Elnur Gabarron TPG-IR Manual

1

INTRODUCTION

The remote control allows setting temperature values
and operation schedules in order to configure the
heaters through infrareds.
The main functions are:
- Hourly programming (weekly

programming)

- Setting temperature values in the
premises
- Temporal suspension of automatic
programming
Various preset programs in the IR remote control are
to be transmitted through IR to every heater available
in the premises.
Contents:
- Remote control unit
- Remote control holder
- Battery set
Screen
Keys
select/validate
Main keys
Baseboard
Validation keys:
p
Program
Exit
selection
Compulsory
+
Adjustment +
mode
Comfort
Economy mode
mode
TPG-IR
MANDO A DISTANCIA INFRARROJO
Absence mode Transmission
-
OK
Validation
Adjustment -
Frost protection
mode
2

STARTING

Open the battery lid located at the back part of the
remote control.
1. Remove the battery lid.
2. Remove the battery protection film.
The remote control must turn on.
3. Install back the battery lid.
Picture: remove the battery protection film.
The batteries discharge is indicated on the LCD
displayby the specific sign:
The backlit of the display is off once the remote
control batteries are discharged.
There is one minute time lapse to replace the
batteries before losing time and program settings.
3
PROGRAMMING
The remote control unit has:
- 4 main keys (wide keys)
- AUTO: key AUTO
- PROG: programming key
- Time Settings key
- Temperature setting key
- Other 4 keys, select validation, its function
corresponds to the picture indicated at the
Bottom of the display.
Main keys are priority keys over validation keys.
