Quick User Guide
Model MCN-AS1020
Before using this machine, read the operator's manual in its entirety.
Failure to follow operating instructions could result in death or serious
injury. Full operation manual available at www.moe-cleaner.com
Step 1
Insert Handle
Step 3
Insert Locking Taper Pin
Step 6
Connect Power Cable from
Pump to Cleaning Head
Step 2
Insert Clevis Pin
Connect Electrical Connectors from
Handle to Cleaning Head
Step 4
Connect 4 Pin (Female) into 4 Pin
Receiver. Turn threads to lock.
Step 7
Connect Power Cable from
Handle to Pump
Step 5
Connect 3 Pin same as 4 Pin Cable
Step 8
Add 2 gallons clean cold water and
approved Encapsulator Cleaning
Solution
Advertisement
Summary of Contents for Moe-Cleaner MCN-AS1020
- Page 1 Quick User Guide Model MCN-AS1020 Before using this machine, read the operator’s manual in its entirety. Failure to follow operating instructions could result in death or serious injury. Full operation manual available at www.moe-cleaner.com Step 1 Step 2 Insert Handle...
- Page 2 C) Check water pressure to Spray Nozzle by holding Spray Lever up A) Check Power is ON D) DO NOT OPERATE MOE-CLEANER if water pump is making a ‘vibrating noise’ B) Turn Cable Lock to locked position E) Clean and flush Water Filter Screen (STEP 14) to correct Water Pump noise, then...
- Page 3 Remove hair from both ends of brushes to avoid hair tangling and interfer- ing with axle bearings. Do not rinse or wash top of Moe-Cleaner, Moe Handle, or Clean Water Filter Screen weekly.
- Page 4 To remove brushes, lift and PULL this cleaning head Pin by pulling on Pin Ring. Use and insert Pin on opposite side of Cleaning Head to push the Axle out. Repeat for both brush axles. 714-265-0630 | 714-785-3284 | vinh@moe-cleaner.com | www.moe-cleaner.com...
