- Page 1 Technical Manual of BR-15 Banknote Recycling Module...
-
Page 2: Document Record
Document Record Creation/ Item Version Date Participants Modification Technical Manual Jiangliang Hu of BR-15 Banknote V1.0 2014-05 Creation Zhiyuan Zhou Recycling Module... -
Page 3: Table Of Contents
BR-15 Technical Manual Content DOCUMENT RECORD....................I GENERAL DESCRIPTION................1 MODEL AND TERMS..................1 OVERVIEW......................1 ...........................1 OMPOSITION .............................2 IMENSIONS FEATURES......................2 MODULE FEATURES..................3 .............................3 PPER .......................... 3 EPOSIT ASSETTE ......................3 EPLENISHMENT ASSETTE ........................4 ECYCLING TECHNICAL PARAMETERS................4 ........................ 5 ECHNICAL ARAMETERS ...................... -
Page 4: General Description
The module features high reliability, accessibility and maintainability in reducing cash exposure, calculating cost allowance and settling accounts. BR-15 is mainly applied in small amount cash transaction service industries, such as the AFC system in mass transit industry, Kiosk with deposit and cash recycling functions in banking industry, self-service equipment in parking lot and self-service payment system in retailing industry. -
Page 5: Dimensions
BR-15 Technical Manual Dimensions 275(L)×162(W)×634.5(H) (Unit: mm) 4. Features n Single banknote acceptance, fast banknote deposit and cash recycling; n It is based on proven note validation and forgery-proof technology; n Compact banknote acceptance structure and banknote validation system; n Banknote recycling in 4 denominations provides more flexible and optimal change giving method;... -
Page 6: Module Features
BR-15 Technical Manual 5. Module Features Upper Part n Its entrance indicator facilitates patrons to use; n Banknotes giving to the patron are up to 20 notes in one transaction with the banknotes of small denomination put on the top;... -
Page 7: Recycling Drum Set
BR-15 Technical Manual reliability; n Automatic loading banknote to the recycling drums ensures less manipulation and corruption in the process of banknote replenishment. n Banknote replenishment in different denominations by loading the cassette with mixed denominations. Recycling Drum Set n Recycling of up to 260 banknotes in 4 denominations;... -
Page 8: Technical Parameters
Inspection method No inspection Data bit: 8bits Communication parameter Starting bit: 1bit Ending bit: 1bit Pin3 —— PC-RXD(BR-15 to upper stream) Pin2 —— PC-TXD( upper stream to BR-15) Pin description Pin1/Pin4 —— PC-GND(signal earth) RAMS Specifications (Working environment: 20℃, 50%RH) - Page 9 BR-15 Technical Manual Item Specifications Remarks Note jam rate Less than 3/100000 70% new or above notes Mean Time Work in standard environment under working Between Failures 300,000 times standard (MCBF) Work in standard environment under working Service Life 10 years...
