User Guide of HD Endoscope
MAIN &ACCESSORIES PART LIST
1. 2.4"color LCD monitor
2. Power on/off button
3. Brightness up button (rotation)
4. Brightness down button(zoom)
5. Battery compartment (4 x 1.5V AA)
6. Flexible tube
7. Magnet
8. Mirror
9. Hook
Information About The Product
The product is designed as a remote inspection device. It can be
used to look into tight spots and beam back real-time video to its LCD
monitor. Typical applications might include HVAC, termite and other
insect or building inspections, cable routing, automotive/boat/aircraft
inspections etc.
Before First Use
Advertisement
Table of Contents
Summary of Contents for blick-store W3-CMP2812
- Page 1 User Guide of HD Endoscope MAIN &ACCESSORIES PART LIST 1. 2.4”color LCD monitor 2. Power on/off button 3. Brightness up button (rotation) 4. Brightness down button(zoom) 5. Battery compartment (4 x 1.5V AA) 6. Flexible tube 7. Magnet 8. Mirror 9.
- Page 2 Remove all packaging materials and check the scope of delivery for completeness Please install the batteries before using the product, choose the accessory according to the actual situation. Steps of installation as following: To Install Batteries 1.Remove cover 2.Insert 4 new AA (1.5 V) batteries into the proper slots in the battery compartment.
- Page 3 Rotating the display Press the right button for 1.5 seconds to rotate the display by 180˚ Zoom function Press the left button for 1.5 seconds to be increased in size from x1, x 1.5 to x2.0 ACCESSORIES To attach an accessory: 1.
- Page 4 Specification 2.4” TFT resolution 960 x 240 Pixels Lens sensor resolution 640 x 480 Pixels Display 2.4” TFT LCD Diameter of camera head 8.0 mm White comparison n Automatic Exposure to light Automatic 4 LEDs, white Camera illumination 4 X 1.5V AA Batteries(not included) Power by 54 ∘...
