Product Code: 2069T
OWNER'S MANUAL
PRODUCT CODE: 2069T
900kg SWIVEL BASE UTILITY CRANE
WITH WINCH
Maximum
Minimum
Maximum
Swivel Base
Minimum
Working
Maximum
Lift
Lift Radius
Lift Radius
Plate
Lifting
˚Rotation
Lifting
Capacity
Height
Radius
900kg
930mm
1800mm
270x270mm
170mm
360˚
1295mm
Made in China to TQB Brands Pty Ltd specifications.
Visit us at www.tqbbrands.com.au
Advertisement
Table of Contents
Summary of Contents for TQ 2069T
- Page 1 Product Code: 2069T OWNER’S MANUAL PRODUCT CODE: 2069T 900kg SWIVEL BASE UTILITY CRANE WITH WINCH Maximum Minimum Maximum Swivel Base Minimum Working Maximum Lift Lift Radius Lift Radius Plate Lifting ˚Rotation Lifting Capacity Height Radius 900kg 930mm 1800mm 270x270mm 170mm 360˚...
-
Page 2: Table Of Contents
Product Code: 2069T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Safety Instructions
Product Code: 2069T SAFETY INSTRUCTIONS SAFETY OPERATING INSTRUCTIONS Before using the hydraulic crane ensure it is in sound condition, and good working ü order. Crane boom must always be stored and secured in the down position when not in ü... -
Page 4: Assembly, Operation, Preventitive Maintenance
Product Code: 2069T ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES This TradeQuip hydraulic utility crane provides the lifting power to lift a 900kg load when fully retracted and 450kg when fully extended. The boom pivots 360˚ at the base for easy loading and unloading. - Page 5 Product Code: 2069T Connect the Hydraulic Ram (F) to the Boom Main Post Secure the Base (J) to the utility bed, garage floor, or where the hoist will be used. Insert the assembled parts (Main Post, Boom and Hydraulic Ram) to the Base Insert the Boom Extension (B) into the Boom.
- Page 6 Product Code: 2069T Attach the Handle (E) to the Main Post, securing it with the Hitch Pin (17). Attach the Wheel Binding Bolt (18) to the Base. 3. BEFORE USE Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked joints and damaged, loose, or missing parts.
- Page 7 Product Code: 2069T 4. OPERATION To Raise: Turn the release valve to the right. To Lower: Turn the release valve slowly to the left. To Add Oil: Fully collapse the jack and add oil to increase oil level up to oil plug NOTE: ONLY USE HYDRAULIC JACK OIL.
-
Page 8: Parts Diagram
Product Code: 2069T PARTS DIAGRAM Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 8... -
Page 9: Parts List
Product Code: 2069T PARTS LIST Part # Description Part # Description Winch Assembly Lock Washer ˚16 Winch Wire Flat Washer ˚16 Bushing 3T Jack Large Pulley Bolt M16x90 Post Weldment Bolt M12x40 Nut M14 Turntable Lock Washer ˚14 Bearing ˚14 Flat Washer ˚14... -
Page 10: Warranty
Product Code: 2069T WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
