  • Page 1 Alarm Operation Manual AL-1112 Powered by...
  • Page 2 Before reading this manual This is a basic installation and operation manual for use of an IDIS alarm box. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
  • Page 4 Before reading this manual FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.

  • Page 5: Table Of Contents

    Table of Contents Part 1 - Remote Setup ........6 Product Features .

  • Page 6: Part 1 - Remote Setup

    Part 1 - Remote Setup Product Features This alarm box offers the following features: • DirectIP protocol supported • Extend alarm terminal of recording equipment • Easy connection with network • Support PoE and DC, AC power • Check current alarm status via front LED Accessories Upon unpacking the product, check the contents inside to ensure that all the following contents are included.
  • Page 7 Part 1 - Remote Setup Alarm Out LED Alarm In LED Power LED Network LED Factory Reset Switch 1 Alarm Out LED Displays alarm out status 2 Alarm In LED Displays alarm in status 3 Power LED Displays system operating status 4 Network LED Displays network connection status LED Status Indications...
  • Page 8 Part 1 - Remote Setup Rear Panel Alarm Out Alarm In USB Port Network In DC Out Power In 4 Network In Connect a network cable with an RJ-45 jack. The alarm box is capable of connecting to networks via an Ethernet connector and also receives PoE power from the network cable.

  • Page 9: Part 2 - Remote Setup

    Part 2 - Remote Setup Remote Setup Configure basic alarm box settings and all other system settings. Screen images may vary depending on the model. Launch the IDIS Discovery program and then from the main screen, select a network device whose settings you wish to change.

  • Page 10: Quick Setup

    Part 2 - Remote Setup System From the Remote Setup screen, select the menu on the left to display the current settings. Select an option under the menu to change the corresponding settings. Once you have changed the settings, click Save to apply the settings. Change the alarm box’s system information, add users/ groups, and/or import/export settings.

  • Page 11: General

    Part 2 - Remote Setup General • Setup - Load Default Setup: Restores all settings other than Date/Time to their factory defaults. Select Include Network Setup to load default network settings as well. For more information on network setup, refer to the Network on page 13. - Import Setup: Open a setup file and apply its settings to the alarm box.

  • Page 12: Date/Time

    Part 2 - Remote Setup Date/Time User/Group • User/Group: Change remote alarm box control • Date/Time: Change the alarm box’s date/time permission settings for users and user groups. settings and display formats and configure the time zone and daylight saving time settings. Click Save to - Add Group: Add a new user group.

  • Page 13: Network

    Part 2 - Remote Setup Network • Type: Select the type of network you are using. If this option has been changed, click Save to apply the current settings, and then restart Remote Setup. If you do not restart Remote Setup, the changes afterwards will not be applied.

  • Page 14: Port

    Part 2 - Remote Setup Port Security • Use/Port: Enable/disable ports and designate • IP Filtering: Select this option to enable IP Filtering. corresponding port numbers. Remote Port and HTTP IP Filtering allows alarm box access from certain IP ports are enabled by default and cannot be disabled. addresses and blocks access from others.

  • Page 15: Ieee 802.1X

    Part 2 - Remote Setup • SSL: Select this option to enable SSL (Secure Sockets IEEE 802.1X Layer). Enabling this option applies SSL protocol protection on data transmitted out. However, Select the IEEE 802.1X option to enable IEEE 802.1X programs and systems that do not support SSL will not be able to connect to the device.

  • Page 16: Event Action

    Part 2 - Remote Setup Event Action Event Designate event detection alert actions. Configure event detection settings. Alarm out Select Alarm Out to enable alarm out. • Dwell Time: Designate the alarm out duration. When an event occurs, alarm out will be generated for the specified duration.

  • Page 17: Alarm In

    Part 2 - Remote Setup Alarm In System Event Select Alarm In to enable alarm in event. With alarm Select System Event and configure system event in event enabled, alarm in detections by the alarm in settings. With system event enabled, system status connector will be assumed as events.

  • Page 18: Part 3 - Appendix

    Part 3 - Appendix Setup Menu Tree (Remote Setup) Remote Setup Quick Setup System Network System General Date/Time User/Group Network IP Address Port Security IEEE 802.1X Event Action Alarm Out Event Alarm In System Event Troubleshooting Problem Check • Check the LAN cable. Power LED will not turn on •...

  • Page 19: Specifications

    Part 3 - Appendix Specifications 8 Digital-Input channels - including GND (1ea per 4 alarm ins) Input - Dry contact, Wet contact Alarm High : Open or DC 3V ~ DC 30V LOW : Short or DC 0V ~ DC 1.8V Output 4 Relay-out channels (NC, NO, COMMON) Ethernet...

  • Page 20: Index

    Part 3 - Appendix Index Camera Name Date/Time IDIS Web port IPFiltering Remote Port Time Sync User/Group V1.0...
  • Page 21 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
