Summary of Contents for OSTLING Minietch 80
- Page 1 Operating instructions EU 80 TREND MARKING SYSTEMS PO BOX 1311 CASTLE HILL NSW 2154 TEL: (02) 9629-9535 FAX: (02) 9629-7535 EMAIL: trend@trendmarking.com.au INTERNET: www.trendmarking.com.au...
- Page 2 Copyrights All parts of this technical document including any patents described or trademarks contained therein are sole property of Ostling Markiersysteme GmbH Solingen, Germany. Without our prior approval no part of this document may be duplicated or made available to a third party. Any misuse of this manual is strictly prohibited. No form of misrepresentation of the content of this technical document will be permitted.
-
Page 3: Table Of Contents
Operating instructions EU 80 Contents 1.0 Function explanation 2.0 Technical data 2.1 controls 3.0 Programming procedure 3.1 Preparing the marking head 3.2 Moistening the felt with electrolyte 3.3 stencils 4.0 Marking process 5.0 Maintainence 6.0 Accessories 7.0 Troubleshooting 7.1 Problem: No mark 7.2 Problem: Mark is unclear 7.3 Problem: Black spots around the mark 8.0 Electrolytes... -
Page 4: Function Explanation
155 x 200 x 150 mm 2.1 Controls Pos. 1 Voltage 8 V (AC) Pos. 2 Voltage 16 V (AC) ÖSTLING MINIETCH 80 Pos. 3 Voltage 24 V (AC) Pos. 4 Unit off Pos. 5a Connection - Positive cable Pos. 5b Connection - Negative cable 8V AC 16V AC 24V AC Pos. -
Page 5: Programming Procedure
Operating instructions EU 80 Programming procedure • Plug the banana plug with the red cable in the red plug insert (Pos. 5a). • Attach the other end of the red positive cable with the connector on the marking head (Pos. A). •... -
Page 6: Stencils
Operating instructions EU 80 Stencils In order to make your own stencils quickly and professionally, ask about our customized stencil printing systems. This includes the Östling PT 220, 550, and a 24 pin printer as well as all software. Marking process •... -
Page 7: Troubleshooting
Operating instructions EU 80 Troubleshooting Problem: No mark Try the following: • Is the power cord plugged in ? • Are all the cables properly installed ? • Has a voltage been set ? • Is the circuit breaker (Pos. 7) on the back side in order ? •... - Page 9 ÖSTLING Markiersysteme...
