Lorex DMC2161 Getting Started

Hide thumbs Also See for DMC2161:

DMC2161 Components

Getting Started: The DMC2161 Cameras come with the following components. The

components marked with a red slash are not needed for your connection to the QLR Card:

1 x Camera (with 6-PIN DIN Connection)

1 x Long DIN to RCA Cable

1 x Short DIN to RCA Cable

1 x Camera Power Adaptor

(optional)

1 x RCA to USB Adaptor Box Cable

1 x USB Adaptor Box & USB Cable

Table of Contents

Do you have a question about the DMC2161 and is the answer not in the manual?

Page 1 DMC2161 Components Getting Started: The DMC2161 Cameras come with the following components. The components marked with a red slash are not needed for your connection to the QLR Card: 1 x Camera (with 6-PIN DIN Connection) 1 x Long DIN to RCA Cable...
Page 2 DMC2161 Components Camera Connections: Connect the DIN end of the camera to the DIN end of the RCA-to-DIN Cable – you can choose to use either the Long or Short RCA-to-DIN cable for this depending on the distance the camera will be from your DVR.
