DMX Wireless Transceiver
XP-LR512 RT
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP-LR512 RT and is the answer not in the manual?

Questions and answers

Summary of Contents for Acome XP-LR512 RT

  • Page 1 毅丰 2015.06.11 受控正本 DMX Wireless Transceiver XP-LR512 RT User Manual...
  • Page 2: Specification

    Specification Input Voltage: AC 100-240V 50/60Hz Power Consumption: Wireless frequency: 2.4GHz Receive range: 300m Weight: 0.6Kgs Dimension: 194 x 100 x 127 mm...
  • Page 3: Control Panel

    Control Panel Signal quality indicators Function For the Receiver, it shows Press to link with, or the signal strength; for the unlink from another Transmitter, only one unit. indicator on all the time. RX/TX switch Status Indicators Select Receiver or RF Link on Transmitter: Transmitter.
  • Page 4: Operation Indications

    Operation Indications When operating, the units show different indications depending on its mode and link status: Transmitter when not linked. Receiver when not linked. Transmitter when linking. Receiver when linking. Transmitter showing a healthy Receiver showing a healthy link link with a Receiver. with a Transmitter.
  • Page 5: Rear Panel Connections

    5-pin XLR input Power In DC12V Power Input Optional Accessories For XP-LR512 RT, below three groups of accessories can be selected: A. Hanging suspender x 1, Fixed Plate for hanging x 1 B. Fixed plate for wall-hang x 1 C. Fixed plate A x 2, Fixed plate B x 2, M4 x 10 Hex screw x 4...
  • Page 6 Mounting 1. Hanging in the truss Put the fixed plate into the side slot of the fixture from the side hole. Screw the clamp (not included) via the screw and nut onto the hanging suspender. Fix the hanging suspender and the fixed plate via the quick-lock fasten.
  • Page 7 3. Fixed in the equipment cabinet Put the fixed plates A into the side slots of the fixture. Combine fixed plate A with fixed plate B via M4 x 10 Hex screws. Mount the combination in the equipment cabinet via the screws.
  • Page 8: Operation

    Operation Connect with the other XP-LR512 RT: 1. Ensure the antenna is connected for all XP-LR512 RT. 2. Connect XP-LR512 RT with DMX console and connect the other XP-LR512 RT with the fixtures. 3. Power on all the fixtures. 4. Select TX mode (Transmitter) or RX mode (Receiver) for all the XP-LR512 RT.
  • Page 9 If the indicator changes to flash slowly, it means fail. 7. For the wireless control fixtures, cancel the wireless mode via the menu to unlink it from the XP-LR512 RT; on the transmitter, press the hold its Function button for more than 3 seconds to...
  • Page 10: Maintenance

    To optimize range and performance: Keep antennas upright;  Maintain the Transmitter to Receiver line of sight;  Elevate the units above any crowds;  Elevation above ground increases range;  Keep away from large metal objects.  Maintenance Clean the front transparent cover at least every 1-2 months. Use a moist, lint-free cloth.
  • Page 11: Declaration Of Conformity

    Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008.
  • Page 12 Innovation, Quality, Performance...
