Summary of Contents for RISUTEC TK-120B
- Page 1 RISUTEC TK-120B Planting machine with mounding feature Instruction manual Starting from serial number #65 RISUTEC OY Porintie 314 Building 5 29250 NAKKILA, FINLAND +358500721764...
- Page 2 EC-DECLARATION OF CONFORMITY RISUTEC OY Porintie 314 29250 NAKKILA, FINLAND +358500721764 We affirm, that the equipment manufactured by us fulfils the requirements of the machine directive (directive 2006/42/EY), the changes related to it and the national statutes that enact them.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ......................1 GENERAL ..........................1 SAFETY AT WORK ......................1 INTRODUCTION AND USAGE ....................3 GENERAL ..........................3 USAGE ..........................3 MONITOR ............................ 5 MAIN ............................ 5 TUBE............................. 7 CONTROL ..........................7 INFO ............................8 MAINTENANCE ........................ -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS GENERAL Every user must become acquainted with the machine’s safety and operating instructions and obey them. In addition to the manual, one must act according to the regulations and laws of the country and local work safety authorities. Use of the machine for tasks other than which it was designed for is at user’s own responsibility. - Page 5 Exceeding the given performance values is forbidden. All the safety- and warning signs on the machine must be legible and intact. Always shut down the engine when exiting the cabin of the vehicle and empty possible pressure accumulators according to the vehicle manufacturers’ instructions. This way you avoid unintentional movement of the equipment.
-
Page 6: Introduction And Usage
2 INTRODUCTION AND USAGE GENERAL Risutec TK-120B is meant to be attached to an excavator. To use the machine a ½ inch pressure line and 5/8 inch tank line are needed. Voltage 24 V unless agreed otherwise. The equipment can only be installed by a professional mechanic. - Page 7 Mounding with plate: The plate is set peak first to the ground and pulled along the surface about 10 cm deep. The mineral ground must be revealed. The pulled ground is turned over the untouched ground leaving mineral ground on top. The machine is moved lightly on top of the formed mound and the seedling is planted.
-
Page 8: Monitor
3 MONITOR MAIN Logo Risutec INFO = Opens Risutec Oy’s (manufacturer) contact information page Circle symbol = Adjusts the pressure of the feet, short cut Plant in tube = Blue light is on when the seedling has passed the light sensor in the planting tube Next seedling = moves the seedling to a next place in the cassette and and drops the seedling Tube = opens tube’s manual controlling page... - Page 9 Red warning sign = Hydraulic pressure filter is blocked 1 = how many seedlings have been planted after the ”new round” button was pushed. Valvula aire = Gives an air pulse to move the seedling. Is used in case the seedling isn’t sucked out of the cassette for some reason.
-
Page 10: Tube
4 Update the program!= The automation of the planting machine’s program will only be switched on after the manufacturer has been connected to the machine and checked the program. Contact the manufacturer after 100 hours of use! Green long bar= Feet rise up, planting done Red long bar= The lid of the planting tube is closing TUBE Tube up = Planting tube up... -
Page 11: Info
INFO The program’s version number can be found on this page. When asking for an update the manufacturer needs the program type written in blue. A good way to do this is to send a photo. Pressing LOGS opens a log page where all the planted seedlings and total time can be found. -
Page 12: Maintenance
MAINTENANCE 1-4 numbers= Pressing these buttons removes the notifications from the main screen. Notice that pressing #4 won’t switch the automation on. That requires remote access with the manufacturer. Manual= opens the manual Hydraulics= opens hydraulic chart Electric= opens electric chart Spare= opens spare parts list... -
Page 13: Adjusting
ADJUSTING PAGES 3.6.1 MAIN Info= opens system modules Measure= opens the condition of sensors, valves and incoming wires page Adjust= opens adjust page Preferences= monitor adjusting, language 3.6.2 INFO Modules= shows information about the modules Logs= shows past history (program) -
Page 14: Measure
3.6.3 MEASURE General: True= active, in use False= not connected DIN input= Operation of switches and sensors DOUT output= electrical operation of on/off valves COUT output= electrical operation of proportional valves COUT/DOUT= the mA value of the electrical propotional outputs using on/off valves MD4-5= operation of the monitor, main computer... - Page 15 XA2(1)= Operation of Modul XA2 toiminta, no1 adress resistor G2= operation of a separate internet modem G11= operation of an internet modem used by phone DIN G2 modem= If true, the separate modem is connected DIN light sensor= Tells the operation of the light sensor DIN Main Filter= If true, the pressure filter has blocked and symbol on the screen is active DIN planting order= If true when pressing the planting command, button is working...
- Page 16 Feet light= Status of the power supply for the feet light Flushing pump= Status of the power of the flushing pump Flushing pump valve= Status of the power of the flushing pump’s three way valve. Has to be ”true” if pump is active and water isn’t run. Fertilizer pump valve= Status of the fertilizer pump Fertilizer pump valve= Status of the fertilizer pump’s three way valve Has to be ”true”...
- Page 17 COUT Feet pressure mA= The voltage of the proportional valve when the valve is active. COUT Main Flow ask mA= The voltage of the proportional valve for flow request...
- Page 18 VRefA= reference voltage should be value 5. VBB= main voltage...
-
Page 19: Adjust
MDGN= signal strenght ADJUST Planting depth ms= Planting depth is adjusted in milliseconds, two preselected adjustments Sealing feet pressure%= Pressure of the feet Sealing feet depth= Depth of feet, adjusted in milliseconds... - Page 20 Tube door delay ms= Closing time of the tube’s lid. Defines the speed of the planting circle. If this is too fast, a planted seedling might be lifted off when lifting the machine. Watering ms= Amount of water, parameter ms. The amount is checked by measuring the water for example in a bucket.
- Page 22 EXAMPE OF ADJUSTING VALUES Select what needs to be adjusted...
-
Page 23: Modems
Click When adjusted, leave screen touching ✓ or X. If ✓, you accept your adjusted measure! 4 MODEMS... -
Page 24: G2/G3 Modem
G2/G3 MODEM You can get internet connection with G2 modem. Risutec can adjust your machine with Internet connection. Works with G2, 3G and 4G connections. The SIM-card must be 15 mm*25 mm and suitable for phone calls and data transfer! (only Internet-data-transfer card won´t work). -
Page 25: Maintenance
NOTE! WHILE DOING MAINTENANCE ON SKB-180, TURN THE CARRIER ENGINE OFF! 7 WARRANTY The products of Risutec Oy are given a 6 months warranty during which we answer for all raw material and manufacturing faults. The warranty starts from the date it has been delivered to the client The warranty doesn’t include manufacturer’s possible repair visits nor travel or...
