Summary of Contents for Origin Enigma
- Page 1 nigma Self Encrypting Drive Installation & User Manual...
-
Page 2: Introduction
Thank you for choosing the Enigma SED from Origin Storage to secure your data. Incorporating the latest 256 Bit AES hardware encrypted 2.5” hard drives from Toshiba; the Enigma SED solution provides permanent full disk encryption on the fly, which means no speed degradation when reading and writing data. -
Page 3: Table Of Contents
USB Connection............Page 7 eSATA/USB Combo Connection......Page 8 Cloning Your Hard Drive............Page 8 Step 2 - Fitting Your Enigma SED Hard Drive....... Page 11 Step 3 - Activating Hardware............Page 12 Using Enigma SED..............Page 18 Contact Details................Page 19 Warranty Information.............. -
Page 4: Installation Instructions
Installation Instructions The Enigma SED can be installed as an upgrade for your existing hard drive; the following instructions will guide you through the installation process including how to clone data on your existing hard drive to the Enigma SED. - Page 5 The Acronis True Image HD setup wizard will appear. Click “Next” to proceed. Read the license agreement and if you agree to its terms select “I Accept This Agreement” and click “Next” to proceed. If you would like to participate in the Acronis Customer Experience Program select the relevant option and then click “Next”...
- Page 6 Select the type of installation you would like to perform by clicking on the relevant icon, we recommend selecting “Typical” . Select to install the Acronis software for all users or only the current user by selecting the relevant option and click “Next” to continue. The setup wizard will now show a summary of the options selected, and allow you to change any of these by clicking “Back”...
-
Page 7: Hardware Setup
Hardware Setup: In order to clone data from your existing hard drive to your new Enigma SED, you need to use the supplied Data Transfer Cable to connect the Enigma SED to your computer. Depending on available ports you can use either a USB port or eSATA/USB Combo port to connect the Data Transfer Cable to your computer. -
Page 8: Esata/Usb Combo Connection
Windows will detect the new hardware and automatically install the correct drivers for the device, if it does not you may need to reboot your computer for the Enigma SED to be detected. The Enigma SED will not appear in “My Computer” because it is not initialised. - Page 9 The source disk will usually be “Disk 1” and is the existing hard drive on your computer. The target disk is the Enigma SED and can be checked by ensuring that the capacity shown in the “Before” section matches that of your Enigma SED and that is it also listed as “Unallocated” . Click “Proceed”...
- Page 10 Once the clone process is complete press any key on your keyboard to shut down your computer. Disconnect the Data Transfer Cable from your computer once it is shut down. Proceed to “Step 2 – Fitting Your Enigma SED Hard Drive” . Page 10...
-
Page 11: Step 2 - Fitting Your Enigma Sed Hard Drive
If you have purchased the Bare Drive version you will need to remove the fitting bracket from your existing hard drive and attach it to the Enigma SED hard drive before you can fit the Enigma SED into your computer. -
Page 12: Step 3 - Activating Hardware
Without the correct authentication credentials the Enigma SED will remain locked, will not boot up and will prevent access to the encrypted data stored on it. Management of the hardware encryption activation/deactivation and the authentication credentials is handled by the WinMagic MySecureDoc Express software supplied with the Enigma SED. - Page 13 The installation wizard will launch. Click “Next” to continue. Read the license agreement and if you agree to its terms select “I Accept the Terms in the License Agreement” and click “Next” . We recommend using the default destination folder for installation. Click “Next” to proceed. If you would like to change the folder that MySecureDoc Express is installed in click “Change”...
- Page 14 Click “Install” to start copying the files to your computer. Click “Finish” to complete the installation wizard, then click “Yes” when prompted to reboot. Once your computer has finished rebooting right click on the MySecureDoc Express tray icon and select “MySecureDoc Express” from the pop-up menu. Page 14...
- Page 15 Enter the credentials you would like to use (the password hint is optional) and click “Next” . NOTE: It is important that you keep these details secure as without them you will not be able to access your computer or administrate the other users and settings for the Enigma SED. Page 15...
- Page 16 MySecureDoc Express. The media created here is unique to this computer and should be stored in a safe place. Step 3 of the Disk Activation Wizard is the final step in activating the Enigma SED. Click “Activate Disk” to complete the wizard.
- Page 17 “SecureDoc Boot LogOn” and asked to enter your authentication credentials. The administrator credentials you have created allow you full control over the management of the Enigma SEDs hardware encryption, including adding/removing users and enabling/disabling the encryption authentication. If you wish to use the computer in a multi-user environment or limit user access rights to the management console, you must create additional users.
-
Page 18: Using Enigma Sed
Using Enigma SED Once the Enigma SED is installed and configured all data that is read from or written to the Enigma SED hard drive will be encrypted and decrypted on the fly using 256 Bit AES hardware encryption. Without successful authentication your computer will not be able to boot into Windows and the data stored on the Enigma SED will not be accessible and the drive will remain locked. -
Page 19: Contact Details
Contact Details If you have any questions regarding your Enigma SED or wish to make any comments you can contact us using the details below: http://www.originstorage.com Website: sales@originstorage.com E-Mail: Sales support@originstorage.com Support Telephone: +44 (0)844 288 6868 Fax: +44 (0)844 288 9090... -
Page 20: Warranty Information
Your sole and exclusive remedy for a covered defect is repair or replacement of the defective product, at Origin Storage's sole option and expense, and Origin Storage may use new or refurbished parts or products to do so. The replaced part/product will be warranted for the remainder of the original warranty or three (3) months from the date of shipment of such parts/products, whichever is longer. -
Page 21: Legal Notices
Legal Notices Copyright © Origin Storage Limited, 2009-2010. All rights reserved. “Enigma SED” , the Enigma SED logo and the Origin Storage logo are trademarks of Origin Storage Limited. “Acronis” and “Acronis Secure Zone” are registered trademarks of Acronis, Inc. - Page 22 Notes Page 22...
- Page 23 Page 23...
- Page 24 enigmaSED.com...
