Summary of Contents for DriSteem Drane-Kooler Series
- Page 1 READ AND SAVE THESE INSTRUCTIONS DRANE-KOOLER™ Water Tem perin g D evic e Installation, Operation, and Maintenance Manual...
-
Page 2: Table Of Contents
INSTALLATION AND MAINTENANCE WARNINGS Attention installer For warnings and cautions to the Drane-Kooler water tempering device, refer to the Installation, Operation, and Maintenance Manual provided with the humidifier . DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 3: Overview
. These multiple mounting options provide capability for the Drane-kooler to be properly supported and not secured entirely by piping . DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 4: Capacities And Connection Sizes
9 .5 4 .3 Table 2-4: Drane-kooler material Operating weight 6 .8 Description Material Drane-kooler body 304 stainless steel Optional material 316 stainless steel Valve body Bronze Vaccuum breaker Brass DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 5: Dimensions
Width of tank and tempered water outlet 7 .5 (191) Width of mounting plate holes, center to center 4 .0 (102) Length, from valve inlet to mounting plate 12 .0 (305) DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 6: Installation
• Run a 2” (DN50) pipe as directly as possible from the Drane-kooler to the drain . Maintain a pitch to drain of at least 1/8”/ft (1%) . • Make sure there is a 1” (25 mm) air gap between the drain piping and the drain . DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 7: Mounting
L-bracket, two nuts, and two bolts that attach to the Drane-kooler . Beam clamp assembly and 1/4" threaded rod are supplied by others . FIGURE 5-3: OPTIONAL FLOOR MOUNT OM-1114 OM-1115 DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 8: Piping
Recommended minimum pitch: 1/8" per ft (1%) before drain Drain OM-1120a FIGURE 6-2: DRANE-KOOLER MOUNTED DIRECTLY UNDERNEATH AN EVAPORATIVE HUMIDIFIER Drane-kooler OM-1121 Drane-kooler OM-1122 Note: Pitch drain piping at least 1/8"/ft (1%) in direction arrows . DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 9: Operation
PVC pipe . *Please see the capacities table on Page 4 . FIGURE 7-1: PRINCIPLE OF OPERATION Vacuum breaker Temperature-actuated valve Sensor Capillary tube OM-1114-2 DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 10: Maintenance And Troubleshooting
Makes a loud popping or crackling noise popping or crackling sound . Check P-traps on Drane-kooler humidifier or other appliance to ensure that the P-traps have the proper depth and are working properly . DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 11: Replacement Parts
Model DK-12 replacement parts Item Description Part Number Drane-kooler weldment, Model DK-12 167001-020 Water tempering valve 505090 Valve, 1/2" N36 vacuum relief 320400 Floor stand assembly 185110 Suspension mount hanger assembly 185100 DRISTEEM DRANE-KOOLER WATER TEMPERING DEVICE INSTALLATION, OPERATION, AND MAINTENANCE MANUAL... -
Page 12: Warranty
DriSteem U .S . operations are ISO liability in tort, or any other legal theory, even if DriSteem has notice of the possibility of 9001:2015 certified such damages .
