Insert Plate Size
CONTENTS
3/4" x 4 1/4" (19mm x 108mm) lock with
3 pairs of metal inserts
1" x 6" plate (25mm x 152mm)
1 nesting plate
5/8" x 7/8" (16mm x 22mm) lock with 1"
x 2 1/4" plate (25mm x 57mm)
3" x 3/4" (76mm x 19mm) lock with 1" x
4 3/4" plate (25mm x 120mm)
Inserts
Other equipment required not supplied:
•
Light Weight Electric Router capable of plunging the depth of the
required lock.
•
16mm Special Guide Bush
•
12.7mm Router Bit
NOTE: Before commencing with any operation, check that the cutter you
are using will fit centrally inside your 16mm guide bush and that there is
sufficient clearance for the cutter to rotate freely.
Page 4
Lock
5 Lever Sash Lock
Mortise Latch
5 Lever Dead Lock
Nesting Plate
LOCK JIG
INSTRUCTION LEAFLET
Advertisement
Summary of Contents for Worktop Express Lock Jig
- Page 1 CONTENTS 3/4" x 4 1/4" (19mm x 108mm) lock with 5 Lever Sash Lock 3 pairs of metal inserts LOCK JIG 1" x 6" plate (25mm x 152mm) 1 nesting plate 5/8" x 7/8" (16mm x 22mm) lock with 1"...
- Page 2 1) The nesting plate has a centre line scribed on it, which The lock jig is a self-centring template used for routing out the edges of doors to ac- relates to the centre line of the final position of the lock.
