Page 1 Dual Pneumatic READ & SAVE THESE INSTRUCTIONS Atomizing System T R I O N | w w w . t r i o n i a q . c o m ®...
Page 2: Table Of Contents
Following the steps in the Maintenance section will ensure this. Please read and understand this section. The system is designed for direct humidification of an area. DO NOT install in duct or air handling systems. Contact TRION for information on our Herrmidicool system if direct humidification is not possible.
Page 3: Warranty
TRION Factory Repair Department for complete reconditioning without charge to the user for parts or labor. Incidental expenses such as cost of transporting the part/unit to TRION shall be borne by the user. Upon completion of the reconditioning, the humidifier will be returned at no cost to the user.
Page 4: System Operations
I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l II. SYSTEM OPERATION The Dual Pneumatic atomizing system operates with air and water under pressure - air at approximately 30 psi and water at approximately 32 - 38 psi.
Page 5 The standard Dual Pneumatic atomizing system requires ON-OFF humidistats for operation. Controls may be provided by others, in which case, consultation with TRION is essential to ensure proper operation. Several control options are available from TRION. standard system consists of a control humidistat and high- limit (safety) humidistat.
Page 6 I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l Figure 4. AH-1020 - Air Control Section For System Capacities up to 240 lbs./hr.
Page 7 I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l 1 /2'' NPT FEMALE DRAIN LOOP CONNECTION.
Page 8: System Layout/Installation Guidelines
Heads should be located so that the discharge is away Do not add parts to these assemblies without permis- from personnel to ensure that droplets and evaporative sion from TRION. Head assemblies for systems using cooling will not cause discomfort. demineralized water supplies will have the same com- Do not locate heads in such a manner that they ponents as shown on this page.
Page 9 I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l Control Sections Control sections should be placed where they are easily accessible and protected from traffic damage.
Page 10: Start-Up Procedures
For longer or shorter lengths of pipe,the friction loss is it will be necessary to supply a water pressure booster proportional to the length. pump or bladder tank for the system. Consult TRION for assistance in sizing pump and tank. Example: AIR LINE 500 ft.
Page 11: Operating Instructions
I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l Adjust air pressure regulator of control section to 30 psi. fittings, connections, valves, control sections, and head Slowly move the CONTROL humidistat to a higher RH assemblies.
Page 12: Maintenance Instructions
I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l Each Dual Pneumatic Atomizing System is custom designed OUTSIDE of the heads as required to keep the spray for each application to maintain the level of relative humidity pattern adequate.
Page 13 I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l Replace parts as required. wiring and supply lines.
Page 14 I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l be maintained, additional humidification equipment will now be required. Call your TRION/HERRMIDIFIER representative. Exhaust, make-up air, or cooling equipment may have been added to the area since the system was designed.
Page 15: Parts List
I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l IX. PARTS LIST Brass Nozzle Consists of: SS Nozzle Consists of: Part # Description...
Page 16: Typical Layouts
I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l X. TYPICAL LAYOUTS D u a l P n e u m a t i c w w w.
Page 17: Wiring Diagram
I n s t a l l a t i o n , O p e r a t i o n & S e r v i c e M a n u a l XI. WIRING DIAGRAMS w w w. t r i o n i a q . c o m D u a l P n e u m a t i c...
