BEAR

INSTRUCTION MANUAL

ISSUE E

Table of Contents

Need help?

Do you have a question about the BR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for RJH FINISHING SYSTEMS BR Series

Page 2 And meets the Essential Health and Safety Requirements of Machinery Directive 2006/42/EC and subsequent amendments. Electrical control and its Components are in accordance with the Low Voltage (2006/95/EC) and EMC (2004/108/EC) Directives. Signed by: J.R.Gathercole C.Eng Engineering Director For and on behalf of RJH Finishing Systems Ltd.
Page 3: Table Of Contents
CONTENTS 1. Safe Handling & Installation 2. Safety 3. Machine Operation 4. Maintenance 5. Risk Assessment 6. Troubleshooting Appendix 1. Recommended Spare Parts 2. Machine Footprint 3. Cutting Oil Data Sheet 4. Contact Details Due to a policy of continuous improvement, your machine may differ slightly to the exhibits shown in this manual...
Page 4: Safe Handling & Installation
SECTION ONE SAFE HANDLING & INSTALLATION 1.1 GENERAL DESCRIPTION These robust tool grinders come with an integral force fed re-circulatory coolant system, filter and oil reservoir. They are supplied with grinding wheels fitted as standard and are therefore ready to use once installation has been completed. NOTE: A can of grinding wheel oil is supplied with the compliments of RJH Finishing Systems Ltd.
Page 5 SECTION ONE SAFE HANDLING & INSTALLATION 6. Slide the machine off the Fork 5. With the machine sat stable Lift extensions onto the ground. on the Fork Lift extensions – lower to the ground. PLEASE NOTE!!! For protection during transit certain components may have been packed separately around the base of the machine.
Page 6 SECTION ONE SAFE HANDLING & INSTALLATION Position the machine so that it does not cause obstruction in use. The machine must be securely bolted through the holes provided using proprietary bolts (Para-bolts/Raw-bolts) with ∅10mm and 60mm length. Access is gained by removing the two base covers as shown.
Page 7: Safety
SECTION TWO SAFETY 2.1 SAFETY FEATURES These tool grinders are supplied in accordance with the European Machinery Directive 2006/42/EC and subsequent amendments. 2.2 STANDARD SAFETY FEATURES  No volt overload push button starter, which will stop the machine if the motor becomes overloaded or if a power failure is incurred.
Page 8 SECTION TWO SAFETY 2.7 SAFE WORKING PRACTICES  Bear machines have been designed and manufactured to provide many years reliable service as a tool grinder. Use for any other purpose may lead to personal injury and/or damage to the machine. ...
Page 9: Machine Operation
SECTION THREE MACHINE OPERATION 3.1 SHARPENING A CHISEL/PLANE BLADE  Ensure that every operator has been instructed in the use of all the machine controls.  Insert the swivel arm into the inspection position Fig 1.  Slacken the black knurled knob in the swivel arm and insert the blade to be sharpened, allowing enough protrusion of the blade to ensure that the tool carrier is clear of the grinding wheel.
Page 10 SECTION THREE MACHINE OPERATION 3.3 CONE WHEEL – BEAR2 MODELS ONLY  The cone wheel is used to remove any burrs formed on the inner face of a gouge after sharpening.  Adjust the height of the work rest to the required position. ...
Page 11: Maintenance
SECTION FOUR MAINTENANCE 4.1 GENERAL  All machines in this family are relatively simple and need little attention by way of maintenance.  The machine is fitted with sealed for life bearings and will require no further lubrication.  It is recommended that any dust/debris is periodically cleaned off. ...
Page 12 SECTION FOUR MAINTENANCE  Chipped or damaged wheels should be replaced immediately.  If a grinding wheel is to cut properly it must run true and not be ‘loaded’ or ‘glazed’. Loading is when the porous structure of the wheel becomes clogged with work piece material.
Page 13 SECTION FOUR MAINTENANCE 4.8 WHEEL CHANGE  Grinding wheels MUST be changed by suitably trained personnel and in accordance with the Abrasive Wheels Regulations.  Isolate/disconnect the power supply.  Remove the nut on the spindle and take off the wheel with the clamp plates. ...
Page 14: 5.1 Risk Assessment
RISK ASSESSMENT 5.1 RISK ASSESSMENT Bear machines have been developed from machines that RJH Finishing Systems Ltd have supplied into the market place for many years and have an excellent safety pedigree. However, like all machines of this type they can be dangerous if used carelessly or incorrectly.
Page 15 SECTION FIVE RISK ASSESSMENT EJECTION OF PARTS/COMPONENTS is present with all grinding processes. Avoid applying excessive pressure or pressing sharp objects into the wheel as this will increase the risk of ejection and can result in wheel damage or even breakage. LOW RISK VIBRATION caused by the operation will be transmitted to the operator’s arm(s) and in extreme cases can lead to Hand Arm Vibration Syndrome.
Page 16: Troubleshooting
SECTION SIX TROUBLESHOOTING SYMPTOM CHECK ACTION Machine will not start Mains On Switch on Isolator Emergency Stop Release ‘E’ Stop Control Overloads Requires Electrician Control Fuses Requires Electrician No oil feed Pipes Clear blockages Control valve Open if closed Tank oil level Top up if necessary Poor Grinding Wheel selection...
Page 17: Recommended Spare Parts
APPENDIX ONE RECOMMENDED SPARE PARTS PART N DESCRIPTION 7242-001 START BUTTON 7242-002 STOP BUTTON 8625-001 OIL (5 LITRE) BRFILTER FILTER BLOCK H BRA80 GRINDING WHEEL O BRRAO RADIUS ARM BER-1-0071 CHISEL ARM ASSEMBLY H BRA80/17 CONE WHEEL 7373-164 NON RETURN VALVE N100024 PUMP BER-1-0022...
Page 18: Machine Footprint
APPENDIX TWO MACHINE FOOTPRINT BEAR1 TOOL GRINDER...
Page 19 APPENDIX TWO MACHINE FOOTPRINT BEAR2 TOOL GRINDER Front Side...
Page 20: Cutting Oil Data Sheet
APPENDIX THREE CUTTING OIL DATA SHEET Health & Safety Data Sheet NEAT CUTTING OILS PENNINE LUBRICANTS UNIT 35, NUTWOOD TRADING ESTATE LIMESTONE COTTAGE LANE SHEFFIELD S6 1NL TEL: 0114 2852987 FAX: 0114 2852988 PRODUCT NAME: METACUT 22, 32, T, G, H, AL, CF, BC, HONING FLUID, FORM GRINDING OIL, COMBICUT FG PRODUCT CODE: AF0, AF1, AF2, AF3, AF4, AF5, AF7, AF9, AES, AXX1 APPLICATION:...
Page 21 APPENDIX THREE CUTTING OIL DATA SHEET Skin: Wear oil impervious gloves in cases of prolonged or repeated skin contact. Change heavily contaminated clothing and overalls as soon as possible. Inhalation: Respiratory protection is not normally required. Industrial Hygiene: Wash hands after use, before eating, drinking or smoking and before and after using the toilet.
Page 22 APPENDIX THREE CUTTING OIL DATA SHEET EH 40 Occupational Exposure Limits. EH 58 The Carcinogenicity of Mineral Oils. EH 62 Metalworking Fluids - Health Precautions. SHW 397 Effects of Mineral Oil on the Skin...
Page 23 APPENDIX THREE CUTTING OIL DATA SHEET Product Data Sheet HONING FLUID (NEAT CUTTING OIL) Product Code: AF3. Product Description Pennine Honing Fluid is manufactured from highly refined mineral oils treated with active extreme pressure and lubricity improving agents. It is used primarily in all honing applications including power stroke honing where cooling units may be utilised.
Page 24: Contact Details
APPENDIX FOUR CONTACT DETAILS ARTILLERY STREET HECKMONDWIKE WEST YORKSHIRE WF16 0NR TEL: +44 (0)1924 402490 FAX: +44 (0)1924 404635 E-MAIL: sales@rjhfinishing.co.uk WEB: www.rjhfinishing.co.uk...
