SHARK JAW TOYS MAKO JET Instruction Manual

2g rc radio control
Hide thumbs
Table of Contents

Advertisement

Quick Links

1 1
2gRC Radio Control Batteries
1.
Insert eight (8) AA (Double A) batteries (not included) into the transmitter while taking careful note of proper
polarity clearly marked in the transmitter's battery compartment.
2.
Turn switch on to ensure the batteries have been installed correctly. When this is confirmed, turn radio off.
Charging the Aircraft Battery
Battery Capacity: 11.1 V, 1,000 mAh, Lithium Polymer
Typical Charge Time: One hour
1.
Read the warnings and directions very carefully.
2.
Following the guidelines, connect the battery pack to the charger.
3.
The charger light turns from red to green when battery is fully charged.
NOTE: The lithium polymer battery included with this plane can be
recharged 30-40 times. Thereafter it should be disposed of safely.
3
2
12
13
1
1
Throttle Stick
2
Attack Button (Thrust Boost)
3
Power LED
4
Antenna
5
Attack Button Engaged LED
6
Dual Rate Switch
4
5
6
7
8
9
10
11
21
7
Speaker
8
Elevon Stick
9
Aileron Trim
10
Elevator Trim
11
Neck Strap Hook
12
Power Switch
14
15
19
18
20
13
Throttle Trim
14
Internal Wing
15
Elevon Control Surface
16
Duct
17
Outboard Vertical Stabilizer
18
Coanda
16
15
14
17
19
Ducted Fan Unit
20
Battery Compartment
21
High-Impact Nose
