Summary of Contents for AmeriWater CIP1
- Page 1 CLEAN IN PLACE OPERATION & MAINTENANCE INSTRUCTIONS MODEL CIP1 Manufactured With Pride In The USA www.ameriwater.com • 800-535-5585 AmeriWater • 3345 Stop 8 Rd • Dayton, OH 45414 Part Number: 98-0007 Revision: E...
-
Page 3: Table Of Contents
TABLE OF CONTENTS OBJECTIVE ......................1 CHEMICALS REQUIRED ..................1 INSTALLATION ....................2 HIGH pH CLEANING .................... 3 LOW pH CLEANING ..................... 5 FLUSH AND RETURN TO SERVICE ..............6 SPARE PARTS LIST .................... 7... -
Page 4: Objective
The objective of the Clean In Place (CIP) system is to introduce high pH and low pH membrane cleaners to the AmeriWater RO+ system at low pressure and high velocity. This action removes scale and organic contaminants from the RO+ membranes and improves system performance. -
Page 5: Installation
INSTALLATION 1. Connect the PUMP FEED end of the hose (with the female garden hose thread fitting) to the bottom of the CIP drum. Connect the other REJECT end of hose to the CIP Pump Inlet. RETURN FIGURE 2 shows the flow direction arrows on the CIP pump inlet and outlet. -
Page 6: High Ph Cleaning
In cases of heavy fouling, turn off the RO and CIP pump and allow the system to soak for a minimum of 30 minutes.* * Contact AmeriWater Technical Support or your local AmeriWater dealer for custom cleaning procedures if necessary. - Page 7 c. After the soak time, turn on the CIP pump and RO, and allow the cleaning solution to recirculate again for 30 minutes. Disconnect the pump outlet hose from the CIP drum and direct the hose to a drain. Continue running to drain until the CIP drum is empty (some solution may need to be manually dumped out of the CIP drum).
-
Page 8: Low Ph Cleaning
In cases of heavy fouling, turn off the RO and CIP pump and allow the system to soak for a minimum of 30 minutes.* * Contact AmeriWater Technical Support or your local AmeriWater dealer for custom cleaning procedures if necessary. -
Page 9: Flush And Return To Service
Disconnect the pump outlet hose from the CIP drum and direct the hose to a drain. Continue running to drain until the CIP drum is empty (some solution may need to be manually dumped out of the CIP drum). CAUTION: Neutralization of the spent cleaning solution may be required by local regulations. -
Page 10: Spare Parts List
SPARE PARTS LIST Description Part Number HOSE BARB, 3/8”MPT x 3/8”HB 14520503 HOSE BARB, 1/2”MPT x 1/2”HB 14520506 FITTING, 3/4”HG INSERT x 1/2”MPT 14570110 WASHER, RUBBER, GH 14570111 FITTING, 3/4”MGHT x 1/2”MPT 046520423 HOSE, 1/2”, MEDICAL SYTLE-5000 12677125 CLAMP HOSE 1/2" SST 15650050 PUMP, AQUATEC, 120VAC, 3.5GPM@50PSI 80-0026...
