- Page 1 OceanGuard Installation Guide...
- Page 2 Ocean Protect | OceanGuard Installation Guide Rev: 1 Last Updated: March 2019 Introduction The purpose of this manual is to indicate the safest and most efficient method in installing the Ocean Protect OceanGuard. Equipment The following personal protective equipment is required by staff for installation activities: ...
- Page 3 | OceanGuard Installation Guide Configurations The OceanGuard can fit a range of pits typically found in Australia including, kerb entry, rear entry with grated drain entry as well as field gully pits. There are multiple sizes to suit pits ranging in plan dimensions of 450 x 450mm – 1200 x 1200mm. Additional custom sizes are available to suit circular and non-standard pits.
- Page 4 Ocean Protect | OceanGuard Installation Guide Installation Procedure The aim of all pit insert installations is to install the largest unit into each pit, without influencing the hydraulic performance of the pit or drainage system. Strut Install 1. Measure the internal dimensions of the pit while marking the center of the pit length, at 150mm down from entry of pit (the height where the struts are to be secured).
- Page 5 3. Drill a 5mm hole through the flow diverter and into the strut for each T-strut, and secure the flow diverter to the T-strut with a pop rivet. NOTE: if you OceanGuard requires a Filtration Cage this step can be skipped and addressed as part of the Filtration Cage Installation.
- Page 6 Ocean Protect | OceanGuard Installation Guide Filtration Cage Install (if required) 1. Lower the filtration cage through the flow diverter until the lip of the cage sits on the internal lip 2. Drill a 5mm hole through the flow diverter, filtration cage lip and into the strut for each T-strut, and secure the flow diverter to the T-strut with a pop rivet.
