Page 1: Reference Manual
Ayazi DAC mk2 Reference manual v.2.2... - Page 2 1 DAC INTRODUCTION Thank you for purchasing the Ayazi digital to analog converter. It was designed to bring you many years of outstanding listening pleasure. We sincerely hope that it will. The Ayazi DAC digital to analogue converter is a highly versatile, user- friendly product and we strongly recommend that you read this manual.
- Page 3 The single-ended output, also situated on the rear panel, must be connected to the input on the next device up the chain: pre-amplifier, amplifier / receiver, etc. 1.2 DAC FRONT PANEL INDICATORS & FRONT PANEL SWITCHES Two indicators on the DAC front panel illuminate to indicate operational states: ...
- Page 4 2 DAC INSTALLATION AND CONNECTIONS The DAC should be installed on a dedicated equipment stand intended for the purpose. Once you have safely installed the device, please connect audio inputs and output using quality interconnect cables. Good quality cables can provide better audio results. Before powering on, make sure you read the passage below! Connecting to mains &...
- Page 5 2.1 INPUTS & OUTPUT s/pdif coaxial 75ohm (connection with CDP or any s/pdif out devices ) type b (connection with P/C ) Output single-ended 2.5k Ω, 2.0V Left rca left analog out Right rca right analog out www.ideonaudio.com Ayazi manual...
- Page 6 2.2 DRIVERS INSTALLATION If you're going to use a Windows PC as an audio source via USB, Windows will have to install drivers when you first plug in the Ayazi DAC. This should be a fully automatic process* on Windows 10, 8, and 7, but it may take a long time to download and install.
- Page 7 4 SERVICING THERE ARE NO USER-SERVICEABLE PARTS INSIDE ANY PS AUDIO PRODUCT. REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL Please contact your authorized dealer, distributor, or Ideon Audio if you have any questions not addressed in this reference document. www.ideonaudio.com...
- Page 8 5 WARRANTY Ideon Audio provides a 2-year manufacturer’s warranty on all new Ideon Audio components. This Warranty is subject to the following conditions and limitations: The Warranty is void and inapplicable if the product has been used or handled other than in accordance with the instructions in this document, abused, or...
