HEBU Staubsauger
Gebrauchs- und Serviceanleitung
Seite 3
Operating and service manual
Page 17
Mode d´emploi et de service
Page 31
Instrucciones para el uso y el servicio
Página 45
Istruzioni per l´uso et di servizio
Pagina 59
HB 8881
HB 8881V
DEUTSCH
ENGLISH
FRANÇAIS
ESPAÑOL
ITALIANO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HB 8881 and is the answer not in the manual?

Questions and answers

Summary of Contents for HEBU medical HB 8881

  • Page 1 HB 8881 HB 8881V HEBU Staubsauger Gebrauchs- und Serviceanleitung DEUTSCH Seite 3 Operating and service manual ENGLISH Page 17 Mode d´emploi et de service FRANÇAIS Page 31 Instrucciones para el uso y el servicio ESPAÑOL Página 45 Istruzioni per l´uso et di servizio...
  • Page 2 HEBU Staubsauger...
  • Page 3: Table Of Contents

    HEBU Staubsauger HB 8881 HB 8881V HEBU Staubsauger Inhalt Lieferumfang............................. 5 Sicherheitshinweise .......................... 5 Einsatzbereich ..........................6 Zweckbestimmung ........................6 Kontraindikationen ........................6 Bedienung ............................6 Manueller Betrieb ........................6 Automatik - Betrieb ........................7 Reinigung und Wartung ........................8 Filter wechseln ..........................
  • Page 4 HEBU Staubsauger HEBU Staubsauger...
  • Page 5: Lieferumfang

    HEBU Staubsauger 1 Lieferumfang HB 8881 HEBU Staubsauger HB 8887-03 ECO-Vlies-Filter HB 8886-04 Vliesfiltertüte (1 Stück) Gebrauchsanweisung Auf Wunsch unserer Kunden ändern wir diese Standardbestückung. Bitte beachten sie den Text auf ihrer Rechnung. Weitere Informationen finden sie im Kapitel Zubehör.
  • Page 6: Einsatzbereich

    HEBU Staubsauger 3 Einsatzbereich Der Einsatz von Staubabsaugungsgeräte findet in der Orthopädie zur Entfernung von Gipsstaub statt. 3.1 Zweckbestimmung Eine Zusammenstellung von Vorrichtungen, die benutzt wird, um den Staub der durch eine Gipssäge bei der Gipsentfernung produziert wird (z.B., pneumatische oder elektrische Gipssäge,) vom Arbeitsfeld abzusaugen.
  • Page 7: Automatik - Betrieb

    HEBU Staubsauger Inbetriebnahme: ➢ Absaugschlauch adaptieren ➢ Netzstecker einstecken ➢ Gerät einschalten und in Betrieb nehmen 4.2 Automatik - Betrieb ➢ Netzstecker der HEBU-Oszillosäge am Sauger einstecken (1) ➢ Sauger einschalten (2) ➢ Lampe leuchtet und der Sauger läuft zur Kontrolle ca.
  • Page 8: Reinigung Und Wartung

    HEBU Staubsauger 5 Reinigung und Wartung Vor Reinigungs- und Wartungsarbeiten Netzstecker ziehen. Instandsetzung dürfen nur durch zugelassene Kundendienststellen oder durch Fachkräfte für dieses Gebiet, welche mit allen relevanten Sicherheitsvorschriften vertraut sind, durchgeführt werden. Sicherheitsüberprüfungen nach den örtlich geltenden Vorschriften für ortsveränderliche gewerblich genutzte Geräte beachten ➢...
  • Page 9: Motorschutzfilter Wechseln

    HEBU Staubsauger 5.3 Motorschutzfilter wechseln ➢ Sauger ca. 30 min abkühlen lassen (falls er zuvor in Betrieb war) ➢ Filterabdeckung öffnen ➢ Filterhalterung entfernen ➢ Motorschutzfilter wechseln ➢ Filterhalterung wieder anbringen ➢ Filterabdeckung schließen, muss hörbar einrasten...
  • Page 10: Störungshinweise

    HEBU Staubsauger 5.4 Störungshinweise Saugturbine läuft nicht • Kabel, Stecker, Sicherung und Steckdose überprüfen • Gerät einschalten Saugturbine schaltet ab • Behälter leeren Saugturbine läuft nach Behälterentleerung nicht wieder an • Gerät ausschalten und 5 s warten, nach 5 s wieder einschalten Saugkraft lässt nach •...
  • Page 11: Ersatzteile Sauger

    7 Ersatzteile Sauger 7.1 Ersatzteile Gehäuse (Zeichnungspositionen beziehen sich auf Abbildung 1 HEBU-Nr. Pos. Menge Beschreibung HB 8881 HB 8881V Haube kpl. Nur für Ersatz E 8881-01 Zylinderstift 5m6x50 -St ISO 2338 E 8881-02 Kabelhacken (grau) E 8881-03 Netzanschlusskabel 8m *EU / 8m *US...
  • Page 12 HEBU Staubsauger Abbildung 1: Explosionsansicht des Gehäuses...
  • Page 13: Ersatzteile Saugturbine

    HEBU Staubsauger 7.2 Ersatzteile Saugturbine (Zeichnungspositionen beziehen sich auf Abbildung 2 HEBU-Nr. Pos. Menge Beschreibung HB 8881 HB 8881V Gehäuse kpl. E 8881-20 Saugturbine kpl.230V / 110V E 8881-21 E 8881-21V Kohlebürstensatz E 8881-22 Lagerung Motor unten T12/1 E 8881-23 Gehäuse kpl.
  • Page 14: Ersatzteile Behälter

    HEBU Staubsauger 7.3 Ersatzteile Behälter (Zeichnungspositionen beziehen sich auf Abbildung 3 HEBU-Nr. Pos. Menge Beschreibung HB 8881 HB 8881V Behälter kpl. E 8881-31 Sicherungsring E 8881-32 Sauganschluss - T E 8881-33 Fahrgestell kpl. Nur für Ersatz E 8881-34 Lenkrolle mit Bremse E 8881-35 Rad kpl.
  • Page 15: Garantie

    Entsorgungs- und Recyclingsystem für Elektrogeräte zugeführt werden. Weitere Informationen erhalten Sie bei Ihrem Fachhändler. 10 Technische Daten Bauart HB 8881 HB 8881 (V) Netzanschluss 220-240 Volt, 50/60 Hz. 110-120 Volt, 50/60 Hz. Nennaufnahme 1300 Watt 1300 Watt...
  • Page 16: Anhang

    HEBU Staubsauger 12 Anhang Komplettsetz mit Sägen und Zubehör HB 8888-01 Mit Säge HB 8884, Sauger + Schlauch + Schlauchhalter + Absaugglocke + Sägeblatt 8896-03 + Werkzeug (jedoch ohne HB 8883-03 und HB 8883-05) Nur optionales Zubehör Nur optionales Zubehör HB 8888-02 Mit Säge HB 8880, Sauger + Schlauch + Schlauchhalter + Absaugglocke + Sägeblatt 8896-02 + Werkzeug (jedoch ohne HB 8883-04 und HB 8883-05)
  • Page 17 HEBU Staubsauger Zubehör (optional) HB 8883-03 Aufhängung mit Griff, höhenverstellbar HB 8883-04 (HB 8883-03 für alle Sägen außer ECO II und HB 8883-04 für ECO II) HB 8883-05 Magnetische Ablage für Sägeblätter und Werkzeug...
  • Page 18 HEBU Vacuum Cleaner HB 8881 HB 8881V HEBU Vacuum Cleaner Contents Scope of delivery ............................... 20 Safety instructions.............................. 20 Scope ................................. 21 Inteded use ............................... 21 Contraindications ............................21 Operation ................................21 Manual mode ............................21 Automatic mode ............................22 Cleaning and maintenance ..........................
  • Page 19 HEBU Vacuum Cleaner HEBU Vacuum Cleaner...
  • Page 20: Scope Of Delivery

    HEBU Vacuum Cleaner 1 Scope of delivery HB 8881 HEBU Vacuum Cleaner HB 8887-03 ECO nonwoven filter HB 8886-04 Nonwoven filter bag (1 pc.) Operating manual On request, we can alter this standard configuration. Please note the wording on your invoice.
  • Page 21: Scope

    HEBU Vacuum Cleaner 3 Scope Dust extraction equipment is used in orthopaedics to remove gypsum dust. 3.1 Inteded use dust extractor; Accessories: An assortment of devices used to extract the dust produced by a plaster saw during gypsum removal (e.g., pneumatic or electric gypsum saw) from the working field. It usually consists of a motorized vacuum pump, a filter and a collection container (e.g., bag or cartridge).
  • Page 22: Automatic Mode

    HEBU Vacuum Cleaner Commissioning: ➢ Adapt the suction hose ➢ Connect the mains plug. ➢ Switch on the device and start up 4.2 Automatic mode ➢ Insert the mains plug of the HEBU oscillating saw at the vacuum cleaner (1). ➢...
  • Page 23: Cleaning And Maintenance

    HEBU Vacuum Cleaner 5 Cleaning and maintenance Before performing any cleaning or maintenance work, disconnect the mains plug. Repairs may only be performed by approved customer service centres or by specialist personnel who are familiar with all relevant safety regulations. Ensure that all safety checks stipulated by the relevant locally applicable regulations for mobile commercially used devices are observed.
  • Page 24: Exchanging The Motor Protection Filter

    HEBU Vacuum Cleaner 5.3 Exchanging the motor protection filter ➢ Leave the vacuum cleaner to cool down for around 30 minutes (if it has just been in use) ➢ Open the filter cover ➢ Remove the filter holder ➢ Exchange the motor protection filter ➢...
  • Page 25: Troubleshooting

    HEBU Vacuum Cleaner 5.4 Troubleshooting Suction turbine is not running • Check the cable, plug, fuse and socket. • Switch on the device The suction turbine switches off • Empty the container The suction turbine does not start up again after emptying the container •...
  • Page 26: Vacuum Cleaner Spares

    7 Vacuum cleaner spares 7.1 Housing spares (drawing numbers refer to Fig. 1) HEBU-Nr. Pos. Batch Description HB 8881 HB 8881V Complete hood for replacement only E 8881-01 Parallel pin 5m6x50 -St ISO 2338 E 8881-02 Cable hook (grey) E 8881-03...
  • Page 27 HEBU Vacuum Cleaner Fig. 1: Explosion drawing of the housing...
  • Page 28: Suction Turbine Spares

    HEBU Vacuum Cleaner 7.2 Suction turbine spares (drawing numbers refer to Fig 2) HEBU-Nr. Pos. Batch Description HB 8881 HB 8881V Complete housing E 8881-20 Complete suction turbine 230V / 110V E 8881-21 E 8881-21V Set of carbon brushes E 8881-22...
  • Page 29: Container Spares

    HEBU Vacuum Cleaner 7.3 Container spares ( drawing numbers refer to Fig 3) HEBU-Nr. Pos. Batch Description HB 8881 HB 8881V Complete container E 8881-31 Circlip E 8881-32 Suction port T E 8881-33 Complete chassis for replacement E 8881-34 only...
  • Page 30: Warranty

    Ask your specialist dealer for more detailed information. 10 Specifications Model HB 8881 HB 8881 (V) Mains connection 220-240 Volt, 50/60 Hz. 110-120 Volt, 50/60 Hz. Rated consumption...
  • Page 31: Annex

    HEBU Vacuum Cleaner 12 Annex Complete set including saw and accessories HB 8888-01 With saw HB 8884, vacuum cleaner + hose + hose holder + dust removal unit + saw blade 8896-03 + tools (but without HB 8883-03 and HB 8883-05) Only optional Only optional accessories...
  • Page 32 HEBU Vacuum Cleaner HB 8883-03 Hanging kit with handle, height adjustable HB 8883-04 (HB 8883-03 for all saws except ECO II and HB 8883- 04 for ECO II) HB 8883-05 Magnetic shelf for saw blades and tools...
  • Page 33 HEBU Aspirateur HB 8881 HB 8881V Aspirateur HEBU Contenu Etendue de la livraison ............................35 Remarques relatives à la sécurité ........................35 Service ................................36 Fonctionnement manuel ..........................36 Fonctionnement automatique ........................37 Application ................................. 37 Utilisation conforme à l'usage prévu ......................37 Contre-indications .............................
  • Page 34 HEBU Aspirateur HEBU Aspirateur...
  • Page 35: Etendue De La Livraison

    HEBU Aspirateur 1 Etendue de la livraison HB 8881 Aspirateur HEBU HB 8887-03 Filtre en non tissé ECO HB 8886-04 Filtre en non tissé (1 unité) Notice d’utilisation A la demande de nos clients, nous apportons des modifications à ce contenu standard.
  • Page 36: Service

    HEBU Aspirateur 3 Service 3.1 Fonctionnement manuel Montage du filtre : ➢ Déverrouiller et déposer la tête d’aspiration ➢ Mettre en place le filtre en papier ➢ Remonter et verrouiller la tête d’aspiration Mise en service : ➢ Ajuster le tuyau d’aspiration. ➢...
  • Page 37: Fonctionnement Automatique

    HEBU Aspirateur 3.2 Fonctionnement automatique ➢ Brancher la fiche d’alimentation de la scie oscillante HEBU sur l’aspirateur (1) ➢ Allumer l’aspirateur (2) Le voyant s’allume et l’aspirateur se met ➢ en marche pour contrôle pendant environ 0,5 s L’aspirateur se trouve alors en mode veille (3) Remarque : ♦...
  • Page 38: Nettoyage Et Maintenance

    HEBU Aspirateur 5 Nettoyage et maintenance Avant les travaux de nettoyage et de maintenance, débrancher la fiche d’alimentation Les travaux de réparation doivent être effectués uniquement par des centres de service après-vente homologués ou par des professionnels qualifiés en la matière et familiarisés avec toutes les consignes de sécurité...
  • Page 39: Changement Du Filtre De Protection Du Moteur

    HEBU Aspirateur 5.3 Changement du filtre de protection du moteur ➢ Laisser l’aspirateur refroidir pendant environ 30 min (s’il était en service auparavant). ➢ Ouvrir le couvercle de filtre ➢ Enlever le support de filtre ➢ Changer le filtre de protection du moteur ➢...
  • Page 40: Accessoires/Pièces De Rechange

    HEBU Aspirateur • Mettre l’appareil en marche. La turbine d’aspiration se désactive • Vider le réceptacle La turbine d’aspiration ne se remet pas en marche après la vidange du réceptacle • Mettre l’appareil à l’arrêt et attendre 5 s, le remettre en marche 5 s après La puissance d’aspiration baisse •...
  • Page 41: Pièces De Rechange Dispositif D'aspiration

    7 Pièces de rechange dispositif d’aspiration 7.1 Pièces de rechange boîtier (les positions indiquées se réfèrent à la figure 1) HEBU-Nr. Pos. Ensemble Description HB 8881 HB 8881V Capot complet Seulement pour E 8881-01 remplacement Goupille cylindrique 5m6x50 -St ISO 2338 E 8881-02 Accroche-câble (gris)
  • Page 42 HEBU Aspirateur Figure 2 : Vue éclatée du boîtier...
  • Page 43: Pièces De Rechange Turbine D'aspiration

    HEBU Aspirateur 7.2 Pièces de rechange turbine d’aspiration (les positions indiquées se réfèrent à la figure 2) HEBU-Nr. Pos. Ensemble Description HB 8881 HB 8881V Boîtier complet E 8881-20 Turbine d’aspiration complète 230V / 110V E 8881-21 E 8881-21V Jeu de balais de charbon E 8881-22 Logement inférieur du moteur T12/1...
  • Page 44 HEBU Aspirateur HEBU-Nr. Pos. Ensemble Description HB 8881 HB 8881V Réceptacle complet E 8881-31 Circlip E 8881-32 Raccord d’aspiration en T E 8881-33 Chariot complet. Seulement pour E 8881-34 remplacement Galet-guide avec frein E 8881-35 Roue complète (gris) E 8881-36 Vis 5x30 -10.9-R2R (K-In6Rd)
  • Page 45: Garantie

    électriques. Pour de plus amples informations, adressez-vous à votre commerçant spécialisé. 10 Caractéristiques techniques Type HB 8881 HB 8881 (V) Raccordement au réseau 220-240 Volt, 50/60 Hz. 110-120 Volt, 50/60 Hz. Capacité nominale 1300 Watt...
  • Page 46: Annexe

    HEBU Aspirateur 12 Annexe Jeu complet avec scies et accessoires HB 8888-01 Avec scie HB 8884, aspirateur + flexible + support de flexible + cloche d’aspiration + lame de scie 8896-03 + outil (mais sans HB 8883-03 et HB 8883-05) Seulement accessoire Seulement accessoire optionnel...
  • Page 47 HEBU Aspirateur Accessoires (optionnels) HB 8883-03 Suspension avec poignée, réglable en hauteur (HB 8883-03 pour toutes les scies sauf ECO II et HB 8883- HB 8883-04 04 pour ECO II) HB 8883-05 Tablette magnétique pour lames de scie et outils.
  • Page 48 Aspirador HEBU HB 8881 HB 8881V Aspirador HEBU Índice Instrucciones de seguridad ..........................50 Manejo ................................52 Servicio manual ............................52 Servicio automático ........................... 53 Aplicación ................................53 Uso previsto .............................. 53 Contraindicaciones ............................ 53 Limpieza y mantenimiento ..........................54 Cambio de filtro ............................
  • Page 49 Aspirador HEBU Aspirador HEBU...
  • Page 50: Instrucciones De Seguridad

    Aspirador HEBU 1 Volumen de suministro HB 8881 Aspirador HEBU HB 8887-03 Filtro de tela no tejida ECO HB 8886-04 Bolsa del filtro de tela no tejida (1 unidad) Instrucciones para el uso Podemos variar este equipamiento estándar según los deseos del cliente.
  • Page 51 Aspirador HEBU...
  • Page 52: Manejo

    Aspirador HEBU Manejo 3.1 Servicio manual Montaje de la bolsa del filtro: ➢ Desbloquear el cabezal aspirador y extraerlo. ➢ Colocar la bolsa del filtro ➢ Colocar el cabezal aspirador y bloquearlo Puesta en marcha: ➢ Adaptar la manguera aspiradora ➢...
  • Page 53: Servicio Automático

    Aspirador HEBU 3.2 Servicio automático ➢ Enchufar al aspirador a la clavija de alimentación de la sierra oscilante HEBU (1) ➢ Conectar el aspirador (2) ➢ La lámpara está encendida y el aspirador funciona durante unos 0,5 seg. para control. Ahora, el aspirador se encuentra en el modo "Standby"...
  • Page 54: Limpieza Y Mantenimiento

    Aspirador HEBU 5 Limpieza y mantenimiento de iniciar los trabajos de limpieza y mantenimiento, desenchufar la clavija de alimentación. Las reparaciones solamente pueden ser llevadas a cabo por servicios técnicos oficiales o por especialistas en este sector que conozcan todas las prescripciones de seguridad relevantes.
  • Page 55: Cambio Del Filtro Protector Del Motor

    Aspirador HEBU 5.3 Cambio del filtro protector del motor ➢ Dejar enfriar el aspirador aprox. 30 min (si previamente había estado en funcionamiento) ➢ Abrir la tapa del filtro ➢ Retirar el soporte del filtro ➢ Cambiar el filtro protector del motor ➢...
  • Page 56: Accesorios/Piezas De Recambio

    7.1 Piezas de recambio de la carcasa (Las posiciones de los dibujos se refieren a la ilustración 1) HEBU-Nr. Pos. Conjunto Descriptión HB 8881 HB 8881V Tapa compl. sólo para recambio E 8881-01 Pasador cilíndrico 5m6x50 -St ISO 2338 E 8881-02...
  • Page 57 Aspirador HEBU Cable de conexión a la red 8m *EU / 8m *US E 8881-04 E 8881-04V Palpador compl. (gris) E 8881-05 Tornillo 5x40 -A2-70 (IN6Rd) E 8881-06 Guía de aire compl. sólo para recambio E 8881-07 Filtro sólo para recambio HB 8887-03 (162x64x20mm) Rejilla abertura de soplado (negra)
  • Page 58 Aspirador HEBU Ilustración 3: Vista desarrollada de la carcasa...
  • Page 59: Piezas De Recambio De La Turbina Aspiradora

    7.2 Piezas de recambio de la turbina aspiradora (Las posiciones de los dibujos se refieren a la ilustración 2) HEBU-Nr. Pos. Conjunto Descriptión HB 8881 HB 8881V Carcasa compl. E 8881-20 Turbina aspiradora compl. 230v / 110V E 8881-21 E 8881-21V...
  • Page 60: Piezas De Recambio Del Recipiente

    Aspirador HEBU 7.3 Piezas de recambio del recipiente (Las posiciones se refieren a la ilustración 3) HEBU-Nr. Pos. Conjunto Descriptión HB 8881 HB 8881V Recipiente compl. E 8881-31 Anillo de seguridad E 8881-32 Conexión para la manguera en T E 8881-33 Bastidor compl.
  • Page 61: Garantía

    Su comercio especializado le facilita más información al respecto. 10 Datos técnicos Tipo constructivo HB 8881 HB 8881 (V) Conexión a la red 220-240 voltios, 50/60 Hz. 110-120 voltios, 50/60 Hz. Consumo nominal de corriente...
  • Page 62: Anexo

    Aspirador HEBU 12 Anexo Juego completo con sierra y accesorios HB 8888-01 Con sierra HB 8884, aspirador + manguera + soporte de manguera + campana de aspiración + hoja de sierra 8896-03 + herramienta (pero sin HB 8883-03 ni HB 8883-05) Sólo accesorio Sólo accesorio opcional...
  • Page 63 Aspirador HEBU Accesorio (opcional) HB 8883-03 Soporte de suspensión con mango, altura regulable (HB 8883-03 para todas las sierras excepto ECO II y HB 8883- HB 8883-04 04 para ECO II) HB 8883-05 Bandeja magnética para hojas de sierra y herramientas.
  • Page 64 Aspirapolvere HEBU HB 8881 HB 8881V Aspirapolvere HEBU Indice Materiale fornito ..............................66 Indicazioni di sicurezza ............................66 Azionamento ..............................67 Funzionamento manuale ........................... 67 Funzionamento automatico ........................68 Applicazione ............................... 68 Uso previsto .............................. 68 Controindicazioni ............................68 Pulizia e manutenzione ............................69 Sostituire filtro ............................
  • Page 65 Aspirapolvere HEBU Aspirapolvere HEBU...
  • Page 66: Materiale Fornito

    Aspirapolvere HEBU 1 Materiale fornito HB 8881 Aspirapolvere HEBU HB 8887-03 Filtro ECO in tessuto non tessuto HB 8886-04 Sacchetto filtro in tessuto non tessuto (1 pz.) Istruzioni d'uso Su richiesta dei nostri clienti possiamo variare questo corredo standard. Si prega di osservare il testo riportato sulla Vostra fattura.
  • Page 67: Azionamento

    Aspirapolvere HEBU 3 Azionamento Funzionamento manuale Inserimento del sacchetto filtro: ➢ Sbloccare il cappello d'aspirazione e rimuoverlo ➢ Inserire il sacchetto filtro in carta ➢ Applicare il cappello d'aspirazione e bloccarlo Messa in funzione: ➢ Attaccare il tubo d'aspirazione ➢ Inserire la spina di collegamento alla rete elettrica ➢...
  • Page 68: Funzionamento Automatico

    Aspirapolvere HEBU 3.2 Funzionamento automatico ➢ Inserire la spina della sega oscillante HEBU sull'aspiratore (1) ➢ Accendere l'aspiratore (2) ➢ La spia s'illumina e l'aspiratore effettua l'avviamento a fini di controllo per ca. 0,5 secondi. Ora l'aspiratore si trova nel modo standby (3) N.
  • Page 69: Pulizia E Manutenzione

    Aspirapolvere HEBU 5 Pulizia e manutenzione Prima di eseguire lavori di pulizia e manutenzione staccare la spina di collegamento alla rete elettrica La riparazione può essere effettuata solo da officine autorizzate del servizio assistenza clienti o da personale specializzato in tale ambito e a conoscenza di tutte le rilevanti prescrizioni di sicurezza in merito Attenersi alle previste verifiche di sicurezza secondo le normative vigenti in loco per apparecchi mobili d'utilizzo industrial...
  • Page 70: Sostituire Filtro Salvamotore

    Aspirapolvere HEBU 5.3 Sostituire filtro salvamotore ➢ Lasciar raffreddare l'aspiratore per ca. 30 minuti (se prima è stato in funzione) ➢ Aprire la copertura filtro ➢ Rimuovere il portafiltro ➢ Sostituire il filtro salvamotore ➢ Applicare nuovamente il portafiltro ➢ Chiudere la copertura filtro, deve essere udibile il suo inserimento in posizione.
  • Page 71: Accessori/Ricambi

    Aspirapolvere HEBU • Controllare cavo, spina, fusibile e presa • Accendere l'apparecchio La turbina d'aspirazione si spegne • Svuotare il contenitore Dopo lo svuotamento del contenitore la turbina d'aspirazione non si riavvia • Spegnere l'apparecchio ed attendere 5 secondi, dopo 5 secondi riaccenderlo La forza d'aspirazione va diminuendo •...
  • Page 72: Pezzi Di Ricambio Aspiratore

    7.1 Pezzi di ricambio corpo apparecchio (Le posizioni disegno si riferiscono alla Fig. 1) HEBU-Nr. Pos. Numero Descrizione HB 8881 HB 8881V Calotta compl. solo per sostituzione E 8881-01 Spina cilindrica 5m6x50 -St ISO 2338 E 8881-02 Gancio cavo (grigio)
  • Page 73 Aspirapolvere HEBU Fig.4: Vista esplosa del corpo apparecchio...
  • Page 74: Pezzi Di Ricambio Turbina D'aspirazione

    Aspirapolvere HEBU 7.2 Pezzi di ricambio turbina d'aspirazione (Le posizioni disegno si riferiscono alla Fig. 2) HEBU-Nr. Pos. Numero Descrizione HB 8881 HB 8881V Corpo compl E 8881-20 Turbina d'aspirazione compl. 230V / 110V E 8881-21 E 8881-21V Set spazzole...
  • Page 75: Pezzi Di Ricambio Contenitore

    Aspirapolvere HEBU 7.3 Pezzi di ricambio contenitore (Le posizioni disegno si riferiscono alla Fig. 3) HEBU-Nr. Pos. Numero Descrizione HB 8881 HB 8881V Contenitore compl. E 8881-31 Anello di sicurezza E 8881-32 Attacco aspirazione -T E 8881-33 Carrello compl. solo per sostituzione...
  • Page 76: Garanzia

    Potete ricevere ulteriori informazioni in merito dal Vostro rivenditore di fiducia. 10 Dati tecnici Tipo HB 8881 HB 8881 (V) Allacciamento alla rete 220-240 Volt, 50/60 Hz. 110-120 Volt, 50/60 Hz. Potenza allacciata 1300 Watt...
  • Page 77: Appendice

    Aspirapolvere HEBU 12 Appendice Kit completo con seghe ed accessori HB 8888-01 Con sega HB 8884, aspiratore + tubo + supporto tubo + campana d'aspirazione + lama sega 8896-03 + utensile (tuttavia senza HB 8883-03 e HB 8883-05) Accessorio solo Accessorio solo optional optional...
  • Page 78 Notizen / Notes / Note / Noticias / Notizie Accessori (optional) HB 8883-03 Dispositivo di sospensione con impugnatura, regolabile in altezza (HB 8883-03 per tutte le seghe eccetto ECO II e HB 8883-04 HB 8883-04 per ECO II) HB 8883-05 Ripiano d'appoggio magnetico per lame sega ed utensili...
  • Page 79 Notizen / Notes / Note / Noticias / Notizie _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________...
  • Page 80 Notizen / Notes / Note / Noticias / Notizie _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________ _______________________________________________________________________________________...
