Summary of Contents for Denon Professional Lectern Active
- Page 1 English ( 2 – 6 ) User Guide Appendix English ( 27 )
- Page 2 User Guide (English) Introduction The Lectern Active is a portable lectern for multi-media presentations—perfect for hotels, places of worship, conference rooms and convention centers. This all-in-one solution is designed with professional features, such as a powerful 2-way speaker system, inputs for a microphone and playback device, an LED podium lamp and a separate output to feed an external sound system or remote zone.
- Page 3 Features Rear Panel 1. Power Input: Insert the included power cable here to power the unit. 2. Fuse: If the fuse is broken, disconnect the power cord from the power outlet, and then unscrew this holder to replace the fuse. Replace it with a fuse with an appropriate rating (printed under on the rear panel).
- Page 4 Setup Items not listed under Introduction Box Contents are sold separately. 4-pin Podium Lamp XLR Microphone Smartphone (charging or audio playback) Loudspeaker Power Outlet...
- Page 5 Using a screwdriver, remove the top two rubber foot pads from the Lectern Active base. These screws can be set aside. Place the wheel so the hole in its base is matched up with the hole in the Lectern Active base where the rubber foot was attached.
- Page 6 • USB: Connect a device to the USB port on the rear panel. Important: Lectern Active must be powered on to power or charge any connected devices. To play audio: 1. Connect an audio device to one of the aux inputs—the 1/8” (3.5mm) input using a stereo 1/8”...
- Page 7 Appendix (English) Technical Specifications Output Power 200 W peak; 100 W RMS Bi-amplified design with electronic crossover & limiter Amplification (4) 5.25” (133 mm) full-range speakers (1) horn-loaded high-frequency driver Mixer Controls Microphone volume, mute button Auxiliary volume for 1/8” (3.5 mm) and RCA aux inputs (1) XLR microphone input Connections (1) 1/8”...
- Page 8 denonpro.com Manual Version 1.6...
