Summary of Contents for Justus Mino I
- Page 1 Operating and Installation Instructions for Wood Burning Stoves JUSTUS Mino I 293 2925 000 · 1089...
-
Page 2: Table Of Contents
Table of Contents JUSTUS factory guarantee Welcome Description Energy Label and Product Data Sheet according to EU regulation General Declaration of performance External combustion air supply CE mark Design Appliance parameters* Rear cover Flue tube connection and setup of the wood burning stove... -
Page 3: Welcome
Dear Customer, JUSTUS GmbH Oranier Strasse 1 JUSTUS wood burning stoves offer you sophisti- 35708 Haiger cated and reliable technology, functionality and an Germany attractive design. Telefon: +49 (0) 27 71 / 2630-0 If, despite our careful quality checks, you find... - Page 4 This fireplace must not be altered in any way! The purchaser and operator of this wood burning stove is obliged to learn how to handle it correctly by reading these instructions. Our guarantee of fault-free function shall immediately be rendered void if the following guidelines and instructions are not complied with. Thank you for your understanding. Please note: Before setting up and operating this appliance, check for any transport damage to the functional parts (air slide, lining, seals, firebox door, pipe supports, etc.).
-
Page 5: Description
1. Description Fig. 1 Upper flue tube opening The wood burning stove is made of a welded steel construction. The central section fea- tures the firebox, which is lined with safety panels. The ash box is located below a sturdy Rear flue cast iron trivet. -
Page 6: Design
2.2 Design 3. Flue tube connection and setup of the wood burning stove The wood burning stove series described in these instructions are of "Design 1". 3.1 Connection of the flue tube Wood burning stoves of this design have self-closing firebox doors powered by a spring Your wood burning stove can optionally be mechanism and are approved exclusively for connected upwards or to the rear. -
Page 7: Setup Of The Wood Burning Stove
3.2 Setup of the wood burning stove servicing purposes. A Site survey should al- ways be carried out to ensure the suitability of Fire safety regulations according to Feu- the surrounding surfaces as certain materials Vo (minimum distances; see Fig. 2) must be such as tile and marble may need additional complied with when setting up the appliance. -
Page 8: Technical Data
4. Technical data Exhaust mass flow: 4.8 g/s Wood burning stove type: Mino I Design: Feed pressure for NHO: 12.0 Pa Nominal heat output: 5.0 kW Exhaust temperature at outlet: 273 °C Heat output range: 3.0 - 5.4 kW Approved fuels: - Firewood <... -
Page 9: Operating The Wood Burning Stove
5. Operating the wood burning stove Caution! The burning of fuel releases heat energy, which General leads to the significant safety instructions heating of surfaces, firebox doors, To ensure the safe operation of your wood operating handles, viewing panes and burning stove, it is essential to follow the flues. Touching these components with- safety instructions below: out suitable safety or auxiliary equipment The wood burning stove may only be oper- (use fireproof gloves!) is forbidden while ated in accordance with these operating in- the stove is heating. -
Page 10: Suitable Fuels
Suitable fuels Commissioning The wood burning stove is suitable for burn- - Open the primary and secondary air controls ing untreated firewood, wood briquettes and as far as they will go! Ensure that any throttle lignite briquettes. cap installed in the connecting piece is also Classic stove woods include beech and birch. -
Page 11: Heating With Lignite Briquettes
Heating with lignite briquettes Feed quantities and air adjustment with nominal heat output (NHO) - First create a base pile of embers with wood. For wood / wood briquette fuel: - Then place 2 lignite briquettes cross-ways in the firebox. Leave a little space between the Fuel quantity: 2 logs / piece briquettes. -
Page 12: Cleaning And Maintenance
Cleaning and maintenance Caution! The wood burning stove must only be cleaned when it has fully cooled! At least once a year, and more often if required, the soot and ash deposits in the flue tube and firebox, as well as the flue gas routes, should be removed. -
Page 13: Chimney Fire
Note: The paint coating on the stove only achieves its final stability after sever- al cycles of heating to the nominal heat output (NHO). avoid damaging paint, surface cleaning is recommended only after multiple heating cycles. 5.10 Chimney fire If an unsuitable fuel or a fuel that is too wet is used, deposits in the chimney can ignite, causing a chimney fire. -
Page 14: Use In Smoke Control Areas
7. Use in Smoke Control Areas The original DEFRA Stop consists of 2x an- gled stoppers (A) and 2x M6 hex nuts (B). 7.1 The Clean Air Act 1993 and Smoke Control Areas To mount the stoppers your stove is already fitted with 2x threaded bolts (C), located be- Under the Clean Air Act local authorities may hind the air controls. -
Page 15: Suitable Fuels
7.3 Suitable fuels This appliance has been recommended as suitable for use in smoke control areas when burning wood logs with moisture 15-20%. The lenght oft he wood logs must be between 20 and 30 cm. The width shall not exceed 7 cm. 7.4 Refuelling on to a low firebed If there is insufficient burning material in the firebed to light a new fuel charge, excessive... -
Page 16: Justus Factory Guarantee
Further claims are excluded. and local requirements of the responsible JUSTUS is not liable for any direct or indirect damages authorities, gas and electricity supply companies. caused by the use of non-original spare parts. -
Page 17: Energy Label And Product Data Sheet According To Eu Regulation
Energy Label and Product Data Sheet according to EU regulations Mino I Produktdatenblatt gemäß (EU) 2015/1186 Anhang IV Product data sheet in accordance to (EU) 2015/1186 Annex IV/ Label énergétique et fiche produit selon les normes (EU) 2015/1186 Annexe IV... -
Page 18: Declaration Of Performance
Declaration of Performance... -
Page 19: Ce Mark
CE-Kennzeichnung CE marking Der Hersteller JUSTUS GmbH The manufacturer Werk 10 Oranier Straße 1 35708 Haiger erklärt in alleiniger Verantwortung, dass das Produkt „Raumheizer für feste Brennstoffe“ mit der Handelsbezeichnung declares under our responsibility that the product “room heater by solid fuel“ with trade name... - Page 20 In the event of a service call-out, please only quote the model number of your stove. It is worth noting down the version of your new wood burning stove now in the circular field provided in the table below. Model Mino I Serial 4810 55 A06 Production No. Inspection stamp, date: JUSTUS GmbH · Oranier Strasse 1 · 35708 Haiger · Germany...
