- Page 1 Operating Manual gilson porta-Screen® pS-3 & pS-4 Rev: 04/13/2011 pHOne: 800-444-1508 FaX: P.O. Box 200, Lewis Center, Ohio 43035-0200 800-255-5314 740-548-7298 e-mail: customerservice@gilsonco.com Website: www.globalgilson.com 740-548-5314...
- Page 2 Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® sAFeTy INsTrUCTIONs Whether you are the owner, employer, operator, or maintenance person for this machine, safety is your responsibility. You are responsible for operating and maintaining this equipment in compliance with these instructions and for using common sense.
-
Page 3: Table Of Contents
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® Table of Contents Page safety Instructions Unpacking & set-Up Operation Safety Precautions..........4 Timer Set-Up & Operation........5 Procedure............... 5 sample Capacity Coarse Aggregates..........6 Fine Aggregates............. 6 Maintenance & Disassembly Clamping System........... -
Page 4: Unpacking & Set-Up
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® Gilson Porta-screen ® The Gilson Porta-Screen is a portable shaker for field control of construction aggregates ® and for quality control in asphalt and ready-mix plants. It is designed for best separation in the 2in (50.8mm) to No.16 (1.18mm) range. -
Page 5: Timer Set-Up & Operation
Porta-Screen ® you may insert the required trays in the upper slots This unit is equipped with an easy-to-operate Gilson interval with the pan immediately below. Then fill the lower count-down timer. The timer has a large 0.6in LED display slots with extra trays. -
Page 6: Sample Capacity
If you are testing materials exclusively in the fine range, we recommend equipment specifically de- Minimum quantity of sample is usually established by the signed for this purpose, such as the Gilson Model SS-8R specifications of the test procedure. For example, ASTM Sieve Shaker. -
Page 7: Belts
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® rod (#50) is accessible. (Grease fitting may be Access to Belts: pointing either to the front or to the back of the Porta-Screen 1. DISCONNECT AND LOCK OUT ELECTRIC POWER. -
Page 8: Bearing Replacement
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® Tighten the bracket mounting screws. 2. Connecting Rod & Drive Shaft Bearings: The con- necting rod (#50) can be replaced as an assembly, or (5) Reassemble. you can press out and replace its bearing and bushing (#52). - Page 9 Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® s. Continue or reassemble in reverse order. When DO NOT PlUG IN THe POrTA-sCreeN UNTIl yOU ® replacing timing belt, refer to timing belt instructions Are reADy TO Use IT.
-
Page 10: Parts List
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® 5.0 PArTs lIsT PArTs NO. reqUIreD Outer Case & Frame Parts Top frame cross bar Top frame screw & lock washer Bullseye level with cushion washer Bullseye level adjusting screws... - Page 11 Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® PArTs NO. reqUIreD Connecting Rod Assembly Parts Connecting rod with grease fitting Connecting rod rubber bushing Connecting rod bearing with inner race — (Connecting rod assembly - Parts 50, 51, 52, assembled)
-
Page 12: Parts Diagram
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® 6.0 PArTs DIAGrAM Page 12... -
Page 13: Accessories
Gilson Company, Inc. Gilson Porta-Screen : PS-3 & PS-4 ® 7.0 ACCessOrIes Porta-screen Tray cloth has metal shields Porta-screen has Foot-Tab leveling. ® ® to eliminate partial openings. PsA-114 Porta wheels may be attached for added mobility. Ball-bearing wheel assemblies with rubber...
