WATER THERMOSTAT - TYPE SU 6.2.
USER'S GUIDE
Manufacturer and service: 1 -CUBE
s.r.o.
Hamry 3567, 580 01 Havl.Brod
tel. 569 433 620
fax 569 422 144
C
ONTENT
1. Range of the supply ........................................................................................................................................................ 2
2. Installation instructions .................................................................................................................................................. 2
3. Safety recommendations ................................................................................................................................................ 3
4. Technical data ................................................................................................................................................................. 4
5. User's guide ................................................................................................................................................................... 5
6. Monitoring RS232 ......................................................................................................................................................... 13
7. Maintenance ................................................................................................................................................................. 13
8. Important warnings ...................................................................................................................................................... 13
1
Advertisement
Summary of Contents for 1-CUBE SU 6.2.
-
Page 1: Table Of Contents
1-CUBE s. r. o. Hamry 3567, 580 01 Havl. Brod, Czech Rep. tel + 420 569 433620, fax + 420 569 422144 e-mail: 1-cube@1-cube.com, web site: www.1-cube.com WATER THERMOSTAT - TYPE SU 6.2. USER’S GUIDE Manufacturer and service: 1 -CUBE s.r.o. -
Page 2: Range Of The Supply
1. R ANGE OF THE SUPPLY Water thermostat type SU6.2- hot bath ......1 pc Water thermostat type SU6.2- cold bath ......1 pc Bottle holder for 6 bottles ..........2 pcs 2. I NSTALLATION INSTRUCTIONS The Water Bath is determined only for work in laboratories which is the ordinary laboratory place. The Bath must be located in the horizontal position (for proper operation of the apparatus). -
Page 3: Safety Recommendations
Cold Bath SU6.2. connection: 3. S AFETY RECOMMENDATIONS Water Bath may be operated only by person who became completely acquainted with its function within the framework of the training, or who became thoroughly acquainted with the user’s guide of this device. The Water Bath must be plugged in with the help of a standardized plug into single-phase el.socket with circuit breaker. -
Page 4: Technical Data
4. T ECHNICAL DATA Electric data: - voltage system TN-S 1+PE+N - voltage 230V/50 Hz or 110V/60 Hz - protection IP 20 - the equipment can be used in neutral medium - the equipment output : hot bath 1500W, cold bath 1800W - circuit breaker–10A fusible cut out - plugging in el. -
Page 5: Users Guide
5. U ’ S GUIDE Picture of the cooling bath - SU6.2: Control panel Mixer engine Removable top Cooling thermostat Cooling on-off switch Cooling exchanger Air inlet First switch on the Main Switch located on the front panel of the equipment. NOTICE: It is forbidden to use the device without filling it with water. - Page 6 The bottles can be put in only into the bottle holder which makes part of the supply. If you put them inside without the bottle holder the bottles may move in the bath and the stirrer can be damaged. The stirrer is controlled with the help of the switch „Stirrer“. We reccommend to leave the stirrer always switched on (in the position I) in this way the stirrer will be controlled (switch on/switch off) with "Main switch".
- Page 7 Connector RS232 After switching on the equipment there is 1-CUBE name and the version of the control programme appears on the display, they disappear after a while and the the text THERMOSTAT appears on the display. Once you finish working switch off the device with the help of the Main switch.
- Page 8 Adjustment of the required temperature or time: The required temperature or time in the methods (menu) THERMOSTAT, CALIBRATION and PROFILE are adjusted by pressing keys plus + (to increase the value) or minus – (to decrease the value). First the required value is changed of tenths of degree or 1 seconds, after ten changes (ten presses of key) the required value is changed of degrees or 10 seconds, after ten following changes (ten presses of key) the required value is changed of 10 degrees or 100 seconds etc.
- Page 9 same way the temperature of point 2, the temperature of point 3, the temperature of point 4, the temperature of point 5, the temperature of point 6, the temperature of point 7 and by pressing the key OFF the control of the adjusted curve starts running.
- Page 10 Calibration of the lower temperature 5 degrees Celsius (point 1) : First check if the temperature in bath is about 5 degrees Celsius and if it is not use the method Thermostat to reach it. Once temperature of 5 degrees Celsius is reached use the following procedure: 1) Press the keys OFF and ENTER at the same time 2) There is text „dig value of tem“...
- Page 11 Calibration of the upper temperature 70 degrees Celsius (point 2) : First check if the temperature in bath is about 70 degrees Celsius and if it is not use the method Thermostat to reach it. Once temperature of 70 degrees Celsius is reached use the following procedure: 1) Press the keys OFF and ENTER at the same time 2) There is text „dig value of tem“...
- Page 12 Hysteresis adjustment to achieve the most accurate regulation Very complicated regulation algorithm is used to achieve the required temperature. 3 hysteresis ranges are used and the heating output is regulated according to them, in addition its amplitude is changed linearly in dependence on temperature and on cooling compressor closing.
-
Page 13: Monitoring Rs232
The fuses are located on the back panel of the Water Bath. It is forbidden to replace the fuse by fuse with different value than the value indicated on the equipment. Service: For service contact the manufacturer: 1-CUBE, Hamry 3567, 580 01 Havl.Brod, Czech Rep. tel. 00 420- 569 433 620 fax .00 420-569 422 144 1-cube@1-cube.com NOTICE: It is forbidden for anyone except for the manufacturer or authorized company to repair the apparatus.
