Summary of Contents for Spicles SUB 1.0
- Page 1 INSTRUCTION MANUAL E-BIKES ENGLISH FREE YOUR CYCLIST SPIRIT...
-
Page 2: Table Of Contents
INDEX Introduction ................................2 Parts description ................................ 3 Daily checks ................................6 Battery charging ................................ 6 Charging tips ................................6 With the battery removed ............................. 6 When the battery is charging on the bike ......................6 Duration of charging .............................. 7 Warning about charging ............................ -
Page 3: Introduction
Introduction Welcome Thank you for purchasing e-bike from SPICLES. We take pride in bringing you a quality product that will offer you years of enjoyment. SPICLES e-bike is featured with, zero emission, battery powered, with stable performance and overall after-service. -
Page 4: Parts Description
Parts description SUB 1.0... - Page 5 BIGGEST...
- Page 6 TOWN-E...
-
Page 7: Daily Checks
Daily checks To ensure the safety, make the following functional checks before driving: 1. Normal operation of the light, brake and power cut system 2. Tire pressure (low pressure, will influence both autonomy and speed). 3. Wheel axel tightening. 4. Battery charging level 5. -
Page 8: Duration Of Charging
6. When in use, the charger should not be covered, to prevent overheating, damage, or fire. 7. The charger is only for indoor use. Please keep it in dry and ventilated place. 8. If you notice a strange smell coming from the charger, or it is too hot, please stop charging, and contact SPICLES Company. -
Page 9: Driving
Driving Minimum saddle height and the way to measure To adjust seat height, use quick release lever to free the seatpost and pull upwards or push downwards to reach desired height. Important tips while driving 1. In order to reduce consumption, increase autonomy, and extend the motors lifespan, use the pedals during the startups and climbs. -
Page 10: Saving Battery Power And Extending Your Range
Range Driving condition Surface 10Km 20Km 30Km 40Km Wind level：2-3 Flat Normal temperature：25℃ Normal load against wind level: 2-3 Flat normal temperature: 25℃ normal load degree of slope≤2 degree; wind level: 2- upslope/downslope 3 normal temperature: 25℃ normal load Power consumption of one time charge: ≤0.5kw.h Economical speed: 18km/h The load haul is related with road, road surface, times of start-up, times of braking, wind direction, Atmospheric temperature, air pressure in the tire and correct way of charging, please note this during driving. -
Page 11: Operation Explanations Lcd Screen
Operation explanations LCD screen SPICLES electric bicycles mount two types of LCD screens, very similar in operation: LCD-SW900 LCD-850-A LCD-SW900 operation ON/OFF the bike a. Press the battery ON/OFF button and battery power LED display to see the power capacity. -
Page 12: Lcd-850-A Operation
Reset ODO Long press for 5s to reset ODO. Change data in multi-function Area Shortly press to change data. Parameters setting Long press to start setting parameters, such as wheel size(inch), background luminance On the setting interface, shortly press , or to plus/minus value. - Page 13 5. ON/OFF Headlight Long press to turn ON/OFF Headlight 6. Reset ODO Long press for 5s to reset ODO. 7. Change data in multi-function Area Shortly press to change data. 8. Parameters setting Long press to start setting parameters, such as wheel size(inch), background luminance On the setting interface, shortly press , or...
-
Page 14: Basic Maintenance
Basic maintenance To ensure safe riding conditions you must properly maintain your bike. You should follow the basic guidelines below and see your certified local bike shop seasonally to ensure your bike is safe for using. Regular self-checks 1. Tightening and correct operation of both wheels, frame and front fork. 2. -
Page 15: Recommended Torque Values For Threaded Fasten
Recommended torque values for threaded fasten Parts Torque required (N.m) Handlebar Stem Saddle Seatpost Front wheel 16-25 Rear Wheel 25-35 B.B Parts 35-55 Wiring diagram with LCD display... -
Page 16: Useful Tips
Useful tips 1. This user manual should be used only to reference use and functions but should not be used as a reference for inspection. 2. The images shown may differ from the actual model to technical improvements. 3. We reserve the right to change the model without prior notice due to technical improvements. 4. -
Page 17: Safety Notes Before First Use
-Failure to wear a helmet when riding many result in serious injury or death. -Do not use this product with standard bicycle trailers, stands, or vehicle bicycle racks. Contact SPICLES to check if your equipment will work with the bicycle. - Page 18 -Any changes to the product not expressly approve by SPICLES could void warranty and care while riding. -Because electric bikes are heavier and faster than normal bicycles, they require extra caution and care while riding.
