MODEL: XL202
FIRMWARE: RFTDAF
Installation Guide
COMPATIBILITY
Range Extender*
XK Modules
+
The power (
12V
) must be applied
last to the XK module.
* Vehicles equipped with factory remote starter only
†
CANMAX400 is not only a range extender, it is also a standalone remote starter.
REQUIREMENT SPECIFICATIONS
Update Alert
Firmware updates are posted to the web on a regular basis. It is important that you check
tm
for firmware and/or install guide updates prior to the installation of this
†
CANMAX400
+
The RFTD feature of the
CANMAX400 must be turned on to
have full two-way communication.
*
TECHNICAL SUPPORT / INFORMATION
Remote Starter Standalone
Note: See XpressKit.com for vehicle application guide.
DLPKKICH3
or XK09
or CANMAX400
To proceed with the installation of the
XL202 RFTD with Astro firmware you need:
XL202 RFTD module.
D2D harness.
AstroStart RF kit, which includes a
and a receiver antenna.
* This image is for example purposes only. Your remote may
be a different model.
Rev.: 20091124
Page 1
web resources:
www.xpresskit.com
www.xpressvip.com
www.directechs.com
+
†
remote
product.
