Slazenger S000154 Assembly, Installation, Care, Maintenance, And Use Instructions

10/12 ft trampoline combo
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Slazenger is a trade mark of Pacific Brands and is used under licence by Action Sports Equipment Ltd.
72 Silverwater Rd, Silverwater, NSW, Australia, 2128
Parts & Service Enquiries: 1800 465 070 (Australia); 09 477 6020 (New Zealand)
Or email:
service@actionspares.com.au
Sales Enquiries: 1800 777 137 (Australia); 09 477 6020 (New Zealand)
Model: S000154 - 10FT TRAMPOLINE COMBO
Model: S000155 – 12FT TRAMPOLINE COMBO
Assembly, Installation, Care, Maintenance and Use Instructions
Manual depicts typical installation – your model may differ from illustrations in terms of the number of legs
Please read and retain this manual as it will assist with identification for parts and service.
Read these materials prior to assembling and using of this product
These trampolines are subject to 100kgs (10ft) & 150kgs (12ft) weight limit.
Usage of these trampolines is limited to persons weighing less than weights specified above.
Do not allow more than one person on the trampoline at a time.
Do not allow young children to use unless supervised by an adult.
Action Sports has reproduced extracts from AS4989-2006 Clauses 3.2.1 – 3.2.2; 3.3.1.2 & 3.3.2.1 and
Appendices A & B. These have been reproduced with permission from SAI Global under licence 1004-C016.
The relevant standard may be purchased online at www.saiglobal.com.
@ACTION SPORTS EQUIPMENT PTY LIMITED – www.actionsports.com.au
Action Sports Equipment Pty Ltd.
(Australia) or
Or visit our website: www.actionsports.com.au
on the unit and also the number of enclosure poles.
IMPORTANT
THIS PRODUCT IS FOR DOMESTIC USE ONLY.
- Warning -
orders@bernsport.co.nz
(New Zealand)
Page: 1
