USER MANUAL OF WIFI
IMPORTANT NOTE:
Read the manual carefully before connecting your
Smart kit(Wireless module). Make sure to save this
manual for future reference.
DECLARATION OF CONFORMITY
Hereby, we declare that this AC is in compliance
with the essential requirements and other
relevant provisions of Directive 2014/53/EU.
A copy of the full DoC is attached.
HU10533

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSK102 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for mundoclima OSK102

Summary of Contents for mundoclima OSK102

  • Page 1 USER MANUAL OF WIFI IMPORTANT NOTE: Read the manual carefully before connecting your Smart kit(Wireless module). Make sure to save this manual for future reference. DECLARATION OF CONFORMITY Hereby, we declare that this AC is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

  • Page 2: Specification

    SPECIFICATION Model: OSK102 Standard: IEEE 802. 11b/g/n Antenna Type: Printed PCB Antenna Frequency : WLAN 2400~2483.5 MHz Operation Temperature:0 C~45 C/32 F~113 F Operation Humidity: 10%~85% Power Input: DC 5V/300mA Maximum Transmitted Power: 19.8dBm Max PRECAUTIONS Applicable system: iOS, Android.

  • Page 3: Download And Install App

    DOWNLOAD AND INSTALL APP CAUTION: The following QR Code is only available for downloading APP. It is totally different with the QR code packed with unit. Android Android Phone users: scan Android QR code or go to google play, search ‘NetHome Plus” app and download it. iOS users: scan iOS QR code or go to APP Store, search ‘NetHome Plus”...

  • Page 4: User Registration

    USER REGISTRATION Please ensure your mobile device is connected to Wireless router. Also, the Wireless router has already connected to Internet before doing user registration and network configuration. It is better to log in your email box and active your registration account by clicking link in case you forget the password.

  • Page 5: Network Configuration

    NETWORK CONFIGURATION Cautions It is necessary to forget any other around network and make sure the Android or i OS device just connect to the Wireless network you want to configure. Make sure the Android or i OS device Wireless function works well and can be connected back to your original Wireless network automatically.
  • Page 6 7 Follow the above steps to enter “AP” mode. 8:08 AM QR Code Align the QR code within the fram e to scan 9 Choose the “ Scan the 8 Choose the network QR code ” method. configuration method.
  • Page 7 Or choose the “Manual Please enter password Setup” method.
  • Page 8 Network configuration is successful Configuration Success, you can see the device on the list.
  • Page 9 Using iOS device to do network configuration Make sure your mobile device has already been connect to the Wireless network which you want to use. Also, you need to forget other irrelevant Wireless network in case it influences your configuration process. Activate the AP mode (Read the WIRELESS MODE IN OWNER'S MANUAL for detailed operations.).
  • Page 10 7 Follow the above steps to enter “AP” mode. Connect to the Wireless Please enter password network.
  • Page 11 Network configuration is successful...
  • Page 12 NOTE: When finishing network configuration, APP will display success cue words on the screen. Due to different internet environment, it is possible that the device status still display “offline” . If this situation occurs, it is necessary to pull and refresh the device list on the APP and make sure the device status become “online”...
  • Page 13 HOW TO USE APP Please ensure both your mobile device and air conditioner are connected to the Internet before using app to control the air conditioner via internet, please follow the next steps: 2 Choose the air conditioner. 1 Click "Login "...
  • Page 14 Make sure the Bucket is not removed and place it in right position.
  • Page 15 From left to the right, these button means Power, Fan, Continuous, Auto Dehumidification, and Pump. 1. Power Press to turn on/off humidifier. 2. Fan mode Press Fan icon to activate high ,med(on some models),low fan speed. 3. Continuous mode Press Continuous icon to activate. Press again to deactivate. 4.

  • Page 16: Special Functions

    SPECIAL FUNCTIONS Including: Timer on, Timer off, NOTE: If the air conditioner do not support the above function, the function will be hided from the function list. Timer on/Timer off Weekly, user can make an appointment to turn on or off AC on specific time.
  • Page 17 Share Device The air conditioner can be controlled by multi-users at the same time by Share Device function. 1 Click " Share device " 2 Let the others to scan the displayed QR code. 3 Click " 4 Add the shared device. Add Share Device "...
  • Page 18 CAUTIONS: CONTAINS FC C ID: 2 AD QOMD N A1 5 CONTAINS IC : 1 257 5A-MD NA 15 T his d evice co mplies with Pa rt 1 5 o f the F CC R ules and In dustry Can ada's lice nce-exemp t RSSs. Operat ion is sub ject to the f ollow in g two con d ition s: (1) T his d evice may not cause int erferen ce;...
  • Page 19 Company will not be liable for any issues and problems caused by Internet, Wireless Router and Smart Devices. Please contact the original provider to get further help. NOTE: All the illustrations in the manual are for explanation purpose only. Your unit may be slightly different. The actual shape shall prevail.
  • Page 20 C/ PROVENZA 392 P2 08025 BARCELONA SPAIN (+34) 93 446 27 80 www.mundoclima.com...
