Gehring Group Adventurer Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WELCOME!
Thank you for choosing our electric bike!
This manual shows how to use the bicycle when you get it. new electric bicycle and gives good advice and
instructions. Your electric bicycle shall be operated to function well and stay long.
By regularly care for and nurture your electric bicycle will become a more fun and safer means of
transportation and you get more out of Your cycling.
Good luck with your new bike!

TABLE OF CONTENTS

1. Generally introduction for electric bike..............................page 1-2
2. Technical specifications......................................................page 2
3. Bike parts...........................................................................page 3
4. installing the handle...........................................................page 3-5
5. installing the saddle............................................................page 6
6. installing the pedals...........................................................page 6
7.installing and take out the battery.....................................page 7
8. charger the battery............................................................page 8
9.Display.................................................................................page 9
10. Gearing.............................................................................page 9
11.Inspection before first bike tour........................................page 10-11
13.Bike legally.........................................................................page 11
14. Maintenance......................................................................page 11-14
15. Safety and maintenance Recommendations................... page 14-16
16.Warranty............................................................................ page 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Adventurer and is the answer not in the manual?

Questions and answers

Summary of Contents for Gehring Group Adventurer

  • Page 1: Table Of Contents

    WELCOME! Thank you for choosing our electric bike! This manual shows how to use the bicycle when you get it. new electric bicycle and gives good advice and instructions. Your electric bicycle shall be operated to function well and stay long. By regularly care for and nurture your electric bicycle will become a more fun and safer means of transportation and you get more out of Your cycling.

  • Page 2: Generally Introduction For Electric Bike

    Generally introduction for electric bike Before the eibke first use, the battery should charging about 4-6 hours. Normally less than 4-6 hours since the battery has power inside. All electric bicycles is a bicycle with an auxiliary meaning to a regular bike for only pedal power has been provided with an electric motor to assist the cyclist when resistance increases, for example.

  • Page 3: Bike Parts

    Control display: bafang LCD display Tire&tubes: Kenda 27.5*1.95 mountain tire Rim:27.5 integrated wheel rims Pedal: alloy MTB pedals Saddle: SR MTB saddle BIKE PARTS 1. leather handlebar 2. LCD display 3. Brake lever 4. Shimano shifter 5.Stem 6. Wheel 7.Suspension Front fork 8.
  • Page 4 Installing Please kindly see below for the installing whole ebike. Normally your ebike is whole ready to ride. Handle 1. Unscrew the stem lower part and turn the stem 180 ° like below pictures. make sure the handle bar and ebike at the same straight line.
  • Page 5 3. Install the wheel: Because the Ebike has the wheel quick release device, only need to put the wheel inside the front fork like below picture, then screw the quick release device two sides tightly. fold and press it make it stable . 4.
  • Page 6 Pedals When installing the pedals to see pedals are marked "L" (left) and "R" (right) on the bolt screwed fixed to the pedal arm. Make sure the right pedal mounted on Blankets respective handlebars.( normally if the pedal can’t be screw into the crank, then it means the pedal is not the right one. You can change another one).

  • Page 7: Charger The Battery

    2. Open the lock on the rack with key 3. pull out or Push in the battery. 4. Lock the battery with key. Charge the battery 1. Before you charge your battery, please check your battery power on display if it’s empty. 2.Charge the battery with the charger when the light from red to green.

  • Page 8: Display

    Display (for the details please see LCD display manual) 1. turn on the display you can choose the mode according to the button, everything will show on the display. For speed, range, temperature, time and battery. Gearing Adjustment of Shimano Tourney 7 gears. Press the right gears and choose the gear you want when you are riding.
  • Page 9 The condition of the chain and sprocket are important for drive package's useful life. Remember to regularly it lubricate each link of the chain with chain oil – a drop on each link is a good rule of thumb. Note also that the chain and sprocket are wear components that must be replaced occasionally. In case of replacement of wear components such as chain, gears, cables, housings, brake pads, tires, tubes, if need, please contact the shop.

  • Page 10: Bike Legally

    BIKE LEGALLY By law, a bicycle always be equipped with brakes and bell. In the dark cycle must also be equipped with head- starter with white light up lantern with red light behind the white reflector front and red reflector back and orange or white reflector in wheels. On public roads, it is important to consider the following: As traffic you are required to know and follow APPLY ratio Traffic rules.
  • Page 11 2.Routine maintenance. Frequency Task Before every ride Be sure batteries are fully charged Check tire pressure Check brake operation Check wheels for loose spokes After every ride Be sure to fully charge batteries Quick wipe down with damp Weekly Lubrication as per schedule Monthly Inspect wire Inspect connectors...
  • Page 12 Battery safety instructions Your bike's battery is an electric component made up of chemical elements. For your safety, it is imperative that you obey the following rules: Always handle with great care Always keep it away from children Do not take it apart or hit, pierce or submerge it, Keep it away from temperatures exceeding 40 ° . Nevercreat a connection between the contacts located at the bottom of the battery.

  • Page 13: Safety And Maintenance Recommendations

    Safety and maintenance Recommendations 1.Safety recommendations Helmet For safe riding- use of a bicycle helmet. Tyres Inspect the wear of your tyres on a regular basis and verify the tyre pressure at least once a month. Tyre pressure: 40-65 PSI depending on the weight of the user. Wheel-rims Please care of the wheel-rims and a clear explanation of any danger of rim-wear.

  • Page 14: Warranty

    Signaling device The bike is silent. In order to alert others as to your presence, you have an approved signaling device: use it only when absolutely necessary, don’t abuse it! Battery WARNING: As with all mechanical components, the bicycle is subjected to wear and high stresses. Different materials and components may react to wear or stress fatigue in different ways.
  • Page 15 WASTE DISPOSAL Electrical waste Used electrical and electronic products, thereby among all types of batteries, be submitted to the intended collection ment for recycling. (According to Directive 2012/19 / EU 2006/66 / EC). Have a pleasant ride!
