- Page 1 ORIGINAL INSTRUCTIONS 2018 MANUAL WELDING...
-
Page 2: Table Of Contents
MANUAL - KRAMER Technik MIG / MMA 185 Before using this product, read all instructions with understanding and keep it for future use TABLE OF CONTENTS SAFETY PRECAUTIONS SYMBOLS ................3 PURPOSE .......................... 6 DESCRIPTION OF THE DEVICE ........................6 TECHNICAL DATA .......... -
Page 3: Safety Precautions Symbols
MANUAL - KRAMER Technik MIG / MMA 185 LIST OF TABLES Table 1. Specifications ........................6 Table 2. Troubleshooting ....................15 1. SAFETY PRECAUTIONS SYMBOLS 1. SAFETY PRECAUTIONS SYMBOLS It is essential to read these signs and safety precautions to protect the health and life of their own and other people. - Page 4 MANUAL - KRAMER Technik MIG / MMA 185 Too long continuous operation may cause overheating. Wait until the device cool down. Follow the guidelines in the "efficiency and thermal protection." Damaged cylinders with technical gases can explode. The bottled gas is accumulated under high pressure.
- Page 5 MANUAL - KRAMER Technik MIG / MMA 185 ATTENTION! Heating test was carried out at ambient temperature and the duty cycle (ratio Load) at 40 Load) at 40 Load) at 40 C has been appointed by the simulations. C has been appointed by the simulations. C has been appointed by the simulations.
-
Page 6: Purpose
MANUAL - KRAMER Technik MIG / MMA 185 2. DESTINY 2. DESTINY KRAMER equipment technician MIG / MMA 185 for manual arc welding in the GMAW (Gas Metal Arc Welding) - MIG / MAG and MMA (Metal Manual Arc Welding). 3. -
Page 7: Operation
MANUAL - KRAMER Technik MIG / MMA 185 Unit nameplate: The accessories supplied with the device: 1. Source of electricity 1. Source of electricity 2. Torch MIG / MAG integrated device 2. Torch MIG / MAG integrated device 3. Cable to the common terminal 3. - Page 8 MANUAL - KRAMER Technik MIG / MMA 185 Front description KRAMER MIG / MAG 185 Front panel Figure 1. Warning LED thermal protection Adjusting dial wire feed speed LCD display Intensity control knob of welding current and voltage Mode switch MIG - MMA The integrated welding torch for MIG / MAG Socket positive polarity (+)
-
Page 9: Installing Spool With Welding Wire
MANUAL - KRAMER Technik MIG / MMA 185 B. COIL ASSEMBLY WITH welding wire B. COIL ASSEMBLY WITH welding wire Before mounting a spool of welding wire, please refer to the data contained in the table below: The maximum size of a spool of wire The diameter of the welding welding wire... -
Page 10: Installation Shielding Gas Bottle
MANUAL - KRAMER Technik MIG / MMA 185 The direction of rotation of the reel of welding wire Figure 2. Connections changes polarity (+) in the shielding gas welding (-) welding wire self-shielded FCAW INSTALLATION shielding gas bottle • Connect with semiautomatic bottle with a suitable cable. •... - Page 11 MANUAL - KRAMER Technik MIG / MMA 185 Figure 3. Back of the device Figure 3. Back of the device Switch ON / OFF warning sign nameplate Power cord Gas connection MIG / MAG Page 11 with 23 Page 11 with 23 Page 11 with 23 Page 11 with 23...
-
Page 12: Welding Process Mig / Mag
MANUAL - KRAMER Technik MIG / MMA 185 6. WELDING PROCESS MIG / MAG 6. WELDING PROCESS MIG / MAG Arc welding shielding gases (indicated by MIG / MAG) is one of the most widely used process for producing weldments. Abbreviation MAG (metal active gas) includes in its description of the active shielding gases. -
Page 13: Current Operating Unit
MANUAL - KRAMER Technik MIG / MMA 185 Self-shielded Flux-Cored Welding Wire This is a method using samoosłonowego core wire for welding (all positions) of normal steel and high strength exceeding 510 MPa. Samoosłonowy wire can be used in welding processes single and multi-layer by using current sources of both flat and falling characteristics. -
Page 14: Maintenance
MANUAL - KRAMER Technik MIG / MMA 185 • Preventing surges Keep values i n the line supply voltage in the Table "Technical specifications". In normal operation, the automatic alignment circuit voltage ensures the maintenance of tension in the acceptable range. The supply voltage higher than the permissible value can damage the welding machine. -
Page 15: Troubleshooting
MANUAL - KRAMER Technik MIG / MMA 185 8. TROUBLESHOOTING 8. TROUBLESHOOTING Table 2. Troubleshooting Possible cause Solution Problem • Check whether the device is connected to the mains The device is not connected to the mains, The device does device does not receive •... -
Page 16: Electrical Scheme
Chief Inspector of Environmental Protection under the number: E0007441WZ and signed a contract with CCR REWEEE Recovery Organization Electrical and Electronic Equipment SA with its seat in Warsaw, ul. Transfer 4/49 (now RELECTRA CCR). Company entrusted with the duties incumbent on FACHOWIEC FHW Zenon Świętek to the collection of waste equipment electrical and electronic equipment. - Page 17 The content of this manual has been prepared by a team of engineers skilled in the art. Copying and distribution of the manual, in whole or in part, without the written consent of The skilled person is prohibited. MADE FOR: FHW FACHOWIEC Zenon Świętek Street. Stefanski 29, 61-415 Poznan www.fachowiec.com...
-
Page 18: Declaration Of Conformity
A person authorized to prepare and store technical documentation Zenon Świętek. Zenon Świętek Poznan, 11/04/2016 www.fachowiec.com Place and date of issue: Page 18 with 23 Page 18 with 23... - Page 19 WARNING - FAILURE! Before sending equipment use our SERVICE CENTER Before sending equipment use our SERVICE CENTER http://pomoc.fachowiec.com http://pomoc.fachowiec.com That allows technical support, contact our service to you and automated That allows technical support, contact our service to you and automated...
- Page 20 MANUAL - KRAMER Technik MIG / MMA 185 set Dz. Laws poz.827 2014 (as at 25 June 2014). effective from 25.12.2014r. set Dz. Laws poz.827 2014 (as at 25 June 2014). effective from 25.12.2014r. set Dz. Laws poz.827 2014 (as at 25 June 2014). effective from 25.12.2014r. 5.
- Page 21 6. breaking holograms WEBSITE ADDRESS One skilled FHW Zenon Świętek 60-169 Poznań ul Grunwaldzka 390 phone; + 48/61 66-18-152 e-mail: serwis@fachowiec.com e-mail: serwis@fachowiec.com important: In the case of unjustified complaint the applicant must bear the costs of transport and a review in accordance with the service price list.
- Page 22 MANUAL - KRAMER Technik MIG / MMA 185 release Date of Stamp and signature The scope of repairs date service adoption Page 22 with 23 Page 22 with 23 Page 22 with 23 Page 22 with 23...
-
Page 23: Notes
MANUAL - KRAMER Technik MIG / MMA 185 12. NOTES 12. NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
