Summary of Contents for HYVE Little Farm LF-ONE
- Page 1 LF-ONE Assembly Guide...
- Page 2 The Step-by-Step Guide to Assemble Your New LF-ONE This manual is your guide to preparing and assembling your new "Little Farm" LF-ONE unit. Inside you’ll find step-by-step instructions to make sure you assemble your unit correctly. The only tools you will need are a Philips head screwdriver and wrench, both of which are included in the kit. We’ve also included extra screws just in case you should happen to drop or misplace one.
-
Page 3: System Contents
Screwdriver (x 1) System Contents Wrench (x 1) Screws S1 5x8mm (x 28) Screws S2 4x10mm (x 8) Screws S3 3x12mm (x 4) Screws S4 4x16mm (x 6) Screws S5 6x16mm (x 6) Screws S6 4x10mm (x 2) Screws S7 4x30mm (x 2) Arch base (x 2) Light brackets (x 6) Drain pipe (x 1) - Page 4 Take out posts A1 (x1) and B1 (x3), and the first level frame (F1). Take off the gray footers (plastic stoppers) at the bottom of the posts, and insert the posts into the four molded openings in the base-level frame (F1).
- Page 5 Take four S1 screws and partially screw them into the holes on the insides at the tops of the posts. Frame 3 (F3) will sit on top of the four posts (A1 + B1 x3) – the plastic corner molds will fit onto the tops of the posts.
- Page 6 Take A2 (with the hoses-end down) and slide the hoses into the top of A1. Slide both hoses down A1 and pull them out through the lowest cut-out on the inside of A1, between F2 and F1. You should leave at least approximately 16-18”...
- Page 7 On the short lengths of the frame (F4) there are screw holes where the arch bases go. Install the arch bas- es on both sides of F4 by attaching them with two S2 screws each. Note: The arch bases can go on either side – they are interchangeable. Attach A3 and B3 poles to F5 arch cross-piece.
- Page 8 Place the L1 tray on the bottom rack. Tip: In order to get the tray into the rack, slide it in at a 45° angle. Once one end of the tray is in about half way, rotate the tray the rest of the way into the rack. Note: There is an online video for further visual explanation and assistance on loading, and unload- ing, trays.
- Page 9 On the right (A posts) side of the unit, install the larger set of pipe clamps on the sides of F2, F3, and F4 in the pre-set screw holes with S4 screws. Attaching the wire conduit (PVC pipe with cables inside): Place the pump into L1.
- Page 10 Take the light fixtures out of their box and partially screw S5 screws into the ends of the fixtures. Mount the light fixtures to the light brackets already attached under each frame level (F3, F4, F5) by hooking the S5 screws to the brackets. Make sure the cables on the light fixtures are next to the cables coming out of the conduit (i.e.
- Page 11 Follow labels on cables plus the diagram on the control box in order to match and correctly connect cor- responding cables. When connecting cables, look for, and line up, arrows on the outside of connectors. Starting from the top of the unit: Connect LED3 to cable from conduit Connect cable with "L1, L2"...
- Page 12 • Follow nutrient mixing instructions closely. Do not overmix nutrients or you could jeopordize crop growth. • Thoroughly clean unit after each grow cycle. • For best results use only SONARAY LED horticulture (grow) lighting fixtures and HYVE supplies and nutrients with the LF- ONE system. www.growhyve.com...
