SOLARA FT2100 User Manual

Field tracker
Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual

Turning On the FT2100

To turn on your FT2100, push the On/Off toggle switch on the right side of the unit upward to
the "On" position.
The FT2100 will show the Solara logo on the display, then the main screen. As the GPS is
activated, a line reporting the number of GPS satellites heard will appear.
Automatic Tracking with the FT2100 (Commence & End Grooming Operation)
*When the power switch is on the FT2100 is automatically tracking. The FT2100 will
automatically transmit a GPS position over the system and then turn off the screen as it goes
into power save sleep mode. The FT2100 will turn off the screen automatically and go into
Power save sleep mode. You will see the green light flash about every 3 seconds once it is in
this mode. The FT2100 will automatically wake up at the programmed time to send the next
position report. In order to save power, the FT2100 does not turn on the screen when doing
routine position reports.
*At the end of grooming operations for the day press the "Send" followed by any number
key to send a complete grooming message, once message had been sent turn the unit off via
the toggle switch.
Solara Field Tracker 2100 User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT2100 and is the answer not in the manual?

Questions and answers

Summary of Contents for SOLARA FT2100

  • Page 1 Solara Field Tracker 2100 User Guide Turning On the FT2100 To turn on your FT2100, push the On/Off toggle switch on the right side of the unit upward to the "On" position. The FT2100 will show the Solara logo on the display, then the main screen. As the GPS is activated, a line reporting the number of GPS satellites heard will appear.
  • Page 2 “Make Txt Msg” menu. To send a text message, ensure the unit is in the “On” position. If the FT2100 is in power save mode, hold down the square yellow “Enter” key to wake the FT2100.
  • Page 3 To send an Alert message, reach under the toggle switch cover and turn on the Alert toggle switch. If the FT2100 was not on, this will also turn on the FT2100. The FT2100 will then enter Alert Mode begin the Alert sequence.
  • Page 4 Solara Field Tracker 2100 User Guide Charging the Internal Battery To charge in a vehicle, plug the vehicle accessory connector into the socket in your accessory power connector. This can be from 8 to 32 Volts, so using the accessory socket in vehicles with 24 volt power systems is OK.
