- Page 1 MANUAL MADE IN JUNE 2019 GERMANY...
-
Page 2: Table Of Contents
The SCROOSER electric scooter is manufactured by SCROOSER GmbH. FOREWORD This user manual is produced by SCROOSER GmbH. We reserve the right to make changes to the design and features of the SCROOSER in the interest of technical optimisation. SCROOSER-PASS The contents of this user manual are correct to the best of our knowledge at the time of finalizing this document. - Page 3 SCROOSER GmbH All rights reserved. 3 STRUCTURE OF THE SCROOSER 11 BATTERY Overview of components Charging the battery Display Removing the battery Charging the battery 4 GETTING STARTED Putting the battery back in Unpacking your SCROOSER Reactivating the battery from sleep mode...
-
Page 4: Foreword
When vehicles are stolen, they are often recovered by the police. The SCROOSER pass allows your SCROOSER to be uniquely identified, making it more likely you will get it back. The You have opted for outstanding quality – a quality that results from the carefully selected SCROOSER pass is also helpful when reporting the theft to your insurance company. -
Page 5: General Information
- If a guarantee service is used, this does not result in an extension or a new start of the guaran- tee period. - If a component of the same type, size or color is no longer available, SCROOSER is entitled to use a part that can be considered as a successor to settle the guarantee claim. -
Page 6: Safety
Safety notices are categorised as follows: Danger You must carefully read through the user manual before using the SCROOSER for the first time. Pay particular attention to the safety instructions. This will help you to familiarise yourself with your SCROOSER more quickly and to avoid operating errors that could result in accidents or This combination of symbol and signal word indicates a situation that presents an immediate damage. -
Page 7: General Safety Notices
General safety notices Always ride your SCROOSER with care and at a speed where you are able to control it. It is not suitable for racing and jumps. Be cautious and anticipate what is ahead. Be mindful Only individuals who fulfil the necessary requirements are allowed to ride the SCROOSER. -
Page 8: Risks When Parking
On a level surface, the SCROOSER’s broad tires automatically keep it balanced. However, the SCROOSER can fall over as a result of strong winds or carelessness or when parked on Make sure the charger is adequately ventilated when in use. -
Page 9: Intended Use
All rights reserved. Intended use The SCROOSER is intended to be used by a person sitting on the saddle with a maximum load of 110 kg on roads. Please ensure that you have purchased a street-legal version, which will be supplied with an individual vehicle approval. -
Page 10: Structure Of The Scrooser
SCROOSER GmbH Alle Rechte vorbehalten. 3 STRUCTURE OF THE SCROOSER Overview of components throttle grip rear-view mirror bell handlebars handlebar clamp display headlight front brake lever vertical footboard with storage compartment Saddle front mudguard tail and brake light, number type plate / VIN lable... -
Page 11: Getting Started
2. Take off the lid of the packaging and remove the cardboard stiffeners from the handlebars and seat. 3. Remove the outer packaging. 4. Lift the SCROOSER from the wheel recesses in the packaging, starting at the back (to the ECO (E) COMFORT (C) left) and then at the front. -
Page 12: Mounting And Adjusting The Rear-View Mirror
SCROOSER GmbH All rights reserved. Mounting and adjusting the rear-view mirror Adjusting the handlebars For security reasons the rear-view mirror is demounted during transport and enclosed. How to adjust the handlebars: How to mount and adjust the rear-view mirror: Loosen the four screws on the handlebar clamp and adjust the handlebars as required. -
Page 13: Start
The headlight and tail light will flash, the battery charge display LEDs on the display will light up and riding mode H for HAND will be displayed. Your SCROOSER is now ready to go. Your SCROOSER comes with an ignition key known as a TAG. -
Page 14: Controls
The SCROOSER has a trip counter and an odometer. After turning the SCROOSER on, the trip counter can be opened by a short press of the ON/OFF button. After a few seconds or when you activate the throttle grip/impulse drive, the display will disappear. -
Page 15: Riding
5% from a standing start without pushing with your foot, the overload protection Riding modes may turn off the motor. If that happens, you need to restart the SCROOSER in the usual way. During prolonged ascents, the control unit may become very warm. If that happens, the power The SCROOSER has four riding modes (figure 8): HAND, SPORT, COMFORT, ECO. -
Page 16: Parking
In low temperatures, especially when there is frost, store your battery in your home or office 8 PARKING and only put it back in your SCROOSER just before you set off. When possible, do not park your SCROOSER in direct sunlight. -
Page 17: Transporting
Turn off the SCROOSER prior to transport. The handlebars can be folded down during transport. attempts to move the SCROOSER while it is in this state, the headlight and tail light will flash for To do so, loosen the four screws on the handlebar clamp. Then fold the handlebars down. For one minute, and the back wheel will remain locked until you use your TAG. -
Page 18: Battery
The SCROOSER has a lithium-ion battery. After 500 charging cycles, it will still have a capacity of 70-80 percent. At an average level of use, this is equivalent to a service life of five years. After that, In comparison with other types of battery, lithium-ion batteries have very low self-discharge. -
Page 19: Charging The Battery
If you use a different charger from the one supplied, this can break the battery. You can now charge the battery in an ordinary household plug socket (220/230 V) using the charger Only use the charger supplied with the SCROOSER. supplied with the SCROOSER. -
Page 20: Putting The Battery Back In
When the battery is fully charged, the LED will change colour from red to green. The battery If you do not use the SCROOSER for a prolonged period of time, the battery will go into sleep mode. will automatically stop charging once it is full (green LED). It takes approx. three to five hours to The SCROOSER will not start while the battery is in this mode. -
Page 21: Storing The Battery
All rights reserved. 12 CARE / MAINTENANCE If you use your SCROOSER as intended, it will have a very long service life and many of the components will require little or no maintenance. Please follow the following care and maintenance instructions in order to maintain optimum functionality. -
Page 22: Brake Pads And Discs
Please note that the parts listed in the following sections (brake pads, tires, etc.) need to be replaced If the SCROOSER is not going to be used for a prolonged period, in order to protect the tires it is if they exceed their wear limit. -
Page 23: Technical Specifications
SCROOSER GmbH All rights reserved. 13 TECHNICAL SPECIFICATIONS Feature Value Feature Value Dimensions L x W x H 1,760 mm x 805 mm x 1,090 mm Front rim Steel, 7.00 x 8 4/60/100 ET0 With mirror 1,760 mm x 805 mm x 1,340 mm Internal tire pressure 0.9 bar (recommended) -
Page 24: Service Partners
High-quality German engineering, carefully selected components and the use of cutting-edge technologies in the frame and throughout the rest of the scooter – these things should hopefully ensure your SCROOSER has a long service life with plenty of carefree scroosing. But on rare occasions, problems can occur even with SCROOSERs. - Page 25 SCROOSER.COM Designed, Engineered & Made in Germany. contact@scrooser.com...
