Downee SPRINT GATE Install Manual

Solar double gates
Hide thumbs

Advertisement

Quick Links

Download this manual
09/01/16
All business
No bullsh*t
SPRINT GATE SOLAR
INSTALL
DOUBLE GATES
MANUAL
Read this manual before starting install
IMPORTANT

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPRINT GATE and is the answer not in the manual?

Questions and answers

Related Manuals for Downee SPRINT GATE

Summary of Contents for Downee SPRINT GATE

  • Page 1 09/01/16 All business No bullsh*t SPRINT GATE SOLAR INSTALL DOUBLE GATES MANUAL Read this manual before starting install IMPORTANT...
  • Page 2 Fed up with all the fluff found in manufacturer’s instructions? The backbone of Short Cuts manuals is short and snappy info to get the best results fast. Produced in-house by the team at Downee, Short Cut manuals are created using plain English and our own real-world install experiences. We’ve chopped off the fat leaving only the meaty bits you need to get a gate system rocking in record time.
  • Page 3 PARTS Ziggy Motor One Booster Motor Two Remotes 24V Motor with 24V Motor Aerial Control Board 30W Solar Panel Gate Bracket Post Panel Post and Clamp Bracket NOT SUPPLIED - Angle Brackets for Battery Box - Gate Post Cap for Panel Post Battery Box Solar...

  • Page 4: Motor Position

    Check gates are in excellent operating condition. Gates in poor operation will give you trouble and prematurely wear out. DELUXE HINGES Gates with automation need heavy duty hinges to handle the load. Designed for Sprint Gate, Deluxe bearing hinges are the finest farm CODE: G7-BBAT gate hinges available anywhere.
  • Page 5 BRACKETS GATE THIS Adjust the Post Brackets to fit the SIDE >>>> Gate Post width and tighten. Mount Post Bracket with bottom edge on the mark. (#4 previous page) Remove a Top Cover off a motor to find which one houses the electronic Control Board.

  • Page 6: Battery Box

    BATTERY BOX NOTE Post Brackets are not supplied with Sprint Gate Kits. Two pieces of angle will do. Work out where the Battery Box will sit above Motor One. Start with the bottom Post Bracket and mount it to Gate Post. Attach the other angle bracket to the top mount on the battery box.

  • Page 7: Solar Panel

    SOLAR PANEL If the gate is shaded through the day, position the Solar Panel away from the gate. Using Tek screws mount Panel Bracket to the Solar Panel. Tek screw the Aerial on top of the Solar Panel Frame. Bolt the Solar Panel (facing north) to the Panel Post. Leave the carton covering the Panel.
  • Page 8 POWER UP MOTOR ONE Remove the Motor cover and the inner control board cover. Use a screwdriver to punch a hole in the cable entry point provided (right). Bottom View Run the battery cable from Battery Box to motor via the new hole. Then divert wire to left side through the hole used to route wires in the grey plastic base.
  • Page 9 CONNECT MOTOR TWO Dig a channel between motors for conduit. Run the Figure-8 and 4-core cable through conduit. Bury the conduit and connect the cables as shown below. MOTOR TWO MOTOR ONE 4-core figure-8 Motor One Use 0.75mm figure-8, 2-core cable and 4-core (three used, one spare) NOTE 0.5mm cable in conduit (not supplied).
  • Page 10 PROGRAMMING Digital Display Programming Buttons Scroll up Scroll down Position the gate half way between open/closed. Lock the Arm using the Key in front of Motor. Using the buttons (above) on the Control Board, Scroll to P030 & press Scroll to d002 & press OK. Display will show P030 Scroll to P003.
  • Page 11 CONNECT THE REMOTE Scroll to P005 & press OK When LEAr shows press the remote button. r000 shows a remote is connected. Repeat step 2 for extra remotes as needed. r001 shows when a second remote is connected. r010 shows when the tenth remote is connected etc. etc. Wait 10sec.
  • Page 12 ACCESSORIES The standard Sprint Gate is operated with remote controls. Other accessories can quickly and easily be added to automate its open/close function such as visitor control, automatic exit, improved security, control via mobile phones, and more. However, more accessories will drain the batteries, so also consider upgrading your solar system to a larger panel or bigger battery bank.

  • Page 13: Solar Controller

    SOLAR CONTROLLER Cover the panel from the sun when connecting panel to controller. Always turn off the load before connecting to the motor. The controller automatically detects system voltage based on battery voltage. If the batteries are too low, the controller will think it is a 12V system. When this happens, the controller will not charge the batteries.
  • Page 14 SOLAR City Winter Spring/Autumn Summer City Winter Spring/Autumn Summer Kalgoorlie 36° 59° 82° Adelaide 32° 55° 78° Albany 32° 55° 78° Katoomba 32° 56° 80° ANGLES Albury 30° 54° 78° Kwinana 34° 58° 82° Launceston 26° 49° 72° Alice Springs 42°...
