Rolling Finisher
Model 3500
Owner's Manual
Installation and Parts Manual
Our Tradition is Quality Driven and Field Proven
Manual # MAN-RF-NA-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Remlinger 3500

  • Page 1 Rolling Finisher Model 3500 Owner’s Manual Installation and Parts Manual Our Tradition is Quality Driven and Field Proven   Manual # MAN-RF-NA-001...

  • Page 2: Table Of Contents

    Table of Contents   OPERATING TIPS ..........................4   SAFETY ..............................5   PRE-ASSEMBLY INSTRUCTIONS ....................... 5   RECOMMENDED TORQUE SPECIFICATIONS ................... 5   ROLLING FINISHER - MAINTAINING ....................6   ..........................6 DJUSTING THE LEVIS EIGHT   ..........................6 DJUSTING THE ITCH ENGTH...
  • Page 3   LAYOUT – 16’ BASE (STANDARD) ....................29   16’4” H 16’ B ..........................29 ARROW ON A   LAYOUT – 16’ BASE ........................... 30   17’10” H 16’ B ..........................30 ARROW ON A   LAYOUT – 3’ WING ..........................31  ...

  • Page 4: Operating Tips

    Operating Tips • Read and understand this manual before operating your Rolling Finisher (RF), please call with any questions before operating. Damage may occur if cart is improperly used or operated. • Always place the front roller in the aggressive mode (position A). The rear roller can be set in either aggressive or passive mode.

  • Page 5: Safety

    Safety 1. Never attempt to operate or adjust the harrow without reading this manual. 2. Never allow anyone to ride on the harrow or other attachments. 3. Drive slowly over rough ground. 4. Always slow down when turning. 5. Always support the Rolling Finisher when mounting or working on the cart or other attachments.

  • Page 6: Rolling Finisher - Maintaining

    Rolling Finisher - Maintaining Adjusting the Clevis Height Major – Remove the two 3/4”-10 x 6” hex cap bolts and pull the telescoping hitch out and rotate 180°. Replace the 3/4” bolts and tighten. The clevis will also have to be rotated. Minor –...

  • Page 7: Single Bar Harrow - Maintaining

    Single Bar Harrow - Maintaining Adjusting Harrow Height The harrow mounting arm height is fixed. The harrow can be angled back to adjust the depth the teeth penetrate the soil. Adjusting Spring Tension Use the 5/16” snap pear link to adjust the chain to the desired length (remove any twist in the chain).

  • Page 8: Double Roller Harrow - Maintaining

    Double Roller Harrow - Maintaining Adjusting the Roller Height Front Roller – The front roller has three height adjustments. This will change the height relationship between the two rollers. Loosen the two 5/8”-11 x 4 1/2”, remove the front bolt. Adjust to desired height and replace the bolt.

  • Page 9: Rolling Finisher - Assembly

    Rolling Finisher - Assembly Base / Axle Instructions (Diagram page 15) 1. The first step is to identify the proper parts to assemble this section of the cart. Set the base on saw horses or similar supports. Note: The axle ears face the front of the cart. 2.

  • Page 10: Base / A-Frame Instructions (Diagram

    Base / A-Frame Instructions (Diagram page 17) 7. Next, the “A” frame can be attached to the base. Use (12) 5/8”-11 x 1 3/4” hex cap bolts, lock washers, and nuts to attach the “A” frame to the base. The “A” frame matches up to plates on the base. The short brace on the rear of the A-frame will be located the bottom when mounted properly.

  • Page 11: Optional Gage Wheel Instructions (Diagram

    Optional Gage Wheel Instructions (Diagram page 21) 14. Next, bolt the gauge wheel mount assembly and back plate assembly to wing extension. Use (4) 5/8”-11 x 3 1/2” hex cap bolts, lock washers and nuts. Location for gauge wheel mounting varies from cart to cart. The following are maximum distances from the center of the wing hinge pin.

  • Page 12: Single Bar Harrow - Mounting

    Single Bar Harrow - Mounting 1 Bar Harrow Instructions (Diagram page 23) 1. Refer to the harrow layout section of this manual for proper location. 2. Place the zinc coated bushings in the harrow arms and attach the arms in the proper holes on the frame.

  • Page 13: Double Roller Harrow - Mounting

    Double Roller Harrow - Mounting Double Roller Harrow Instructions (Diagram page 25) Roller harrows are not recommended in rocky conditions! 1. The roller harrow sections have the bearings factory installed. Refer to the harrow layout section of this manual for proper harrow section location.

  • Page 14: Parts Description - Base / Axle

    Parts Description - Base / Axle Item Part Number Description RF-1003 Base Axle Assembly RF-1039 Jackstand Mount Weldment RF-1040 Jackstand Riser Weldment RF-1054 Flat Fold Wing Stand RF-1050 Wing Stand Weldment (12ft & 14ft Base) RF-1051 Stack Fold Wing Stand (16ft Base) RF-1013-AS Axle Hinge Pin Assembly w/ 1"-14 Hex Slotted Nut &...

  • Page 15: Parts Diagram - Base / Axle

    Parts Description - Base / Axle Remove Pin & Chain From Jackstand Attach to Jackstand Mount Decal- "FEMA" Both Ends Reflector 2 x 9 Yellow Front Side Only Reflector Serial # 2 x 9 Red Location Backside Only Decal- "Caution" See Lower LH Corner Transport Lock 1.00...

  • Page 16: Parts Description - Base / A-Frame

    Parts Description - Base / Axle Item Part Number Description RF-1085 12ft Base Weldment RF-1088 14ft Base Weldment RF-1090 16ft Base Weldment RF-1086 12ft A-Frame Weldment RF-1089 14ft & 16ft A-Frame Weldment RF-1091 12ft Base HD Telescoping Hitch Weldment RF-1087 14ft &...

  • Page 17: Parts Diagram - Base / A-Frame

    Parts Description - Base / A-Frame Decal- "3500 Rolling Finisher" Both Sides Reflector- 2 x 9 Yellow Both Sides Decal- "Caution Transport Hazard" Both Sides Reflector 2 x 9 Yellow Both Sides Light Kit SMV Sign Red Lens Outside Rear...

  • Page 18: Parts Description - Wing

    Parts Description – Wing Item No. Part No. Part Name / Description RF-1004 LH 6ft Wing Assembly RF-1017 RH 6ft Wing Assembly RF-1031 RH 5ft Wing Assembly RF-1032 LH 5ft Wing Assembly RF-1033 RH 4ft Wing Assembly RF-1034 LH 4ft Wing Assembly RF-1035 RH 3ft Wing Assembly RF-1036...

  • Page 20: Parts Description - Wing Extension / Gage Wheel

    Parts Description – Wing Extension / Gage Wheel Item No. Part No. Part Name / Description Wing Assembly RF-1042 LH 4ft Wing Extension Assembly (shown) RF-1043 LH 4.5ft Wing Extension Assembly RF-1044 LH 5ft Wing Extension Assembly RF-1045 RH 4ft Wing Extension Assembly RF-1046 RH 4.5ft Wing Extension Assembly RF-1047...

  • Page 22: Parts Description - Single Bar Harrow

    Parts Description – Single Bar Harrow Item No. Part No. Part Name / Description RF-1022 Harrow Mount Bar Assembly 3/8”-16 x 2 1/2” Gr.5 Bolt w/ Locknut RF-0107 Spacer RF-0112 1/4” Proof Adjustment Chain (11 Link) RF-0111 Tension Spring RTB-0035 3 1/2’...

  • Page 24: Parts Description - Double Roller Harrow

    Parts Diagram - Base / Axle Item Part Number Description RF-0237 Upper Spring Pivot Block F-00003 Close Whl Ten Spring 5/8"-11 UNC x 4" Gr.5 Bolt w/ Locknut RF-1093 Top Spring Lower Mount Weldment RF-0107 Spacer RF-1015 Roller Spring Assy RF-1014 Roller Arm Assembly 1/2"-13 UNC x 3 1/2"...

  • Page 25: Parts Diagram - Double Roller Harrow

    Parts Diagram - Double Roller Harrow Snug 1"-8 Hex Cap Bolt on one Side. Fill "Gap" with 1" flatwahser on other side as needed. Do to frame inconsistency the flatwahser may or may not be needed. Do not Force in the Flatwasher...

  • Page 43: Appendix

    Appendix Hose Diagrams Hose-001 Hose Diagram - 12’ Base only Hose-002 Hose Diagram - 12’ Base Flatfold with Gage Wheels Hose-003 Hose Diagram - 12’ Base Stackfold with Gage Wheels Hose-004 Hose Diagram - 14’ Base only Hose-005 Hose Diagram - 14’ Base Flatfold with Gage Wheels Hose-006 Hose Diagram - 14’...

  • Page 53: Registration Information

    This warranty does not obligate Remlinger Manufacturing to cover cost of labor to replace these parts. This warranty is in effect for 1 year after purchase. Remlinger Manufacturing warrants its own products only, and cannot be responsible for damages to equipment on which it is attached or mounted.
  • Page 54 Notes...

  • Page 55: Registration Form

    1 Bar Harrow None Angled Tooth Straight Tooth Spring Tine Dealer Purchased From Name: Address: City: State: Zip: Mail To: Remlinger Manufacturing Company, Inc. 16394 U.S. 224 Kalida, OH 45853 Fax To: 1-419-532-2244 Thank you for purchasing Remlinger tillage equipment.
  • Page 56 Notes...
  • Page 57 Notes...
  • Page 58                             Remlinger Manufacturing  16394 US 224  PO Box 299  Kalida, OH 45853    Toll Free 1‐800‐537‐7370  Phone (419) 532‐3647  Fax (419) 532‐2244    www.remlingermfg.com ...
