Summary of Contents for SFL Supra
- Page 1 SUPRA Stainless Steel Single Wall Chimney System for Condensing Appliances...
- Page 2 Supra product, unless Approvals approved by SFL prior to installation. The Supra product is CE certified to BS EN 1856-1 & 2 certificate No. 0086-CPD-496040 & 0086-CPD-559419 to the performance Application designations as detailed in Table A below.
- Page 3 Solid Fuel & Oil Fired Appliances: BS EN15287-1:2007 Domestic Gas Installations: BS5440: Part 1: 2008 Joint Seal Where Supra is used to reline an existing stack, it is imperative that Ensure the Seal Lips the product is not supported by suspending from the top of the face down See Fig.
- Page 4 Installed Length (mm) other components, but however applied, 80mm- 150mm must engage a depth equivalent to at least half the diameter of the Supra being 180mm- 600mm used. Adjustable Length (80mm - 350mm) are also supplied with a special Locking...
-
Page 5: Table Of Contents
135° Tee and 45° Elbow configuration 93° Equal Tee Used to provide a 90° connection in a The tee is provided with a 3° connection system run or can be used as an access / on the branch to allow for condensate inspection point when used with a Locking drainage where headroom is limited. - Page 6 Horizontal Duct Drain 40° Elbow Used as a drainage point on the end Used to provide a 40° change of of an inclined manifold or inclined run. direction from the vertical. Incorporates an internal condensate dam and BSP stainless steel connection for 40°...
-
Page 7: A B C
200mm 4579708N Appliance Adaptor 250mm 4579710N 300mm 4579712N Used to connect the Supra product to 350mm 4579714N the appliance. The interface between the Adaptor and the appliance outlet should be sealed with silicon sealant Adaptor to Flex when used on condensing appliances. - Page 8 3115154 of the collar rest on the plate, the hole 180mm 3115185 in which being large enough to permit 200mm 3115205 the passage of the swages of the Supra 20mm 250mm 3115255 construction. 300mm 3115305 The plate must be adequately supported...
-
Page 9: 150Mm 4014915
150mm 70 70123406 180mm 70 70123407 Gas Terminal 200mm 70 70123409 250mm 70 70123411 A terminal designed for use where Supra 300mm 70 70123412 serves conventional gas fired equipment. 350mm 70 70123413 Incorporates a bird screen/mesh. For 400mm 70 70123414... - Page 10 Supra Terminal Kit INCREASERS / REDUCERS The Supra Terminal Kit is designed for use where Supra is located within a Reducers chimney or shaft. It consists of a plate Reducers are used to reduce the and a 100mm upstand (drum) which is...
- Page 11 ELBOW OFFSET DIMENSIONS 15° Offset 30° Offset 45° Offset Dimensions Dimensions Dimensions Size Size Size 80mm 281 37 80mm 313 86 80mm 328 143 100mm 296 39 100mm 335 92 100mm 365 158 130mm 234 31 130mm 245 71 130mm 248 110 150mm 238 32...
- Page 12 (See Page 7). and seal profile Jointing The Supra system is jointed by pushing the male end into the Direction female end of the proceeding component, and then applying a Locking Band. The Locking Band must be installed so that the toggle is only closed from left to right.
- Page 13 Terminal Types exceeding 2.5 metres. The Location Band, used to centralise Supra where lowered into a chimney or shaft, should be used The Supra range offers a number of different terminal types at intervals not exceeding 3 metres, and secured immediately to suit various applications.
- Page 16 Tel: 01271 326633 Fax: 01271 334303 www.sflchimneys.com info@sflchimneys.com Consider your environment and download the latest electronic version of the Supra sales literature direct from our web site using the QR code above. In order to minimise the environmental impact on this publication, it has been printed locally, using vegetable based inks on FSC certified paper.
