SODEX S18152GCW Assembly Instructions Manual

DETAILS
SODEX INTERNATIONAL
18 rue de l'avenir – Bât. 224
14650 CARPIQUET
Phone: + 33 (0) 2.31.53.78.70
Email: karine.chaigneau@sodexinternational.com
DESCRIPTION
Structure in steel 80x80
White powder coated
3,05 m - 2,60 m
CONFORM
European norm
According to the decree above, for the first installation the goal must be tested like below :
Put a vertical and static charge of 320 kg, at the jonction of the pannel and the basket , at 0.20m of the ground,
during one minute.
During the first installation, this stability and solidity test is compulsory.
Every time that the equipment is assembled, a visual check of the stability and solidity must be realized.
The owner must regularly check the condition of the product.
The equipment has to be regularly maintained by the owner. It is advised to:
- Check every week that all the screws are correctly tightened
- Fix paint defects if the module has been damaged, using the adapted paint, specified by the manufacturer.
- Replace all damaged or missing parts with a spare part recommended by the manufacturer.
- Clean the product by using dishwasher soap, clean water, and soft cloth.
It is advised to carry out this cleaning once or twice a year, or even more regularly according to the environmental
conditions (saline environment, ...)
One full year parts and labor guarantee. Every claim regarding the condition of the delivered equipment has to be
done within the legal period,of the reception of the material.
The warranty will not apply to:
- All degradation during the transport.
- All degradation due to poor maintenance.
- All degradation due to use differing from which was intended
- Any defect claimed after the end of the legal period.
- Any damage due to a faulty installation or assembly of the module.
PRODUCT REF
TEST AFTER INSTALLATION
MAINTENANCE
WARRANTY
ASSEMBLY INSTRUCTIONS
MULTI-FUNCTION GOAL
3.05m - 2.60m
S18152GCW
:
UNIT
