INSTRUCTION MANUAL
EVAPORATIVE AIR COOLER
Contents
Model：ARICOOL1H
I. Functions....................................2
II. Main Technical
Parameters.....................................4
III. Electrical Schematic
Diagram.........................................5
IV. Security Rules ..........................6
Maintenance..............7
packs.....................9
VII.Troubleshooting
guide...............10
Advertisement
Table of Contents
Related Manuals for Ariklima ARICOOL1H
Summary of Contents for Ariklima ARICOOL1H
- Page 1 INSTRUCTION MANUAL EVAPORATIVE AIR COOLER Contents Model：ARICOOL1H I. Functions……………………....2 II. Main Technical Parameters………….…………....4 III. Electrical Schematic Diagram…………..………….....5 IV. Security Rules ……..……………...6 V. Cleaning and Maintenance……..7 VI. Usage of Ice packs………..……..9 VII.Troubleshooting guide….………..10...
- Page 2 Timing: in the working state, if the button is pressed, the timing I. Functions off-time can be available; if pressed repeatedly, circular off-time can Note: the instruction describes all the functions. The users can choose be set. The off-time is, in order, 0.5hour→1hours→1.5hours→…… them according to the actual product function.
- Page 3 II. Main Technical Parameters III. Electrical Schematic Diagram Model ARICOOL1H Rated voltage 220-240V Rated frequency 50Hz M4.motor M3.motor Rated power 70W/2000W M2.pump Capacity capacitor Wind speed 6.4--7.8 m/s Evaporation capacity 900mL/h Energy efficiency 9.0W/W ≤65db Noise Type Cooling and heating 1.
- Page 4 IV. Security Rules V. Cleaning and Maintenance 1. Part-time workers and unauthorized repairmen are forbidden to repair or revise the unit’s components as it will void the warranty. 2. Do not operate with wet hands to avoid electric shock. 3. If power lines are aging and knotted or the plug is damaged, they should be repaired by the authorized service center immediately.
- Page 5 3. Cleaning the water tank Cut off the power supply; take the air filter screen down, and then VI. Usage of Ice packs remove the water tank. Remove the dirt in the tank by using a wet The ice pack has a special property of making the water cooler and towel with a mild detergent, After that, wash and rinse it with clean can absorb the heat from water to keep the water temperature below water, wipe it with a dry piece of cloth,...
- Page 6 VII. Troubleshooting guide Malfunction Possible reasons Solutions 1. No power or poor 1. Turn power on No LED contact. display 2. Damaged screen. 2. Replace the screen. 3. Burnt/blown fuse. 3. Replace blown fuse. 4. Circuit board error. 4. Replace the circuit board 1.
