Summary of Contents for Aquapeutics WG-U6811
- Page 1 Aquapeutics Aquapeutics STEAM ROOM Installation Manual WG-U6811 Make the most of your shower;make the best for your home!
-
Page 2: Safety Notice
Safety notice 1. The electrical installation should be performed by a qualified technician or professional. 2. The power supply should match the electric parameter of the product, certified GFCI Circuit . distance among outlets ≧3mm. 3. Cutting any wire on this product is strictly prohibited in the process of handling installation. -
Page 3: Technical Parameter
Technical parameter Product Features - Standard Configuration Function and device WG-U6811 Electric Parameter： Electrical Steam Pump Blower Rated Power Rated current generator Model Size(mm) source voltage (Hz) WG-U6811 1620X1620X2230 220-240 4500 The information of this table are only reference, the company have right to amend the technique parameter、specification 、model、collocate before any advance... - Page 4 Plumbing & Electrical Power Use Advice: The main Power Supply Switch(With the Creepage Protection Switch ) should be mounted about 1000 mm away from the steam room during installation in the site so that the power can be cut off after each use to ensure safety and the service life of computer control system of the product.
- Page 5 Exploded pictures OZONE STERILIZATION ROOF HEAD SHOWER WITH LIGHT RIGHT BACKBOARD MIDDLE BACKBOARD MIRROR LED LIGHT LEFT BACKBOARD LOUDSPEAKER SETS SHOWER SLIDING BAR WITH HAND HELD SHOWER*2 HANDRAILS FOR STORAGE RACK TEMPERATURE DETECTOR S198 SYSTEM ACUPUNCTURE MASSAGE JETS*12 FAUCETS FOOT MASSAGE MEDICINE BOX WATER NOZZLE AIR PUMP SWITCH...
-
Page 6: Installation Steps
Installation Steps Install bathtub Open the packing put the tray to the appropriate place. Use the level ruler test all direction is balance. Adjust the screw which in foot to the tub until level, and then screw down the nut. The feet must adhere to the ground. - Page 7 Installation Steps M4*16(4) M4*25(8) The big single side seal The small single side seal...
- Page 8 Installation Steps M6*25Screw*4 M6*25Screw*4...
- Page 9 Installation Steps M6*25Screw*11 M4*16(5) shower fitting install the wheels foot massage steam box F Spare install the wheels...
- Page 10 Installation Steps Connect top shower Connect back jets Connect handheld shower Connect waterfall foot massage Connect Cold water Hot water Steam generator water in Steam Generator Water out Drainer Hose diagram Note: all pipe there must be gasket...
- Page 11 Operation Instruction Of Steam Room Top shower Back jets H andheld shower Foot massage Waterfall Handheld shower Handheld shower Left ON/ OFF Right ON/ OFF cold C° POWER POWER ON/OFF ON/OFF WATER PUMP SWITCH AIR PUMP SWITCH AIR-CONDITIONING SWITCH...
- Page 12 Operation instruction of S198E system 14 14 -----Next song -----LCD screen -----Power switch -----Last song ----- Shuttle switch -----Volume control...
- Page 13 Operation instruction of S198E system 14 14 -----2 modes of shortcut key -----Radio frequency indication -----Overhead spray -----Steam -----Keyboard lock -----Steam temperature setting -----Steaming time setting -----Upper spray -----Spray -----Middle spray 14 14 -----Lighting -----Lower spray -----Fan -----Cleaning -----Telephone answer -----FM -----Sterilization -----Channel search...
- Page 14 Operation instruction of S198E system 14 14 -----Lighting function key -----Channel storage function key (Optional ) -----Side spray function key -----Setting function key -----Steam function key -----Switch function key -----Fan function key -----Bluetooth function key -----Ozone function key -----Turning/song switch function key 14 14 -----Overhead spray function key -----Tune rising function key...
- Page 15 Operation instruction of S198E system 1. Notes： (1)this panel is equipped with capacitive touch buttons,make sure to advod direct Contact with shower head while selecting installation loaction of the panel.Otherwise it would lead to maloperation or trigger the panel lock (2)all function keys are located at the most conveniet locations。...
- Page 16 Operation instruction of S198E system Instruction for use After stratup the default location of cursor would be .Rotate the shuttle switch to move the cursor.After the cursor moves to a function,press the shuttle switch or the function keys on the remote control to quickly turn on and turn off the function.The icons would light up after functions are turned on and vanish after functions are turned off.
- Page 17 Operation instruction of S198E system then momently press once again to enter duration setting mode. As the icon flashes, rotate the shuttle switch to adjust the time or press on the remote control to increase the time or to decrease the time. Timing range: 5 ~ 50min. ⑤.
- Page 18 Operation instruction of S198E system on the remote control to turn on or turn off the exhaust fan. Icon would light up after startup. 4. Move the cursor to and press the shuttle switch or momently press on the remote control to turn on or turn off the lights. Icon would light up after startup.
- Page 19 Operation instruction of S198E system channel search mode and press on the remote control for one second, which would start automatic upward, downward search until a valid station is obtained.After unlocking the panel and exiting from function settings, touch . The cursor would automatically return to and start the automatic upward, downward search until a valid station is obtained ②...
- Page 20 Operation instruction of S198E system switch to the next song, momently press on the panel to switch to the previous song. When using remote control to switch songs, you first need to press on the remote control to song switch mode, then press to switch to the next song and for the previous song.
- Page 21 Operation instruction of S198E system momently press on the remote control to enter the mode of steam temperature setting, press again to enter the mode of steaming duration setting, then press again to enter volume adjustment mode. The fourth press would return to the steam temperature setting.
-
Page 22: Fault Code
Operation instruction of S198E system （ ） 4 Fault code ： Display on Cause Fault Name Description nixie tube A. General water valve is After the steam function is turned on, the system will open not open; water inlet after it detects shortage of water. If the system B. - Page 23 Aquapeutics Aquapeutics...
