URL http:// www.digipressure .com
E-Mail :sales@digipressure.com
Address: 414. KoFoMotechno center 1289-5.Jeongwang-dong ,Siheung, Kyeonggi-Do Korea 429-450
DIGIPRESSURE
DPC_ HL-DIF
DISPLAY
TYPE
ACCURACY
BURST PRESSURE
TEMPERATURE
HUMIDITY
APPLICATION GAS
SENSOR MATERIAL
PROCESS
PRESSURE RANGE
CONTROL OUTPUT
POWER SUPPLY
ACCESSORY
WEIGHT
CASEMATERIALS
INTERFACE
SETTING MANUAL
3DIGIT FND * 2 HP/LP
HL TYPE (OPTION : HL-DIF, L YTPE)
±1%F.S
100Kgf/cm2g
-20 ~ 60 ℃
0 ~ 80% R.H
Air, Inert gas, Water, Oil, Others
Ceramic Diaphragm
7/16 - 20UNF
HP -1.0 ~ 50Kgf/cm2g, LP -1.0 ~ 50Kgf/cm2g
3Point Relay Output(CONTACT: 250V/3A SPDT)
AC220V±10%50/60Hz0.2A(Option:380V.110V)
Mounting Bracket
Approximately 510g
ABS
RS-485
Connection with Power 220V
Connection with Power 220V
Low Pressure S/W : COM ,NC, NO
Low Pressure S/W : COM ,NC, NO
High Pressure S/W : COM, NC ,NO
High Pressure S/W : COM, NC ,NO
differential
pressure S/W :
pressure S/W :
COM ,NC.NO
COM ,NC.NO
TEL : 82-31-432-8843
FAX : 82-31-601-8600
Advertisement
Table of Contents
Summary of Contents for Digipressure DPC_ HL-DIF Series
- Page 1 High Pressure S/W : COM, NC ,NO High Pressure S/W : COM, NC ,NO differential pressure S/W : pressure S/W : COM ,NC.NO COM ,NC.NO URL http:// www.digipressure .com TEL : 82-31-432-8843 FAX : 82-31-601-8600 E-Mail :sales@digipressure.com Address: 414. KoFoMotechno center 1289-5.Jeongwang-dong ,Siheung, Kyeonggi-Do Korea 429-450...
- Page 2 Press buttons for 3seconds at the same time SET L SET L for correcting value of pressure to 설 정 설 정 ZERO“Never use while operating” URL http:// www.digipressure.com TEL : 82-31-432-8843 FAX : 82-31-601-8600 E-Mail :sales@digipressure .com Address: 414. KoFoMotechno center 1289-5.Jeongwang-dong, Siheung, Kyeonggi-Do Korea 429-450...
