current barometric pressure/ pressure Graph/ Temperature View 2→Weather icon/ Temperature/ Sea Level pressure/ Current barometric pressure/ Clock View 3→Weather icon/ Sea Level pressure/ Current barometric pressure/ Temperature View 4→Difference view - Weather icon/ Sea Level pressure/ Current barometric pressure/ Clock View 5→24 hour recall view.
  • Page 10 How to change the barometric pressure unit: · You can change the barometric pressure unit from mbar/hpa to inHg or vice versa. · Go to view 1 of Barometer mode. · Press and hold S1. Notice the unit icon will change and start to flash. ·...
  • Page 11 Figure 9 Difference View: · Go to view 4 of Barometer mode. The watch will momentarily display the sea level and current Barometric pressure and then display DIFF START HOLD.
  • Page 12 · Press and hold S4 until the watch resets the sea level and current barometric pressure to zero. · Press S1 or S2 to go back to current values. Press S4 to abort the difference measurement. ·While the Sea level and Current barometric pressure is reset to zero, press S4 to confirm and the watch will start the measurement.
  • Page 13 24 hour recall view: The can display the barometric pressure for the last 24 hours in graphical presentation. Press S1 to scroll through the data. HR 0 means the current pressure, HR -1 is the pressure 1 our ago and so on. Figure 11 How to calibrate the Barometer: To have a more accurate reading of the barometer and weather predictions shown by...

  • Page 14: Altimeter Mode

    · Press S1 or S2 to change the values. · Press S4 to exit calibration mode. The watch will also auto exit calibration mode if there is no button operation for 2-3 minutes. Altimeter Mode · Press S3 from Barometer mode to enter Altimeter mode. The watch will momentarily display ALTI and then display the current altitude, accumulated altitude, maximum altitude, and Time.
  • Page 15 Recording an Altimeter Log: · You can record an altimeter log in view 1 and view 2. · Maximum of 20 logs can be recorded in memory. Your saved data can be viewed in LOG DATA mode. · While in view 1 or view 2, press and hold S1 to start the log. The watch will display LOG 1 START and then display the following depending which view you have started the log: O View 1 Ascending or descending rate/ Ascending/ Descending/ current Altitude O View 2 Ascending or descending rate/ Current Altitude/ DIFF...
  • Page 16 How to change the Altitude unit: · You can change the temperature unit from Feet to Meter or vice versa. · Go to View 3 or View 4 of Altimeter mode. · Press and hold S1. Notice the unit icon will change and start to flash. ·...
  • Page 17 24 hour recall view: You can view the previous 24 hours record of Altitude and the ascending or descending rate of that selected hour in the past. Line 1 will display the Ascending or descending rate of the hour. Line 2 displays the altitude of the hour. Line 3 displays the previous time.
  • Page 18 Continue holding S4 until the watch displays the Current altitude. The word CURRENT will be flashing. Press S1 or S2 to select which parameter to set. Following is the sequence of setting when you press S1: → → → → →...
  • Page 19 Then press S3 to go back to field selection. To exit and save modified settings press Figure 16 Automatic switching between Barometer mode and Altimeter mode:...
  • Page 20 The will automatically switch from Altimeter mode to barometer mode if there is no significant changes in altitude for 3 0 m i n u t e s . T h e w e a t h e r icon will appear signifying that that watch has switched to barometer Mode.

  • Page 21: Ski Mode

    To clear a selected Log data press and hold S4 until the watch display C L E A R HOLD. Release S4 after 2 seconds and the selected file is already deleted. The watch will then display the next log file. To clear all logs continue to hold S4 and the watch will display CLEAR ALL HOLD.
  • Page 22 1. Using your current altitude at the finish line as your base altitude. · While in SKI mode and you being in the finish line location, press and hold S2. The watch will display STORE ALTI. · Continue holding S2 until the watch displays STORED ALTI. ·...

  • Page 23: Chrono Mode

    If your current Altitude is less than the base altitude + 35 feet, The Ski mode will not run and the watch will return to reset view. If your current Altitude is more than the base altitude + 35 feet, The Ski mode will start counting up until you reach the base altitude.
  • Page 24 Figure 17 Sail Mode · Press S3 from Chronograph mode to SAIL mode. The watch will momentarily display SAIL and then display the reset view. · Sail timer is a chrono timer combined with a countdown timer. This feature has a maximum capacity of 50 laps and a maximum time of 120 minutes.
  • Page 25 Every full minute short double beep Every 10secs during the last min. short double beep Every second during the last 10sec short single beep At completion of countdown timer long single beep The countdown timer set with the preset values ranging from 1 min to 120 min. To select the length of the countdown timer press S2 while the timer hasn't started yet.
  • Page 26 To select an alarm or chime press S2. Turn on the selected alarm or chime press S1. To set a selected alarm press and hold S4 until the watch display SET HOLD and then the hour digit starts flashing. To adjust the digit, press S1 to advance or press S2 to decrease the value.
  • Page 31 户外先锋Ⅱ说明书 基本操作 所有模式: 该手表为多功能数字手表，有以下 功能：时间，指南针，气压计，高 度计，记录高度数据，滑雪模式， 计时器，航海模式，闹铃和背光灯 功能。 按键位置: Figure 1 手表复位: 警告：复位之后，所有数据都将丢失，包括时间，闹 铃，和个人信息。 同时按下S1，S2，S3和S4按键，使手表复位。随后 所有显示点亮，伴有一声哔哔响，然后背光灯打开。 然后手表会显示软件编号代码。复位之后，用户需重 Figure 1 新设置手表。...
  • Page 32 省电功能: 为了节约电量，在手表复位之后，如果没有模式的改变，手表不会测量气压，温度和高度。 时间模式: 按S2，浏览不同时间视图；按S1，切换时间1和时间2. Figure 2...
  • Page 33 ■ 该手表有两个时间，时间1和时间2，分别计时。此手表支持的日历范围是2006年至2055年。 ■ 在时间模式，气压每2.5分钟读一次数据。温度每4分钟读一次。 ■ 高度和在高度模式中相同。如果30分钟内，高度没有明显变化，天气图标会自动出现，以 提示用户手表现在处于气压模式。 时间设置模式： 按S1按键，值调大；按S2按键，值调小。 Figure 2...
  • Page 34 指南针模式: 在手表显示的中央，以滚动的方式显示指南针方向。在手表显示的下方，以数字形式显示指 南针方向。 Figure 3...
  • Page 35 方位值角度： Figure 3 设置偏转角： n不同的位置有不同的偏转角度。为了获得更准确的指南针方向，建议设置手表的偏转角度。 n指南针的偏转范围是0-90度。如果偏移超过90度，就设置偏移为90度，并等待2-3分钟。如 果用户重新校准指南针，指南针的偏移值将变为0. 气压计模式:...
  • Page 36 气压计模式: 气压模式的不同显示视图： Figure 4 视图1：在视图1， 按住S1按键，改变气压单位，in hg 或mabr/hpa。...
  • Page 37 Figure 4 。 视图2：在视图2， 按住S1按键，改变温度单位，℃或 F Figure 4 视图3：在视图3， 按住S1按键，改变温度单位。同视图2.
  • Page 38 视图4：在视图4，测量海平面气压和当前气压的差值。 Figure 4 视图5：在视图5，浏览过去24小时的记录。...
  • Page 39 Figure 4 注：24小时气压图释义： Figure 4 设置天气和海平面气压：...
  • Page 40 在视图1, 视图2 或视图3的第一个显示视图，按住S4按键，设置天气和海平面气压。 Figure 4 注： 为了天气预报的准确性，需要12小时的气压改变才可以预报将来6个小时的天气预报。 压力传感器的范围是300-1100 毫巴/百帕。 高度计模式: 高度模式的不同显示视图：...
  • Page 41 Figure 5 视图1：在视图1， 按住S1按键，获得高度数据。 Figure 5...
  • Page 42 视图2：在视图2，获得 高度差的值。 视图3：在视图3，改变高 度单位，选择米或英尺。 Figure 5 Figure 5...
  • Page 43 视图4：在视图4，改变高度单位，选择米或英尺。 Figure 5 视图5：在视图5，查看过去24小时的记录。 Figure 5...
  • Page 44 高度设置模式： Figure 6...
  • Page 45 ■ 高度计和气压计自动转换（内部的）。高度模式的采样频率： 高度改变: 所有时间: 2 秒钟/次 高度没有变化: ---- 0 - 30 分钟: 2 秒钟/次 ---- >30 分钟 : 2.5 分钟/次 如果30分钟内都没有高度变化，天气图标出现，以指示该状态正在测量气压（2.5分钟/次）。 在高度模式中24小时之后，自动返回到标准时间模式。采样频率是2.5分钟/次。 - 如果30分钟内，高度没有明显变化，高度计自动转成气压计（天气图标出现）。手表 储存当前高度值。 - 如果短时间内，气压变化很大(>6 毫巴/百帕 每分钟), 手表自动转成高度计(天气图标消失）。 数据记录模式: Figure 6...
  • Page 46 Figure 7 Figure 7 注： 最多保存20个记录数据.
  • Page 47 滑雪模式： Figure 8 注： - 1小时后，运动模式会自动复位， 即使没有达到基准高度值。 - 运动模式停止后，不可以在重新开始。 - 按住S4保存基准高度（在运动开始之 前）。在按S4按键2秒钟，设置基准高度。 - 运动模式开始之后的8分钟内，每1秒 钟读一次数据，之后每1分钟读一次 Figure 8 数据，知道运动模式自动复位。...
  • Page 48 计时器模式： Figure 9...
  • Page 49 航海模式： 在开始累积计时之前，用户可以选 择准备时间，准备时间倒计时到0 之后，手表自动开始累积计时。 选择倒计时时间：进入海航模式， 手表自动显示当前预设置倒计时准 Figure 10 备时间，按S2选择倒计时时间。 倒数计时(准备时间):选择倒计时时间之后，按S1按键，开始倒计时，再按S1按键，停止计时 Figure 1 0...
  • Page 50 开始计时：倒计时完成之后，手表自动开始累积计时。计时期间，获得数据。 查看计时数据 Figure 1 0 注： - 预设置时间范围：选择倒数计时 的时间（以分钟为单位） 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15, 20,25,30,35,40,45,50,55,60,70,80, Figure 10 90,100,110,120...
  • Page 51 闹铃模式: - 手表有2个每日闹铃，闹铃1和闹铃2. - 闹铃时间既是标准时间。 - 自动退出设置模式时，闹铃打开。 - 闹铃1或闹铃2打开，闹铃图标都会出现。 - 闹铃图标只出现在时间模式和闹铃模式。 - 如果闹铃设置为开，在每日闹铃时间， 闹铃会响闹。 - 在闹铃响闹时，按任何按键关闭闹铃。 闹铃在20秒钟之后，自动关闭。 Figure 11...
  • Page 52 - 同时按下2个或多个按键，手表有 反应但是不会有任何功能（除了， 同时按下4个键，复位），打断正 在进行的功能。 Figure 12...
  • Page 54 SPORTSTAR伙伴产品美国MIO系列产品...
  • Page 55 联系我们: 中国总经销：深圳市健康鼠科技有限公司 联系电话：0755-86329391 0755-86329089 0755-86329323 0755-86329538 网址：www.fitmouse.com，www.sportstar.com.cn...
