SAFETY PRINCIPLES, OPERATION AND MAINTENANCE
Read carefully this manual before using this product. This manual contains important
information on safety, use, operation, maintenance and check of the product. Make
this manual available to all responsible persons.
Edition 1.
MAY 2006
Evidence number 1-52473-0-1
BRANO a.s, 747 41 Hradec nad Moravicí
tel.:+420/ 553 632 318, 553 632 345
fax:+420/ 553 632 407, 553 632 151
http://www.brano.cz
OPERATION MANUAL
FOR
ROPE WITH HOOK
Type: Z 500 L
Keep for further use!
Czech Republic
info@brano.cz
Advertisement
Table of Contents
Related Manuals for Brano Z 500 L
Summary of Contents for Brano Z 500 L
- Page 1 BRANO a.s, 747 41 Hradec nad Moravicí Czech Republic tel.:+420/ 553 632 318, 553 632 345 fax:+420/ 553 632 407, 553 632 151 http://www.brano.cz info@brano.cz OPERATION MANUAL SAFETY PRINCIPLES, OPERATION AND MAINTENANCE ROPE WITH HOOK Type: Z 500 L Read carefully this manual before using this product. This manual contains important information on safety, use, operation, maintenance and check of the product.
-
Page 2: Table Of Contents
CONTENT 1 DEFINITION ......................3 2 DEVICE PURPOSE ....................3 3 SAFETY PRINCIPLES..................... 3 3.1 SAFETY SUMMARY ..................3 3.2. SAFETY PRINCIPLES ..................3 4 PACKING, STORAGE AND MANIPULATION ............5 4.1 PACKING ......................5 4.2 STORAGE......................5 5 MAIN TECHNICAL PARAMETERS ................. 5 6 USE OF THE ROPE .................... -
Page 3: Definition
1 DEFINITION ! DANGER Danger is used to indicate the presence of hazard which will cause death or severe injury if the warning is ignored. ! WARNING Warning is used to indicate the presence of a hazard which can cause death or severe injury if the warning is ignored. ! CAUTION Caution is used to indicate the presence of a hazard which can cause minor injury if the warning is ignored. - Page 4 ! WARNING 3.2.1 Prior to use ALWAYS ensure physically fit, qualified and instructed persons older than 18 years of age, familiarized with this manual and trained in safety conditions and way of work, operate the rope. ALWAYS check rope according to the section 7.1before starting to work. ALWAYS make sure the length of rope is sufficient for intended work.
-
Page 5: Packing, Storage And Manipulation
4 PACKING, STORAGE AND MANIPULATION 4.1 PACKING Ropes are supplied packed in bundle tied by binding band. 4.2 STORAGE Store ropes in dry and clean stocks free of chemical influences and vapours. (1) Roll up the rope so that it is not twisted. (2) Lubricate the spring of the hook pawl and contact area of the hook eye with thimble. -
Page 6: Suspending And Binding Of The Rope
Pic.6.1 6.2 SUSPENDING AND BINDING OF THE ROPE ! WARNING 6.2.1 On the rope only such subjects can be suspended or tied that by their shape and stiffness enable safety binding. 6.2.2 Hook the load or bind it on the eye so that the gravity centre of the load is in the axis of the hook. -
Page 7: Rope Recording
7.1.3 When inspecting the rope check visually: - rope marking (marking label with data); - overall condition of the rope; - wear and tear; - change of the rope surface by effect of heat, acids and other chemical substances; - condition of eyes and their entangling and condition of cable ends. Hooks with eye –... -
Page 8: Related Documentation
9 RELATED DOCUMENTATION EC declaration of conformity This Operation Manual was elaborated in accordance with following technical regulations, technical standards and national regulations: • Ministerial order No.24/2003 of the Coll. of Law as amended (EP and Council directive 98/37/EC) • Ministerial order No.23/2003 of the Coll.
