Summary of Contents for ABC IT ABC S-M2080
- Page 1 User Manual ABC-Industrial Switch ABC S-M2080 14/2018...
-
Page 2: Table Of Contents
© Copyright 2003-2016 by ABC IT, Ahrens & Birner Company GmbH Virchowstraße 19/19a D-90409 Nuremberg Fon +49 911-394 800-0 Fax +49 911-394 800-99 mailto:mail@abcit.eu http://www.abcit.eu/ Contents ABC S-M2080 ............................3 FEATURES ..........................3 LEDs Behavior .......................... 3 Port Connection Diagram ....................4 Power Connection Diagram .................... -
Page 3: Abc S-M2080
ABC S-M2080 1. FEATURES • Protocol: IEEE802.3 10/100/1000M Electrical Ports: 8 x 1000M RJ45 ports and CAT5 cable is used • Optical Ports: 2 x 100M/1000M Auto Negotiation SFP port • Input Voltage: Dual Redundant DC18~36V • Power consumption: <9W •... -
Page 4: Port Connection Diagram
3. Port Connection Diagram 4. Power Connection Diagram Left: Single DC input cable connection diagram Right: Dual redundant DC input cable connection diagram 5. Factory Default (for WEB management) IP Address: 192.168.2.1 User: admin Password: system [NOTE]: To press and hold DEFAULT button for at least 5 seconds to apply factory default settings... -
Page 5: Startup And Login
6. Startup and Login Open Internet Explorer, input http://192.168.2.1 in the address bar, then the login interface will display after pressing Enter. Input the correct user name and password (default user name: admin; default password: system). The specific configuration page will display after the successful login. -
Page 6: Online Help
7. Online Help For more configurations and information of ABC S-M2080, please search in the Online Help.
