CNC STEPPING PROGRAMMING MANUAL
Indexing revolving CNC Table :
- With STEPPING POSITION : Table with STEPPING MOTOR and
POSITION .
MUP TEC 160/600 I
MANUAL N° : MAN.IST.PASSO 01
REV.00
Meccanica SCOTTI S.r.l.
20040 Cornate D'Adda Milano - Italia - Via N. Sauro, 22
Telefoni : 039 / 69.21.56 - 039 / 60.60.140 Fax : 039 / 69.23.27
E-MAIL mescotti@meccanicascotti.com
HOME PAGE www.meccanicascotti.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the CNC Table and is the answer not in the manual?

Questions and answers

Summary of Contents for Meccanica SCOTTI CNC Table

  • Page 1 CNC STEPPING PROGRAMMING MANUAL Indexing revolving CNC Table : - With STEPPING POSITION : Table with STEPPING MOTOR and POSITION . MUP TEC 160/600 I MANUAL N° : MAN.IST.PASSO 01 REV.00 Meccanica SCOTTI S.r.l. 20040 Cornate D'Adda Milano - Italia - Via N. Sauro, 22 Telefoni : 039 / 69.21.56 - 039 / 60.60.140 Fax : 039 / 69.23.27...
  • Page 2 MAIN RIGGING FOR INSTALLATION AND USE OF THE TABLE WITH A OWN UNITY OF STEPPING CONTROL . MODEL ..... / I CONNETTION CABLES AND IGNITION CNC. Connect the connectors ILME C1 and C2 at the electrical case. - C1 Motor drive connector, Proximity zero Table and locking and unlocking Table. - C2 supply solenoid valve connector, locking and unlocking Table, feeding 220 V and "...
  • Page 3 USER INSTRUCTIONS FOR CNC MECCANICA SCOTTI DESCRIPTION : - Dimension 335 x 315 x 235 - Weight about 19 Kg - Operative temperature from 2° to 35° C - Moisture from 20 % to 80 % - Keyboard 20 keys...
  • Page 4 KEY MEANING : Dividually pushed : (1) = 1 (2) = 2 (3) = 3 (4) = 4 (5) = 5 (6) = 6 (7) = 7 (8) = 8 (9) = 9 (0) = 0 (2nD) ( A ) = Key of "...
  • Page 5 KEY MEANING : Individually type: (1) = 1 (2) = 2 (3) = 3 (4) = 4 (5) = 5 (6) = 6 (7) = 7 (8) = 8 (9) = 9 (0) = 0 (2nd) = Key of " SECOND FUNCTION " = Key of "...
  • Page 6 For Example : * If you want to carry out a rotation of 90 degrees and 12 hundredths degrees . TYPE : ( 9 ) ( 0 ) ( 1 ) ( 2 ) = NUMERICAL VALUE ( ANG ) = FUNCTION (Forward degrees) - (2ND)(ANG) =Backword degrees = EXECUTION...

  • Page 7: Manual Mode

    MANUAL MODE The manual mode is active when appear on the display Mecc. SCOTTI or MANUAL MODE EXAMPLE • If you want to carry out a rotation of 90 degrees and 12 centesim of degree with the tilting axis : Type ( 9 ) ( 0 ) ( 1 ) ( 2 ) = NUMERICAL VALUE (BAS)
  • Page 8 KEY and FUNCTION USEFUL IN MANUAL The “QUOTA VISUALISATION” key is very useful in manual way. In manual way, after ever positioning it is possible to control the quota, that the table has reached, pushing the STP key. The same key STP pushed in EDIT, makes the program run increasing (for example from step N01 to step N02), while pushing the “2nd STP”...
  • Page 9 MAIN OPERATION TO RESTORE OR TO CREATE THE “ZERO PIECE” • In order to restore or create “ZERO PIECE” in the circumference we suggest operate in this way : Type the funciton : ( 4 ) (OUT) ( = MANUAL TILTING AXIS ( 4 ) (2nd) ( OUT ) ( = AUTOMATIC TILTING AXIS Carry out “TILTING ZERO”...

  • Page 10: Error Message

    ERROR MESSAGE The control gives some messages about main malfunction that could happen. These messages appear in full extention and they are : " CHECKSUM ERROR " : Checksum error of memory if the buffered memory has lost some file because of a BLACK-OUT or a storm, it is necessary to check the saved programs. This error signal will inform the utilizer that the buffered RAM BATTERY is exhausted (Duration about 4 years) .
  • Page 11 THE CNC UNIT DO NOT GIVE BACK THE SIGNAL TABLE IN POSITION TO THE TABLE Check the table parameter : 3° value must be from 2 to 9. Check the fuse in the fuseholder inside the electric box situated in the low-front part of cnc unit.
  • Page 12 PROGRAMMED FUNCTIONING The same functions that you can carry out in manual, may be carryed out also by program. You can save 8 programs of 49 steps each. The steps you can write in the program are 49, but if the program has more then 49 steps, the CNC unit memorized the other steps in the next program and cancel everything in that program.
  • Page 13 A similar program, however, has not a great interest if you don't give the possibility of an exterior entity (Es. Machine tool) to call these movement. The function that allow an exterior entity to interact with the control is the " Wait for outside start " function : ( 2ND ) ( 0 ) .
  • Page 14 At this point you can begin with this program that carries out a rotation of 90 degrees for 4 times after closing the start contact then it stops. TYPE : ( 5 ) (2ND ) ( 1 ) ( = To RECALL PROGRAM N°.5 (2ND ) ( PGM ) = START "...
  • Page 15 ( FPG ) ( ALT ) (2ND ) (2ND ) = ESC from the EDIT and RETURN to MANUAL At this point you can start the program : TYPE : PROGRAM N° ( 1 ) (2ND ) ( 1 ) ( = CONFIRM RESEARCH PROGRAM FUNCTION (2ND ) ( PGM )
  • Page 16 ( 1 ) (2ND ) ( 0 ) ( = WAIT for START ( 0 ) (2ND ) ( 7 ) ( = ABSOLUTE ( 1 ) (2ND ) ( 0 ) ( = WAIT for START ( 90 00 ) ( ANG ) ( = INCREMENTAL ( 1 ) (2ND ) ( 0 ) ( = WAIT for START...
  • Page 17 TYPE : N° of PROGRAM ( 1 ) (2ND ) ( 1 ) ( = CONFIRMATION RESEARCH PROGRAM FUNCTION (2ND ) ( FPG ) = START TABLE...
  • Page 18 INFORMATION RESERVED to SERVICE There are some parameter that you can set once at the installation of the control and the RAM on a particular code. They are : Locking or not locking of the indexing head . Break time after unlocking before the rotation . Duration of rotation signal OK .
  • Page 19 INSTRUCTION TO CLEAN THE MEMORY : Attention ! ! ! ! ! In this way you cancel all the program and all the table parameter. Use this operation only if really necessary. 1. Switch on the CNC unit 2. When the display show “ MECC. SOTTI”, Push : ( 1 ) ( 5 ) ( 9 ) ( 2 ) ( 1 ) ( ) Cancel MEMORY ;...
  • Page 20 N 10 ( 1 ) ( 2 ) ( 1 ) ) Skip to step N.1 ; N 11 ( FPG ) ) STOP PROGRAM ; INSTRUCTION TO ESC FROM PROGRAM AND FROM EDIT : ( FPG ) ( ALT ) ( 2 ) ( 2 Out from EDIT ;...
  • Page 21 4° Repeat " Tilting zero " and " Tilting reset " 5° To escape tilting manual mode, you have to turn OFF and then turn ON the CNC Table or TYPE : ( 3 ) (2ND) ( BAS ) ( = AUTOMATIC TILTING...
  • Page 22 Exchange time of " M Function " between the Table and the machine tool are 200 millisecond like our standard. It is also possible to ast for higher or lower exchange times. Now insert a program in the CNC Table and make the machine tool execute the program in manual mode step by step.
  • Page 23 INSTRUCTION of ENCODER CONTROL EQUIPMENT For enabling the control from encoder you have to set the 4th DIGIT of the Customizing Parameter in the following way : = CONTROL ENCODER DISABLED From 1 to 9 = ACCEPTANCE ERROR ENCODER VALUE The acceptance unit is a function of the transmission ratio .
  • Page 24 Connect the hydraulic cable to the table and the " PNEUMATIC " supply to the hydropneumatic gear case through the our treatment group ( Yellow of Waircom, screw thread 1/8 Gas ) . To turn on the CNC table disconnect in counter-clockwise the " EMERGENCY KEY " ( Red ) and wait that the CNC positioning does his SELF-DIAGNOSTIC .
  • Page 25 made in this way : ( 0 ) (2ND ) ( 8 ) ( 3. TO CARRY OUT THE PROGRAM : To carry out the program in manual way type : ( FPG ) (ALT) (2ND ) (2ND ) After : ( 1 ) (2ND ) ( 1 ) ( = Recall the program N°...
  • Page 26 SCHEME OF HARNESS ENCODER STEPPING TABLE Military Connector Pin Function Color PHASE A GREEN PHASE B YELLOW PHASE C BLUE SHIELD SHIELD BLACK + 12 V ENCODER : MODEL : TELESTAR MEDIOCOD UH 5/12 B 800 RO MANIFACTURER : TELESTAR Via COLOMBO, 13 - 22069 - ROVELLASCA ( COMO ) ITALY...

  • Page 27: Main Characteristics

    19. " M FUNCTION " (Machine tool) It is requested a clean contact for " START " table 20. Table in position' s signal The CNC Table returns an electrical signal 0 Volt to the Machine tool 21. Stepping motor With variable couple according to...
  • Page 28 Provvision regarding testing of MACHINE TOOLS ACCESSORIES. MECHANICALLY CONTROLLED INDEX TABLES. And in conformity with particular certification requirements of MECCANICA SCOTTI S.r.l. . MECCANICA SCOTTI S.r.l. - 20040 - CORNATE D' ADDA ( MI ) ITALY - VIA N. SAURO 22 TEL.
