Heath Consultants RMLD-CS Operator's Manual

Hide thumbs Also See for RMLD-CS:
Table of Contents

Advertisement

Quick Links

OPERATOR
TM
MANUAL
Complete Solution

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RMLD-CS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heath Consultants RMLD-CS

Summary of Contents for Heath Consultants RMLD-CS

  • Page 1 OPERATOR MANUAL Complete Solution...

  • Page 2: Table Of Contents

    Screen Mode - Image ....................42 Surveying with the RMLD-CS ..................... 43 Long Range Scanning ....................... 45 Dealing With False Detections ..................47 How Does the RMLD-CS Measure Gas? ................48 Troubleshooting ....................... 50 Maintenance ........................52 Notes ..........................53 Warranty and Repair ......................
  • Page 3 RMLD-CS Operator Manual 3 / 56...

  • Page 4: Overview

    The RMLD-CS employs the same technology as the RMLD, known as Tunable Diode Laser Absorption Spectroscopy (TDLAS). As the laser passes through the gas plume, the methane absorbs a portion of the light, which the instrument then detects.

  • Page 5: Proprietary Notice

    RMLD-CS Operator Manual Proprietary Notice The contents of this instruction manual are proprietary to Heath Consultants Incorporated. Reproduction of this manual, in whole or in part, is prohibited without the express written consent of Heath Consultants Incorporated. Heath Consultants Incorporated operates under a continual product improvement program and reserves the right to make improvements and / or changes without prior notification.

  • Page 6: Warnings & Definitions

    RMLD-CS Operator Manual Warnings & Definitions Safety and Warning Information It is essential that users of this instrument read, understand and follow the instructions for operation and maintenance. The precautions contained in this manual insure that the instrument is used in a proper and safe manner.

  • Page 7: Definitions

    This can also occur on highly reflective surfaces (windows, water, ice, etc). Control Module: The portion of the RMLD-CS with the keypad and display that clips onto a harness. Dark Zone: An area not being scanned due to an obstruction. This may be an elevation change, the side of a building, behind a curb, etc.
  • Page 8 RMLD-CS Operator Manual Information Consult Instructions for use Ingress protection IP54 Do not dispose of this product in the unsorted municipal waste stream. Dispose of this product according to local regulations.   Measurement Laser Radiation: Class I Visible (Green) Laser Radiation: Class IIIa (3R) Do not stare into beam.

  • Page 9: Specifications

    RMLD-CS Operator Manual Specifications Deieft ny ei t   Tunable Diode Laser Absorption Spectropscopy (TDLAS) Measurement Range 0 to 99,999 ppm-m Sensitiiit   5 ppm-m at distances from 0 to 100 ft (30m) InioinsifySr eit   IECEx 60079-1,-11; ATEX, UL913 (PENDING) Deieft nyDisirnfe  ...
  • Page 10 RMLD-CS Operator Manual Carry Case 21" x 17.5" x 9.5" Battery Removable, rechargeable Li Ion pack, 10.8 VDC 2.6Ah Brteoty mny i e   8 hours at 32 F (approx) Battery Charger External, 110-240 VAC, 50/60 Hz Universal C roney i e  ...

  • Page 11: Rmld-Cs Instrument And Accessories

    (Includes Carry Case, Instrument, Test Cell, Carry Strap, Battery Charger, Battery Pack, USB Cable) Instrument - HPN105354 This is the primary component of the RMLD-CS. In addition to the gas detection capability, it contains the user interface, data logging interface, battery, power connector.
  • Page 12 Vest - HPN 105357 and HPN 105406 The RMLD-CS has an optional accessory type 2 class R vest. It has many pockets for equipment placement. The pocket on the back can hold a pad for your notes/maps or a water pack.
  • Page 13 RMLD-CS Operator Manual USB Cable The USB2 A to micro cable is for downloading data from instrument to computer. 13 / 56...

  • Page 14: Battery, Charger And Charging Procedure

    The RMLD-CS is provided with a universal AC battery supply. The plug of the charger can be changed to fit the type of receptacle used in your location.

  • Page 15: Charging Procedure

    DANGER: To reduce the risk of ignition of a flammable or explosive atmosphere, the battery must be recharged only in a location known to be non-hazardous. WARNING: Only use the HEATH supplied RMLD-CS battery charger to recharge the unit. Use of any other charger may cause severe damage to the battery or electrical circuits.
  • Page 16 RMLD-CS Operator Manual 3. Insert the battery into the charger, ensuring it is all the way down. a. Optional: Fasten captive screws into charger housing to prevent battery from dislodging. b. LED panel will illuminate to show the status of the battery charging.

  • Page 17: Operating The Rmld-Cs

    RMLD-CS Operator Manual Operating the RMLD-CS Turning on the Instrument To turn on the instrument, Press and Hold the middle button for 3 seconds. To turn off the instrument, Press and Hold the middle button for 3 seconds. Working with the Menu Items...

  • Page 18: Instrument Self Test

    RMLD-CS Operator Manual Instrument Self Test The RMLD-CS has a built-in function to perform a Self-Test of the laser wavelength. The self-test feature should be performed daily before survey to ensure that the instrument is operational. A Self- Test log file is recorded and stored on the RMLD-CS instrument.
  • Page 19 RMLD-CS Operator Manual NOTE: Laser wavelength drift is a normal characteristic of the RMLD-CS. Normally the rate of drift is low and will not affect the Self-Test if performed on a regular basis. Survey work conducted with an instrument which has drifted and was not self-tested may need to be redone. If instrument is not able to successfully perform a self-test after three attempts, contact HEATH for assistance.

  • Page 20: Audio Modes

    Real Time (Geiger) The Real Time mode of the RMLD-CS plays a variable (continuous) beep that is relative to the instantaneous concentration level. The faster the unit beeps, the higher the methane concentration level.

  • Page 21: Audio Warning Indications

    RMLD-CS Operator Manual The Real Time mode is most effective when used up close to help verify a low level detection or to help isolate the highest gas concentration. To verify a low level leak the following procedure should be used: 1.
  • Page 22 RMLD-CS Operator Manual If over saturation, the operator should back up from the target or point the device at a less reflective surface. Should the warning(s) persist, it could be due to a fault in the instrument. Check the display and follow the instructions in the troubleshooting guideline.

  • Page 23: Alarm Levels

    RMLD-CS Operator Manual Alarm Levels To change the Alarm Detection Threshold, press the MENU button, scroll down and select ALARM LEVELS. Press the down arrow button to increase or decrease the threshold and SELECT to move the placeholder. NOTE: The higher the threshold setting is, the higher the concentration of methane will be needed to alarm.

  • Page 24: Spotter Control

    RMLD-CS Operator Manual Spotter Control The green spotter laser in under the control of the operator and is on for one minute when the spotter "ON" button has been pressed and when enabled. The green spotter laser will automatically shut off after one minute, requiring the user to press the "ON" button again for use. While using the...
  • Page 25 RMLD-CS Operator Manual 3. The left menu button will now display the spotter ON option. Pressing the left button (on/off) will activate the spotter for 1 minute. 25 / 56...

  • Page 26: Usb File Transfer

    PC. The USB mode in the MENU must be set to "Mass Storage Device" for PC recognition and file logging operations. NOTE: Recognition of RMLD-CS may take some time on first plug in as the required drivers are installed. Please allow time for this initial process to complete.
  • Page 27 RMLD-CS Operator Manual NOTE: 'USER' will be replaced by the operator profile being used during operation 27 / 56...

  • Page 28: Bluetooth

    For instructions and recommendations on how to connect and view data, please contact HEATH for additional information. NOTE: Some devices may not be able to discover the RMLD-CS using the default Bluetooth connection manager on the operator's device. The operator must first install a compatible Bluetooth terminal application on their device for successful pairing.
  • Page 29 RMLD-CS Operator Manual The Bluetooth icon will turn red and a pop up window will be displayed when the connection is lost or not present. 29 / 56...

  • Page 30: Wifi

    RMLD-CS Operator Manual WiFi The WiFi option within the RMLD-CS allows operators to connect with their apple/android/pc devices through specific applications. The instrument sends out real time warnings, errors, and data (instrument readings). Connecting via WiFi will also allow the operator to access useful information stored on the device, such as Self-Test logs, data logging, fault codes, and screen captures.
  • Page 31 RMLD-CS Operator Manual AP Mode The Access Point (AP) mode will broadcast a wireless network directly from the RMLD-CS instrument. The operator must search for this network and connect directly to the instrument using the AP WiFi SSID network name and password.

  • Page 32: Data Logging

    RMLD-CS Operator Manual Data Logging The RMLD-CS data logging feature allows the instrument to store complete telemetry records of the instrument, while powered on, to an internal SD memory card. To enable this feature, select DATA LOGGING from the MENU, then select ENABLED.

  • Page 33: Timezone

    RMLD-CS Operator Manual Timezone The timezone menu option will allow the user to select the desired offset, in hours, from UTC time acquired by the GPS. In the menu, select TIMEZONE, then use the arrow buttons to adjust the desired offset. Select the back arrow button when complete.

  • Page 34: User Profiles

    RMLD-CS Operator Manual User Profiles User profiles allow multiple operators to utilize the RMLD-CS instrument with customized settings and unique PIN protection to enable use. Adding a New User Press the MENU button and scroll down to select USERS from the menu. Select NEW USER, then select ADD NEW USER.
  • Page 35 RMLD-CS Operator Manual Renaming a User Select the user to be renamed. Scroll down the sub menu and select EDIT NAME. Use the down arrow button to scroll through each letter. Pressing SELECT will accept the change and move to the next place holder.
  • Page 36 RMLD-CS Operator Manual Setting User PIN Select the user from the menu and scroll to EDIT PIN. Press select and use the down arrow button to scroll through the numeric options. Pressing SELECT will accept the change and move to the next place holder.
  • Page 37 RMLD-CS Operator Manual 37 / 56...

  • Page 38: About Screen

    · Current Time and Date · Firmware Version · GPS Status · Battery Percent Remaining · Internal SD Card Storage Remaining · Recent Error Codes · Bluetooth Status · WiFi Status · Heath Consultants Incorporated Contact Information 38 / 56...

  • Page 39: Additional Features

    RMLD-CS Operator Manual Additional Features 39 / 56...

  • Page 40: Screen Mode - Survey

    RMLD-CS Operator Manual Screen Mode - Survey The Survey screen mode will display avnumerical readout of PPMM readings. This allows the operator a no-clutter screen to survey with the instrument. During DMD Audio Mode, the Peak and PPMM values will turn red in color when a methane signal is detected.

  • Page 41: Screen Mode - Graph

    RMLD-CS Operator Manual Screen Mode - Graph The Graph screen mode will display a bar graph in addition to the numerical readout of PPMM readings. This allows the operator to easily see the changing values while surveying with the instrument.

  • Page 42: Screen Mode - Image

    Screen Mode - Image The IMAGE mode allows the user to view a live image of where the RMLD-CS is pointed as well as current and peak PPMM readings. This feature is especially useful in bright sunlight when the green spotter laser may be hard to see.

  • Page 43: Surveying With The Rmld-Cs

    The most important aspect to using the RMLD-CS is the proper control and aiming of the infrared beam. The first thing you will need to learn when surveying with the RMLD-CS is to control the aiming of the laser and rate of sweeping. Radical or abrupt motion may cause the RMLD-CS to give false detections due to rapidly changing distance or background that the laser detects.
  • Page 44 RMLD-CS Operator Manual Use an “X”ypattern or similar pattern to thoroughly scan the area. · Target typical vent areas i.e., along the street or sidewalk edges. · Target locations where valves may be placed. · Scan along the foundation of the structure.

  • Page 45: Long Range Scanning

    RMLD-CS Operator Manual Long Range Scanning The RMLD-CS can detect leaks from up to 100 ft. away. Actual distance may vary due to target surface and environmental conditions. As the scanning distance is increased, the laser light level returned will decrease. As the maximum distance is approached, a “low return signal”ytone is heard. You will need to move in closer.
  • Page 46 RMLD-CS Operator Manual 46 / 56...

  • Page 47: Dealing With False Detections

    RMLD-CS Operator Manual Dealing With False Detections While using the DMD mode, several conditions may occur that will cause the algorithm to give a detection indication. The most common situations are: Abrupt or jerky motions causing the scanning distance to rapidly change.

  • Page 48: How Does The Rmld-Cs Measure Gas

    How Does the RMLD-CS Measure Gas? With the RMLD-CS it is now possible to survey areas that are hard to reach or not easily accessible. The RMLD-CS does not have to be within the gas plume because it uses laser technology known as Tunable Diode Laser Absorption Spectroscopy.
  • Page 49 RMLD-CS Operator Manual meter in width, the RMLD-CS will measure 40 ppm-m, plus a background level of 15 ppm-m in this case, displaying a total value of 55 ppm-m. The infrared beam width is about 22”yat 100 feet. It is important to note that the laser beam “footprint”ywidth and distance increases as the distance increases (see Figure 4-5).

  • Page 50: Troubleshooting

    RMLD-CS Operator Manual Troubleshooting The advanced design of the RMLD-CS makes it one of the most reliable leak survey instruments available. However, should you experience problems with the instrument or suspect that the instrument is not operating properly, do not use the instrument for leak survey work until the problem is resolved.
  • Page 51 RMLD-CS Operator Manual high or low for conditions Threshold Error message or Warning icon on Low battery Check battery level and continuously recharge if necessary Allow for the temperature of the instrument to stabilize Moisture condensation on mirror Note error message and...

  • Page 52: Maintenance

    RMLD-CS Operator Manual Maintenance In order to maintain the RMLD-CS in good working condition, the following maintenance should be performed as indicated: Maintenance Item Frequency Clean outer surfaces with damp rag As needed Clean instrument window with damp KimWipe™yor As needed to prevent dust or water stain build...

  • Page 53: Notes

    RMLD-CS Operator Manual Notes 53 / 56...

  • Page 54: Warranty And Repair

    RMLD-CS Operator Manual Warranty and Repair All instruments and products manufactured by Heath Consultants Incorporated are warranted to be free from defects in material and workmanship for one (1) year from the date of shipment. Furthermore, the warranty on authorized repairs in the Houston Factory Service Center (FSC) and other regions is ninety (90) days materials and thirty (30) days labor.

  • Page 55: Return Procedure

    RMLD-CS Operator Manual Return Procedure The following steps will expedite the repair of your instrument: 1. Contact Heath Factory Service at 713-844-1350 to request a repair form. The form is also available on-line at http://heathus.com/info-center/repair-forms/ 2. Package carefully using the original shipping carton and cushions if available and return all components including the repair form.

  • Page 56: Contact Information

    RMLD-CS Operator Manual Contact Information Houston Factory Service Center Manufacturing Division 9030 Monroe Blvd Houston, TX 77061 PHONE 713.844.1300 FAX 713.844.1309 1.800.HEATH.US www.heathus.com Technical Support 1.800.HEATH.US (1.800.432.8487) 56 / 56...
