Lassco Wizer Cornerounder CR-50B User Manual

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

CR-50B Cornerounder
Before operating this equipment, please read these
instructions completely and keep these operating
instructions for future reference.
485 Hague Street, Rochester, NY 14606 U.S.A.
Tel: 585-436-1934
www.lasscowizer.com
Date of Purchase:
Dealer:
Address:
Telephone Number:
Fax: 585-464-8665
info@lasscowizer.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cornerounder CR-50B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lassco Wizer Cornerounder CR-50B

  • Page 1 CR-50B Cornerounder Date of Purchase: Dealer: Address: Before operating this equipment, please read these instructions completely and keep these operating Telephone Number: instructions for future reference. 485 Hague Street, Rochester, NY 14606 U.S.A. Tel: 585-436-1934 Fax: 585-464-8665 www.lasscowizer.com info@lasscowizer.com...

  • Page 2: Operating Instructions

    Operating Instructions Cutting Unit Installation (Special & Standard Sizes) Push down and pull back on the two Thumb Screw Knobs (50B-12) on both sides of the Handle (50B-05) Until the Pivot Bracket (50B-07) is engaged in the last Slot #3 of the Handle.
  • Page 3 Cutting Unit Installation (Large Sizes) Push down and pull back on the two Thumb Screw Knobs (50B-12) on both sides of the Handle (50B-05) Until the Pivot Bracket (50B-07) is engaged in Slot #2 of the Handle. Raise the Handle to the maximum position. Make sure the Adapter Plate has been removed.
  • Page 4 Corner Rounding Operation Place the product you are cutting onto the Wooden Top Plate and push it into the corner aligning it with the Side guide the the back edge of the Cutting Unit. Press down firmly to prevent the product from sliding out of the corner. Depress the Handle with an even consistent pressure until the knives cut through the product.
  • Page 5 Parts Diagram 6-32 x 3/4” Pan Head Slotted Machine Screws Adapter Plate (50-26) Paper Guide (50-03R) Adapter Plate Rotation Tab (50-12) Handle (50B-05) Pivot Bracket (50B-07) 10-32 x 3/8” Socket Head Machine Screws Thumb Screw Knob (50B-12) Black Knob (FM4-4007) Adapter Hold Down Tab (50-11) Shoulder Screws (20-24) Hinge Bracket (50B-08)
