ABS Safety ABS-Lock SYS II Manual

Traversable
Hide thumbs Also See for ABS-Lock SYS II:

Advertisement

Quick Links

Download this manual
Überfahrbar / Traversable
ABS-Lock® SYS II+IV
DIN CEN/TS
Z-14.9-688
16415:2013
DIN EN 795:
2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the ABS-Lock SYS II and is the answer not in the manual?

Questions and answers

Related Manuals for ABS Safety ABS-Lock SYS II

Summary of Contents for ABS Safety ABS-Lock SYS II

  • Page 1 Überfahrbar / Traversable ABS-Lock® SYS II+IV DIN CEN/TS Z-14.9-688 16415:2013 DIN EN 795: 2012...
  • Page 2 ‫وكتيب إرشادات السالمة‬ ‫يجب االلتزام بالتعليمات الواردة في دليل التركيب‬ Kontakte | Contact persons Mustertypenschild | Sample label Vertrieb & Technische Beratung ABS SAFETY GMBH Sales & Technical Support Kevelaer, Germany +49 (0) 28 32 - 972 81 - 0 info@absturzsicherung.de www.absturzsicherung.de...
  • Page 3 ABS-Lock® SYS II+IV Inhalt | Content ABS Systemschild ABS SP ABS TI-Bracket ABS Gabelkopf ABS specification plate (aufgewalzt) ABS clevis (rolled on) ABS ForceLimiter ABS TI-FlexCurve Befestigung für Fassaden- Spannelement / kurven Attachment for tensioning element facade corners ABS CompactForce...
  • Page 4 ABS-Lock® SYS II+IV Montage nach abZ (in Deutschland zu beachten) Z-14.9-688 Installation according to abZ (Observe in Germany) ABS ForceLimiter 2 – 10 Gerades System / straight system ABS ForceLimiter 2 – 10 Mit Kurven / with curves...
  • Page 5 Montage nach EN 795:2012 ABS-Lock® SYS II+IV DIN EN 795 Installation according to EN 795:2012 ABS ForceLimiter max. Gerades System (starres System) / straight system (stiff system) ABS ForceLimiter max. Mit Kurven (starres system) / with curves (stiff system) ABS ForceLimiter max.
  • Page 6 ABS-Lock® SYS II+IV SYS IV SYS II ABS TI-FlexCurve Seite / Page ABS TI-FlexCurve Seite / Page ABS ProSlide SY-PROSLIDE ABS Systemschild ABS specification plate Seite / Page ABS Gabelkopf (aufgewalzt) / ABS clevis (rolled on) ABS TI-Bracket Seite / Page Seite / Page ABS SP Seite / Page...
  • Page 7 ABS-Lock® SYS II+IV ABS TI-FlexCurve Seite / Page ABS TI-Bracket Seite / Page OPTIONAL ABS CompactForce ABS ForceLimiter Seite / Page Seite / Page ABS Spannelement ABS tensioning element Seite / Page...
  • Page 8 ABS-Lock® SYS II+IV SYS IV SYS II ABS TI-Bracket Seite / Page ABS CompactForce Seite / Page ABS ForceLimiter Seite / Page ABS SkyRoll SY-SKYROLL max.
  • Page 9 ABS-Lock® SYS II+IV ABS Gabelkopf (aufgewalzt) / ABS clevis (rolled on) Seite / Page ABS TI-FlexCurve Seite / Page ABS TI-Bracket Seite / Page ABS ForceLimiter Seite / Page...
  • Page 10 10 | ABS Systemschild / ABS specification plate SY-1009 Biegen per Hand Bend by hand 50 Nm 70 Nm 45 Nm...
  • Page 11 ABS Systemschild / ABS specification plate ABS SP SY-1009 SY-1031 70 Nm 50 Nm 70 Nm 45 Nm...
  • Page 12 12 | ABS TI-Bracket SY-TIB-6, SY-TIB-8 70 Nm 50 Nm 70 Nm 45 Nm...
  • Page 13 ABS Gabelkopf (aufgewalzt) / ABS clevis (rolled on) ABS ForceLimiter SY-1051, SY-1051A SY-FL 70 Nm 30 Nm...
  • Page 14 14 | ABS TI-FlexCurve SY-TIFC-6, SY-TIFC-8 Biegen per Hand nur in Richtung der Schlitze Bend by hand only in direction of the slots...
  • Page 15 ABS TI-FlexCurve SY-TIFC-6, SY-TIFC-8 50 Nm 70 Nm...
  • Page 16 16 | Befestigung für Fassadenkurven / Attachment for facade corners SY-1016-FA min. max. WDVS / EIFS Verbundmörtel Special Adhesive WIT-VM-250 • MoA-134...
  • Page 17 Befestigung für Fassadenkurven / Attachment for facade corners SY-1016-FA 70 Nm...
  • Page 18 18 | Universeller Befestigungswinkel / Universal attachment bracket L3-WINK-60-1X17 70 Nm 70 Nm...
  • Page 19 ABS Spannelement / ABS tensioning element SY-1007, SY-1007A...
  • Page 20 20 | ABS Spannelement / ABS tensioning element SY-1007, SY-1007A SYS II SYS IV 8 mm 6 mm 60 Nm 60 Nm SYS II SYS IV 8 mm 6 mm 30 Nm 30 Nm...
  • Page 21 ABS Spannelement / ABS tensioning element SY-1007, SY-1007A SYS II SYS IV 8 mm 6 mm 30 Nm 30 Nm...
  • Page 22 22 | ABS Compact Force SY-CF-6, SY-CF-8...
  • Page 23 ABS Compact Force SY-CF-6, SY-CF-8 SYS II SYS IV 8 mm 6 mm 60 Nm 60 Nm SYS II SYS IV 8 mm 6 mm 30 Nm 30 Nm...
  • Page 24 24 | ABS Compact Force SY-CF-6, SY-CF-8 SYS II SYS IV 8 mm 6 mm 0,4 – 0,6...
  • Page 25 ABS Compact Force SY-CF-6, SY-CF-8 SYS II SYS IV 8 mm 6 mm 30 Nm 30 Nm 20 Nm...
  • Page 26 26 | Scribbles & Notes...
  • Page 27 Scribbles & Notes | 27...
  • Page 28 ABS Safety GmbH Gewerbering 3 D-47623 Kevelaer Germany Tel.: +49 (0) 28 32 - 972 81 - 0 Fax: +49 (0) 28 32 - 972 81 - 29 info@absturzsicherung.de www.absturzsicherung.de www.protection-anti-chute.fr www.fall-arrest.eu instagram.com/abssafety youtube.com/abssafetygmbh facebook.com/ABS.Safety...
