Electronic Devices Limited ED830 Instruction Manual

Bilge level alarm control unit
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
ZONE 1
POWER
ALARM
FAULT
TEST/
OVERRIDE
ELECTRONIC
E
DEVICES
LIMITED
BILGE LEVEL ALARM CONTROL UNIT
INSTRUCTION MANUAL
Address: Enigma House, Enigma Business Park, Malvern, Worcestershire, WR14 1GD
Tel: +44 (0)1684 891500 Fax: +44 (0)1684 891600
Email: sales@electronic-devices.co.uk Website: www.electronic-devices.co.uk
ZONE 2
POWER
ALARM
FAULT
ALARM
ALARM
ACCEPT
ACCEPT
RESET
RESET
TEST/
OVERRIDE
LEVEL DETECTOR TYPE ED830
manufactured in malvern, england
ED830
ZONE 3
ZONE 4
POWER
POWER
ALARM
ALARM
FAULT
FAULT
ALARM
ACCEPT
TEST/
RESET
TEST/
OVERRIDE
OVERRIDE
ALARM
ACCEPT
RESET

Advertisement

loading
Need help?

Need help?

Do you have a question about the ED830 and is the answer not in the manual?

Questions and answers

Summary of Contents for Electronic Devices Limited ED830

  • Page 1 RESET RESET TEST/ OVERRIDE OVERRIDE OVERRIDE OVERRIDE ELECTRONIC LEVEL DETECTOR TYPE ED830 DEVICES LIMITED manufactured in malvern, england ED830 BILGE LEVEL ALARM CONTROL UNIT INSTRUCTION MANUAL Address: Enigma House, Enigma Business Park, Malvern, Worcestershire, WR14 1GD Tel: +44 (0)1684 891500 Fax: +44 (0)1684 891600...
  • Page 2 SPECIFICATION FUNCTION DIAGRAM INSTALLATION- CONTROL PANEL CONTROL PANEL DIMENSIONS DIAGRAM INSTALLATION- FLOAT SWITCHES FLOAT SWITCH CONNECTION DIAGRAM TESTING ADJUSTMENTS (REACTION/RESET TIMING) ZONE CIRCUIT DIAGRAM FLOAT SWITCH CONNECTION DIAGRAM ED830 IM REV 3 13.03.2018 ED830 - BILGE LEVEL ALARM CONTROL UNIT...

  • Page 3: Specification

    GENERAL The ED830 is a four zone bilge level alarm control unit designed to meet the MCA code of practice. Each of the four zones are independent from each other with completely separate circuitry, switches, fuses, lamps etc. Zone wiring is fault monitored with the aid of a 4K7Ω resistor, which must be fitted at the end of the line zone wiring in the form of a end of line float switch.
  • Page 4 It requires approx 30mm-40mm of travel of the float to cause operation of the switch. 275mm (283mm required for lid clearance) M3 mounting holes 25mm from edges. LEVEL DETECTOR TYPE ED830 (335mm required for lid clearance) Cable gland entry holes. 283mm ED830 IM REV 3 13.03.2018 ED830 - BILGE LEVEL ALARM CONTROL UNIT...
  • Page 5 INSTALLATION - FLOAT SWITCHES CONNECTIONS Ensure the intended supply voltage is suitable for the ED830 supplied, both 12Vdc and 24Vdc models are available. The diagram below shows both single and multiple float switch per zone connection possibilities. Multiple float switches per zone wired in Single E.O.L float...
  • Page 6 ALARM OUTPUT FUNCTIONS The ED830 has three sets of voltage free contacts for each zone. One set for the pump, if fitted. The pump must have a current consumption of less than 6A or be driven via a suitable external relay. The second set of contacts are for a low power xenon beacon which could be fitted high on the vessel (e.g top of the mast) to attract attention whilst moored etc.
  • Page 7 CONTACTS FOR connecting SOUNDER 12VDC and (VOLT FREE) 24VDC models available CONNECT FLOAT SWITCH(ES) WITH E.O.L FLOAT SWITCH AS LAST DC INPUT ZONE ALARM CONTACTS FLOAT SWITCH ACCEPTABLE ED830 IM REV 3 13.03.2018 ED830 - BILGE LEVEL ALARM CONTROL UNIT...
