Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Restore Factory Press and hold for five seconds to restore factory settings (including all lighting effects and Settings macros). ※ After the settings are restored, a startup animation will run once to indicate that all settings have been restored.
Page 7
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide My Computer Open My Computer. Calculator Open the system's built-in calculator. Multimedia Player Open the system's built-in multimedia player.
Page 8
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Static: Switching Lighting (1). You can use Fn + F9 (red), F10 (green), and F11 (blue) to change the color of the lighting effect. Pulse: Effects(Front Side) (1). You can use Fn + F7 (slower) and F8 (faster) to adjust the speed of the lighting effect.
Page 9
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Static: Switching Lighting (1). You can use Fn + F9 (red), F10 (green), and F11 (blue) to change the color of the lighting effect (F12 will display the blended color).
Page 10
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Decreasing the Speed of Lighting Effects Five different lighting effect speeds (the will flash when the speed is set to the slowest setting). Increasing the Speed of Lighting Effects...
Page 11
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Adjust the brightness Ten brightness level settings for the green light (the will flash when the brightness of the green light is set to the brightest setting). ※ Press and hold for three seconds to clear the green value...
Page 12
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Changing the Direction of Lighting Effects You can switch the running direction of a specific lighting effect. Switching Profiles Up to six profiles can be saved. The current active profile is shown by the color displayed on the Red, P2: Green, P3: Blue, P4: Yellow, P5: Purple, P6: Aquamarine.
Page 13
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Macro Recording (only available under Game Mode): On-the-Fly Macro (1). Press Fn + PrtSc to enter recording mode (the entire keyboard will light up and the Record button...
Page 14
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Area Backlight Supports up to five presets: FPS1、FPS2、MMO、MOBA、RTS。 ※ All five presets listed above can be recorded and modified separately. Recording procedure (recording can only be activated while in Area Backlight...
Page 15
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Switching WASD and the Direction Keys Switches the functions of WASD keys with the arrow keys. Full Keyboard Lock Lock the entire keyboard ( indicator lights will flash at the same time to indicate the current status).
Page 16
Keyboard Features Features Overview TT Premium | Level 20 RGB User Guide Full Keyboard Brightness Adjustment A total of five brightness levels are available for adjusting the brightness of the keyboard's lighting effects. ※ The last level completely disables the backlight for all keys.
Software Installation Setup Instructions TT Premium | Level 20 RGB User Guide Step 1: Step 2: Launch the setup executable file (.EXE) file and click Next. Click Install to begin the setup process.
Page 19
Software Installation Setup Instructions TT Premium | Level 20 RGB User Guide Step 3: Once setup is complete, you will also need to install the Microsoft Visual C++ 2015 Step 4: Redistributable Package. ※ Without installing the Redistributable Package, the software will fail to launch.
Page 20
Chapter 3: Functions Available on the Home Page TT Premium | Level 20 RGB Mechanical Keyboard User Guide...
Switching Profiles Close Window: Close the display and minimize the program to the lower right corner. The Level 20 RGB can support up to 6 profiles, which can be switched as required. Switching Configuration Pages Switches between the configuration pages single- key operation, lighting effects and sync setting.
Default Function Default Key Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a key, then select a "Default" function from the drop-down list. Click Apply to change and save the new function.
Page 24
Single Key Function Single Key Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a key, then select "Single Key" from the drop-down list. Enter a new key value into the lower-right box.
Page 25
Single Key Function Single Key Setting TT Premium | Level 20 RGB User Guide Step 4: Step 3: Based on the information and color displayed on the screen, you will be able to Click Apply to change and save the new function.
Macro Function Macro Key Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: First, you must designate a key, then select "Macro" in the drop-down list. Select a macro from the upper-right.
Page 27
Macro Function Macro Key Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Select a macro repeat option from the drop-down list located in the Click Apply to save the new function. Verify if the new key function is applied lower-right corner.
Media Function Media Key Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a key, then select “Media" from the drop-down list. Select a multimedia function in the right drop-down list.
Page 29
Media Function Media Key Setting TT Premium | Level 20 RGB User Guide Step 4: Step 3: Based on the information and color displayed on the screen, you will be able to Click Apply to change and save the new function.
Hot Key Function Hot Key Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a key, then select "Function Keys" from the drop-down list. Select a type of hotkey function in the upper-right drop-down list.
Page 31
Hot Key Function Hot Key Setting TT Premium | Level 20 RGB User Guide Step 4: Step 3: Click Apply to save the new function. Verify if the new key function is applied Select a keyboard function in the lower-right drop-down list.
Page 32
Launch Application Function Application Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a key, then select "Launch Application" from the drop-down list. Select "Application" in the upper-right drop-down list.
Page 33
Launch Application Function Application Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on the Open File button located on the bottom-right. Select the executable file (.EXE) to open.
Page 34
Launch Application Function Application Setting TT Premium | Level 20 RGB User Guide Step 6: Step 5: Based on the information and color displayed on the screen, you will be able to Click Apply to change and save the new function.
Page 35
Launch Application Function Website Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a key, then select "Launch Application" from the drop-down list. Select "Web" in the upper-right drop-down list.
Page 36
Launch Application Function Website Setting TT Premium | Level 20 RGB User Guide Step 4: Step 3: Click Apply to save the new function. Verify if the new key function is applied Enter the URL into the textbox located on the bottom-right and press Enter.
Page 37
Gaming Profile Function Gaming Key Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Select a key, then select "Gaming Profile" from the drop-down list. Select a game title in the upper-right drop-down list.
Page 38
Gaming Profile Function Gaming Key Setting TT Premium | Level 20 RGB User Guide Step 4: Step 3: Click Apply to save the new function. Verify if the new key function is applied In the lower-right drop-down list, select an in-game action.
Disable Function Disable Key Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click Apply to save the new function. Verify if the new key function is applied Select a key, then select "Disable" from the drop-down list.
Page 40
Chapter 5: Functions Available on the Macro Page TT Premium | Level 20 RGB Mechanical Keyboard User Guide...
Page 41
Macro Page Macro Recording Setting TT Premium | Level 20 RGB User Guide New Macro / Delete / Copy / New Text / Import Record / Delete / Insert / Pause / Edit / Export Record: Begin macro recording. Delete: Delete the assigned value of a specific key.
Page 42
How to Record Macros Chapter 6: TT Premium | Level 20 RGB Mechanical Keyboard User Guide...
Page 43
Macro Recording Function Recording Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Add a new macro and modify its name. Select the delay method used to record the macro by using the checkboxes below.
Page 44
Macro Recording Function Recording Setting TT Premium | Level 20 RGB User Guide Step 4: Step 3: Enter the sequence to be recorded from the keyboard, then press the Stop Press the Record button. button to complete the recording.
Page 45
Macro Recording Function Insert Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select a macro by clicking on the key it is assigned to. Click the Insert button.
Page 46
Macro Recording Function Insert Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Select the position where new content is to be inserted. Press the Record button.
Page 47
Macro Recording Function Insert Setting TT Premium | Level 20 RGB User Guide Step 5: Step 6: Enter the sequence to be recorded from the keyboard. Click the Stop button to complete the insertion process.
Page 48
Text Recording Function Recording Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Add a new character set and modify its name. Enter the values for the "Start Key" and "End Key" in the upper right corner.
Page 49
Text Recording Function Recording Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on the input box located at the bottom-right corner and enter the Click the Save button to complete the recording of the character set.
Page 50
Chapter 7: Functions Available on the Lighting Effects Page TT Premium | Level 20 RGB Mechanical Keyboard User Guide...
Page 51
Lighting Page Lighting Function Setting TT Premium | Level 20 RGB User Guide Switching Lighting Effects Keyboard light of 13 lighting effects are supported: Static, Pulse, Wave, Spiral Rainbow, RGB Spectrum, Reactive, Flow, Ripple, Raindrops, Snake, Blink, Sound Control and System Temperature.
Static Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Static Area" in the Lighting Effect drop-down list.
Page 54
Static Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Adjust the brightness level of the keyboard's backlight. Click Apply to save the new settings.
Page 55
Static Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Switch the zones to "Customized." Click on a color inside the color wheel or enter the RGB color values to set the color.
Page 56
Static Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 3: Click on the keyboard image directly with the left mouse button to change the Step 4: key color. ※ Right click to cancel the color. Click Apply to save the new settings.
Pulse Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Pulse Area" in the Lighting Effect drop-down list.
Page 58
Pulse Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Adjust the backlight speed. Click Apply to save the new settings.
Page 59
Pulse Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Switch the zones to "Customized." Click on a color inside the color wheel or enter the RGB color values to set the color.
Page 60
Pulse Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 3: Click on the keyboard image directly with the left mouse button to change the Step 4: key color. ※ Right click to cancel the color. Click Apply to save the new settings.
Wave Mode Pattern Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select "Wave Area" in the Lighting Effect drop-down list. Select a set of color patterns on the upper-right.
Page 62
Wave Mode Pattern Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the direction, speed, and brightness level of the lighting effect. Click Apply to save the new settings.
Page 63
Wave Mode Customized Pattern Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Add a new set of color patterns. Add a new color-insertion point and drag it to the desired position.
Page 64
Wave Mode Customized Pattern Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on each color-insertion point to modify its color. Click Apply to save the new settings.
Page 65
Spiral Rainbow Mode Pattern Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select "Spiral Rainbow Area" in the Lighting Effect drop-down list. Select a set of color patterns on the upper-right.
Page 66
Spiral Rainbow Mode Pattern Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the direction, speed, and brightness level of the lighting effect. Click Apply to save the new settings.
Page 67
Spiral Rainbow Mode Customized Pattern Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Add a new set of color patterns. Add a new color-insertion point and drag it to the desired position.
Page 68
Spiral Rainbow Mode Customized Pattern Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on each color-insertion point to modify its color. Click Apply to save the new settings.
Page 69
Spectrum Cycling Mode Area Function Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Set the speed and brightness level of the backlight and click on Apply Select "Spectrum Cycling Area" in the Lighting Effect drop-down list.
Page 70
Reactive Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Reactive Area" in the Lighting Effect drop-down list.
Page 71
Reactive Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Adjust the backlight speed. Click Apply to save the new settings.
Page 72
Reactive Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Switch the area to "Customized." Click on a color inside the color wheel or enter the RGB color values to set the color.
Page 73
Reactive Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 3: Click on the keyboard image directly with the left mouse button to change the Step 4: key color. ※ Right click to cancel the color. Click Apply to save the new settings.
Flow Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Flow Area" in the Lighting Effect drop-down list.
Page 75
Flow Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the speed and brightness level of the backlight. Click Apply to save the new settings.
Page 76
Flow Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Set the area to "Customized", then add a new set of color patterns. Add a new color-insertion point and drag it to the desired position.
Page 77
Flow Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on each color-insertion point to modify its color. Click Apply to save the new settings.
Ripple Mode Color Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Ripple" in the Lighting Effect drop-down list.
Page 79
Ripple Mode Color Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the speed and brightness level of the backlight. Click Apply to save the new settings.
Page 80
Ripple Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Set the area to "Customized", then add a new set of color patterns. Add a new color-insertion point and drag it to the desired position.
Page 81
Ripple Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on each color-insertion point to modify its color. Click Apply to save the new settings.
Page 82
Ribbon Mode Color Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Ribbon" in the Lighting Effect drop-down list.
Page 83
Ribbon Mode Color Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the direction, speed, and brightness level of the lighting effect. Click Apply to save the new settings.
Scan Mode Color Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Scan" in the Lighting Effect drop-down list.
Page 85
Scan Mode Color Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the speed and brightness level of the backlight. Click Apply to save the new settings.
Page 86
Raindrop Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select "Raindrops Area" in the Lighting Effect drop-down list.
Page 87
Raindrop Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the speed and brightness level of the backlight. Click Apply to save the new settings.
Page 88
Snake Mode Color Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select “Snake" in the Lighting Effect drop-down list.
Page 89
Snake Mode Color Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the direction, speed, and brightness level of the lighting effect. Click Apply to save the new settings.
Page 90
Marquee Mode Color Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select “Marquee" in the Lighting Effect drop-down list.
Page 91
Marquee Mode Color Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Set the direction, speed, and brightness level of the lighting effect. Click Apply to save the new settings.
Page 92
Blink Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 2: Step 1: Click on a color inside the color wheel or enter the RGB color values to change Select “Blink Area" in the Lighting Effect drop-down list.
Page 93
Blink Mode Color Area Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Adjust the backlight speed. Click Apply to save the new settings.
Page 94
Blink Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Switch the zones to "Customized." Click on a color inside the color wheel or enter the RGB color values to set the color.
Page 95
Blink Mode Customized Setting TT Premium | Level 20 RGB User Guide Step 3: Click on the keyboard image directly with the left mouse button to change the Step 4: key color. ※ Right click to cancel the color. Click Apply to save the new settings.
Music Mode Color Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select “Music Mode" in the Lighting Effect drop-down list. Set the desired mode of lighting effects.
Sound Control Mode Color Setting TT Premium | Level 20 RGB User Guide Step 3: Step 4: Click on a color inside the color wheel or enter the RGB color values to change Click Apply to save the new settings.
Page 98
System Temperature Mode Function Setting TT Premium | Level 20 RGB User Guide Step 1: Step 2: Select "System Temperature" in the Lighting Effect drop-down list. Click Apply to save the new settings.
Chapter 9: Functions Available on the Settings Page TT Premium | Level 20 RGB Mechanical Keyboard User Guide...
Page 100
Settings Page Else Function TT Premium | Level 20 RGB User Guide Language Settings Sets the language of the program's user interface. Official Website / Social Media Official Website: Visit the Product official website. Social Media: Visit Thermaltake on Facebook.
Page 101
Chapter 10: TT iTAKE App Features Overview TT Premium | Level 20 RGB Mechanical Keyboard User Guide...
Page 102
TT iTAKE APP Download Download Step TT Premium | Level 20 RGB User Guide Step 2 Enter “TT iTAKE" into the search bar. Step 3 Step 1 Tap to download. Open the App Store.
Page 103
APP Connecting Connecting Step TT Premium | Level 20 RGB User Guide Step 2 Open TT iTAKE Engine Software and setting TT iTAKE App password. Step 1 Launch the TT iTAKE app.
Page 104
APP Connecting Connecting Step TT Premium | Level 20 RGB User Guide Step 3 Step 5 Enter TT iTAKE App password. Click to scan for devices. Step 4 In order to establish a connection, click on the IP address of the computer you wish to connect to.
Page 105
APP Connecting Input IP Connecting TT Premium | Level 20 RGB User Guide Connection Guide ※ Before attempting to establish a connection, please read these instructions carefully to prevent problems when searching for your device. Step 1 Enter the computer's IP address.
Lighting Function Pulse Setting Step TT Premium | Level 20 RGB User Guide Switching Device TT iTAKE Engine software Pulse Pulse support devices. Step 3 Select the color you wish to adjust or switch to random color mode (once activated, color selection Step 2 is no longer available).
Page 107
Lighting Function Wave Setting Step TT Premium | Level 20 RGB User Guide Wave Wave Switching Device TT iTAKE Engine software support devices. Step 3 Step 2 Select the direction of running lights. Select the lighting area, effects and preconfigured...
Macro Function Import Macro Setting Step TT Premium | Level 20 RGB User Guide Step 1 Step 3 Click to select the Select the key position for menu in the upper-left adding a new macro. corner. Step 2 Select "Macro“.
Page 109
Macro Function Import Macro Setting Step TT Premium | Level 20 RGB User Guide Step 4 Select a previously recorded macro from the Step 7 program. Tap on the button to activate the macro. Step 5 Select the type of game the macro will be used for.
Page 110
Macro Function Delete Macro Setting Step TT Premium | Level 20 RGB User Guide Step 1 Tap the icon located in Step 2 the upper-right corner to enter editing mode. Tap the trash can icon to delete the macro. Step 3...
Page 111
Virtual Controller Function Setting Step TT Premium | Level 20 RGB User Guide Gaming Profile A maximum of 10 profiles Can be saved. Default Settings Default Settings Step 1 “L" and “R" keys on "A", "B", “X", and “Y" keys Click to select the the keyboard.
Page 112
Virtual Controller Function Setting Step TT Premium | Level 20 RGB User Guide Step 3 Step 4 Tap the icon located in the upper-right corner to enter editing mode. Tap the icon located in the lower-right corner to add new keys.
Page 113
Virtual Controller Function Setting Step TT Premium | Level 20 RGB User Guide Step 6 Once it's added, move the key to the desired position, Step 5 and modify its value and size. Select the design of the new key.
Page 114
Virtual Controller Function Setting Step TT Premium | Level 20 RGB User Guide Step 8 Step 7 Once editing is complete, tap the confirmation icon in the upper-right Select the key settings you want to edit. corner to confirm your settings and exit editing mode.
Voice Control Function Setting Step TT Premium | Level 20 RGB User Guide Step 1 Click to select the menu in the upper-left corner. Step 2 Select "Voice Control“. Step 3 After tapping on the microphone icon, the app will begin to listen for voice commands.
Page 116
Virtual Keyboard Function Setting Step TT Premium | Level 20 RGB User Guide Step 1 Click to select the menu in the upper-left corner. Step 2 Select "Virtual Keyboard“. Step 3 Once the keyboard pops up, press the keys in order...
Page 117
Voice Control Table TT iTAKE APP Command Table TT Premium | Level 20 RGB User Guide Note Command (Chinese) Command (English) Description 紅色 Red Color Change all LED color “Red” 橙色 Orange Color Change all LED color “Orange” 黃色 Yellow Color Change all LED color “Yellow”...
Page 119
Voice Control Table Alexa Command Table TT Premium | Level 20 RGB User Guide Basic Command Color command Wake up Alexa Command Light Mode Color in Red color in Orange color in Yellow color Static Mode in Green color Pulse Mode...
